Omron CX-PROGRAMMER V8.1 Operation Manual page 98

CPU Unit Function Block Specifications
Item
Function Maxi- 128
blocks mum
number of
definitions
Maxi- 256
mum
number of
instances
Com- Total for 704
ment all files
Memory (Kbytes)
Unit (ver.
4.0 or
later)
Inside Function 256
com- block pro-
ment gram
memory memory
(ver. 3.0 (Kbytes)
or later)
Com- 64
ment files
(Kbytes)
Program 64
index files
(Kbytes)
Variable 64
tables
(Kbytes)
CP1H CPU Units
Item
Model
Max. number of I/O points
Program capacity (steps)
Data memory
Number of connectable Expan-
sion Units and Expansion I/O Units
Function blocks Maximum num-
ber of definitions
Maximum num-
ber of instances
Inside comment Function block
memory program mem-
ory (Kbytes)
Comment files
(Kbytes)
Program index
files (Kbytes)
Variable tables
(Kbytes)
Units with internal I/O functions
X models
CP1H-X40DR-A
CP1H-X40DT-D
CP1H-X40DT1-D
320 points (40 built-in points + 40 points/Expansion
Rack x 7 Racks)
20K
32K words
7 Units (CP-series Expansion Units and Expansion I/O Units)
128
256
256
64
64
64
Specification
Units without internal I/O functions
XA models
CP1H-XA40DR-A
CP1H-XA40DT-D
CP1H-XA40DT1-D
Section 2-8
Y models
CP1H-Y20DT-D
300 points (20 built-in
points + 40 points/Expan-
sion Rack x 7 Racks)
73
