Omron D4A-N Datasheet page 20

Coil Spring
D4A-1@16N, D4A-2@16N
Levers (for Roller Lever Switches)
Note: No D4A-0003N or D4A-0004N head should be used with the adjustable roller lever or mechanical malfunctioning could result because the
total weight of the adjustable roller lever is comparatively large. Use a standard-load head (D4A-0001N or D4A-0002N) instead.
Roller Lever
D4A-A00
19.1 dia.
Stainless
sintered
roller
38.1
7.3 dia.
M5 Allen bolt
18
Roller Lever
D4A-A30
19.1 dia.
(see
note)
38.1
7.3 dia.
18
M5 Allen bolt
Note: Stainless sintered roller
F-28
General-purpose Limit Switch
(106.5)
2.6R
6
2.6R
Note: 1. The stainless rod can be operated from any direction except the axial direction (i.e., from the top).
2. The optimum operating range of the stainless rod is within 1/3 of the entire length from the top end.
Roller Lever
D4A-A10
11.5
19.1 dia.
7.9
38.1
9 M5 Allen bolt
Roller Lever
D4A-B06
7.9
17.5 dia.
33.7
9
M5 Allen bolt
39.4
Note: Stainless sintered roller
D4A-@N
(see note 1)
(see note 2)
PT
150
Four, M4 (length: 12)
screws for head
27
+0.2
5.2 dia.
0
mounting holes
70.5
59.5±0.2
0.8
Two, M5 (length: 20)
5.2
screws for box
29.4±0.2
1/2-14NPT
42
conduit
19.5
7.9
Stainless
sintered
roller
7.3 dia.
18
9
21
15
(see note)
7.3 dia.
18
9
6.5 dia.
Stainless steel coil spring
21
75.5
Two, No.10-32UNF
16.5
(depth: 10) screws for
28
back-mounting
29.5
44
Roller Lever
D4A-A20
19.1 dia.
Stainless
sintered
roller
38.1
7.3 dia.
M5 Allen bolt
18
7.9
9 16.5
