Rocstor Y10A321-S1 User Manual

Type-C to HDMI/USB-A/
Type-C Data or PD3.1 Charging
Congratulations
Thank you for purchasing this premium Rocstor product. For optimum performance and
safety, please read these instructions carefully before connecting, operating or using this
product. Please keep this manual for future reference.
Introduction
Rocstor introduces this versatile hub combines Type-C connectivity with HDMI, USB-A,
and Type-C data and power capabilities. With one HDMI port for video and a USB-A 5G
port for data, plus a Type-C port supporting both 5G data and PD3.1 with up to 140W
charging, it's an all-in-one solution. Compatible with any Type-C host supporting DP
Alt mode, it ensures seamless connectivity for your devices.
Package Contents
Before attempting to use this unit, please check the packaging and make sure the
following items are contained in it:
• Main Unit x1
• User Manual
User Manual
Y10A321-S1
®
Features
Upstream:
USB Type-C Male (Connect to a host computer)
• Support DP1.4 Alt mode
• Support reversible connection
• Support PD 3.0 Fast Role Swap
Downstream:
HDMI X1
• Support max 4K/60Hz video output
• Support High Dynamic Range(HDR)
• Support multiple color formats: RGB;
YCbCr4:4:4; YCbCr4:2:2;YCbCr4:2:0 ；
• Support 8/10/12 bit Color depth
• Support HDCP2.3 and HDCP1.4
Note: The actual resolution supported is
determined by the host and the Display.
USB-A 5G X1
• Compliant USB3.2 Gen1 with max
5Gbps data transmission
• Supports max 1.5A downstream
charging
• Supports short-circuit, over-current
protection
Speci cation
Input / Output Connector
Input
Output
Mechanical
Weight Operating Temperature
Size
Warranty
Limited Warranty
Environmental
Operating Temperature Operating Temperature
Operating Humidity
Storage Temperature
Storage Humidity
Power Supply
Regulatory Approvals
Certi cations
Accessory Adapter
User Manual
Type-C Data & PD Charging X1
• Compliant USB3.2 Gen1 with max 5Gbps
data transmission
• Support PD3.1 with max 140W PD
Charging
• 8W is dedicated to the functioning of
this product, the rest power (max 132W)
will be passed to charge for the host
USB-C Male x1
HDMI (Max 4K/60Hz） x1
USB-A 5G (USB3.2 Gen1） x1
Type-C Data & PD Charging x1
(5G&PD3.1 140W）
1.1lbs - (32g) 0°C to 45°C (32°F to 113°F)
2.3x1.5x0.5in - (59x40x14mm)
2 Years
0°C to 45°C (32°F to 113°F)
10% to 85% RH (no condensation)
-10°C to 70°C (14°F to 158°F)
5% to 90 % RH (no condensation)
External PD power or bus power
FCC, CE
English Version
