Instance Specifications
Note
Note
CJ2-series CPU Units
FB Instance
Area
Start address
Non Retain H512
Retain H1408
Timers T3072
Counters C3072
Force-setting/resetting is enabled when the following EM banks are specified:
CJ2H-CPU64(-EIP)/-CPU65(-EIP)
CJ2H-CPU66(-EIP)
CJ2H-CPU67(-EIP)
CJ2H-CPU68(-EIP)
CS/CJ-series CPU Units Ver. 3.0 or Later, and NSJ Controllers
FB Instance
Area
Start address
Non Retain H512
Retain H1408
Timers T3072
Counters C3072
FQM1 Flexible Motion Controllers
FB Instance
Area
Start address
Non Retain 5000
Retain None
Timers T206
Counters C206
CP-series CPU Units
FB Instance
Area
Start address
Non Retain H512
Retain H1408
Timers T3072
Counters C3072
DM area of CP1L-L
Address CP1L-L
D0000 to D9999 Provided
D10000 to D31999 Not Provided
D32000 to D32767 Provided
Default value
End address Size
H1407 896
H1535 128
T4095 1024
C4095 1024
EM bank 3
EM banks 6 to 9
EM banks 7 to E
EM banks 11 to 18
Default value
End address Size
H1407 896
H1535 128
T4095 1024
C4095 1024
Default value
End address Size
5999 1000
T255 50
C255 50
Default value
End address Size
H1407 896
H1535 128
T4095 1024
C4095 1024
Section 2-3
Applicable memory
areas
CIO, WR, HR, DM,
EM (See note.)
HR, DM, EM (See note.)
TIM
CNT
Applicable memory
areas
CIO, WR, HR, DM, EM
HR, DM, EM
TIM
CNT
Applicable memory
areas
CIO, WR, DM
TIM
CNT
Applicable memory
areas
CIO, WR, HR, DM (See
note.)
HR, DM (See note.)
TIM
CNT
