Rocstor Y10A313-S1 User Manual

USB3.2 Type-C to HDMI(4K/60Hz)/USB-A 10G/USB2.0/
Type-C Data&PD Charging
Congratulations
Thank you for purchasing this premium Rocstor product. For optimum performance and
safety, please read these instructions carefully before connecting, operating or using this
product. Please keep this manual for future reference.
Introduction
Rocstor introduces the USB3.2 Type-C Adapter featuring DP1.4 Alt mode, providing an
all-in-one solution for video and data connectivity. Equipped with 1 HDMI port for
video transmission and 3 USB data ports (2 USB 10G, 1 USB 2.0) for data transmission,
this adapter o ers seamless integration for various devices. Additionally, the Type-C
port supports a maximum of 100W PD charging. Compatible with all DP Alt mode
supported Type-C hosts, this adapter ensures versatility and functionality across
di erent systems.
Package Contents
Before attempting to use this unit, please check the packaging and make sure the
following items are contained in the packaging:
• Main Unit x1
• User Manual
User Manual
Y10A313-S1
®
Features
Upstream:
USB Type-C Male (Connect to a host computer)
• Supports DP1.4 Alt mode
• Supports reversible connection
• Supports max 10Gbps data transmission and max 4K/60Hz video transmission
simultaneously
Downstream:
HDMI X1
• Supports max 4096x2160P/60Hz
video output
• Supports High Dynamic Range(HDR)
• Supports multiple color formats:
RGB; YCbCr4:4:4; YCbCr4:2:2;YCbCr4:2:0 ；
• Supports 8/10/12 bit Color depth
• Supports HDCP2.2 and HDCP1.4
Note: The actual resolution supported is
determined by the host and the Display.
Type-C Female X1
(for PD Charging & Data)
• Compliant USB3.2 Gen2 with max
10Gbps data transmission
• Supports PD3.0 with max 100W PD
Charging
• 8W is dedicated to the functioning of
this product, the rest power (max 92W)
will be passed to charge for the host
Speci cation
Input / Output Connector
Input
Output
Warranty
Limited Warranty
Mechanical
Weight
Size
Environmental
Operating Temperature Operating Temperature
Operating Humidity
Storage Temperature
Storage Humidity
Regulatory Approvals
Certi cations
Power Supply
Type
Accessory Adapter
User Manual
USB-A 10G X1 (blue core)
• Compliant USB3.2 Gen2 with max
10Gbps data transmission
• Max 1.5A downstream charging
• Support short-circuit, over-current,
over-voltage protection
USB-A 2.0 X1 (black core)
• Max 480Mbps per port
• Max 500mA downstream charging
• Support short-circuit, over-current,
over-voltage protection
USB-C Male x1
HDMI x1 （ Max 4K/60Hz）
USB-A 10G x1 （ USB3.2 Gen2）
USB-A 2.0 x1
Type-C Data & PD Charging x1
3 Years
1.9lbs (55g)
4.5x1.3x0.4in (115x34x11.5mm)
0°C to 45°C (32°F to 113°F)
10% to 85% RH (no condensation)
-10°C to 70°C (14°F to 158°F)
5% to 90 % RH (no condensation)
FCC, CE
External PD power
English Version
