FURNISHING, USE, OR these rights customarily provided PERFORMANCE OF THIS to the public to use, modify, DOCUMENT OR ANY INFORMATION reproduce, release, perform, CONTAINED HEREIN. SHOULD display, or disclose commercial KEYSIGHT AND THE USER HAVE A computer software or SEPARATE WRITTEN AGREEMENT...
“Returning a Device to Keysight” on page See also, Preparation For Use The 11612B bias network is connected in line with the device to be biased. The bias is applied through the SMB snap-on connector. Refer to Figure 2 on page 5.
Failure to do so may result in irreparable damage to the bias coil. Bias coils damaged by overheating are not covered under warranty. Table 1 11612B Specifications Power Frequency Range DC Resistance from Bias Port to Output Port (typical) °...
Failure to do so may result in irreparable damage to the bias coil. Bias coils damaged by overheating are not covered under warranty. Table 2 11612B Supplemental Characteristics 0.000 to 0.0076 mm (0.0000 to 0.0030 inches) Pin Depth Impedance...
Transistors and negative resistance devices may oscillate if the bias port of the 11612B bias network is not properly terminated. Keysight recommends that bias from the bias supply be routed through the 11635A bias decoupling network before being applied to the bias port of the 11612B.
Page 7
11612B bias network is not properly terminated. Keysight recommends that bias from the bias supply be routed through the 11635A bias decoupling network before being applied to the bias port of the 11612B. An adapter cable (part number 5062-4550) is included to connect the bias network and the bias decoupling network.
1. Connect the equipment for a standard reflection measurement. 2. Calibrate the system with an open and a short. 3. Connect the appropriate RF port of the 11612B to the network analyzer test port. Terminate the opposite port with a 50 ohm load.
Page 9
1. Connect the equipment for a standard insertion loss measurement. 2. Calibrate the system with a through line. 3. Replace the through line with the 11612B. 4. Measure the insertion loss. Refer to the specifications listed in this document. See also, Table 4, “11612B Insertion Loss.”...
General Information Table 5 Performance Test Record ELECTRICAL SPECIFICATIONS Serial Number: ______________ Tested by: ______________ Date: ______________ Return Loss Measured Value Input Port 0.045 to 10 GHz 10 to 20 GHz 20 to 30 GHz 30 to 50 GHz Output Port 0.045 to 10 GHz 10 to 20 GHz 20 to 30 GHz...
Page 11
General Information Returning a Device to Keysight If your device requires service, contact Keysight Technologies for information on where to send it. See “Contacting Keysight” on page 10. Include the following information: — your company name and address — a technical contact person within your company, and the person's complete telephone number —...
Keysight office are available on the Web at: www.keysight.com/find/assist In any correspondence or telephone conversation, refer to the Keysight product by its model number and full serial number. With this information, the Keysight representative can determine whether your product is still within its warranty period.
