- Page 1 Keysight Y1259A Advanced Cooling Spacer Kit For M9046A INSTALLATION NOTE...
- Page 2 These kits are designed for Keysight racks. A non-Keysight rack may require the use of support rails. The parts included with the Y1259A are listed in the following tables (note that not all parts listed are available as field-replaceable parts).
- Page 3 - If instruments or modules in the chassis are consuming maximum power, 1U of rack space is required for ventilation below the Keysight PXIe chassis. To prevent injury during rack mounting, the chassis should be empty and two people should lift it into the rack.
- Page 4 Procedure Keysight Y1259A Advanced Cooling Spacer Kit for M9046A Installation Note Remove two M3 screws from chassis top cover Remove two M3 screws from chassis fan tray Figure 1 Removing the screws 2 Place Cooling Spacer (M9044-80202) on top of the Chassis. See...
- Page 5 Keysight Y1259A Advanced Cooling Spacer Kit for M9046A Installation Note Procedure 5 Make sure the Cooling Spacer orientation is as per below illustration. See Figure Spacer Air Blocker M9044-04105 Figure 3 Cooling Spacer orientation. Please see below. 6 Slot in the Spacer Air Blocker (M9044-04105) into Cooling Spacer and rotate 90º...
- Page 6 Procedure Keysight Y1259A Advanced Cooling Spacer Kit for M9046A Installation Note PSU Air Channel Installation require Y1257A/Y1258A Rack Mount Kit. 9 Remove PSU Air Channel top cover by unfastening five of the thumb screws. Figure Figure 5 Removing PSU Air Channel top cover 10 Attach PSU Air Channel latches on the rack rail.
- Page 7 Keysight Y1259A Advanced Cooling Spacer Kit for M9046A Installation Note Procedure 11 Secure PSU Air Channel bottom cover to chassis with five (5) M3 x 6mm Pan Head Torx T10 screws (0515-0430). See Figure M3 x 6mm Pan Head Torx T10 Screw...
- Page 8 Procedure Keysight Y1259A Advanced Cooling Spacer Kit for M9046A Installation Note Keysight Y1259A Advanced Cooling Spacer Kit for M9046A Installation Note...
- Page 9 This information is subject to change without notice. © Keysight Technologies 2021 First Edition November 2021 *Y1259-90001* Y1259-90001 www.keysight.com...
