Summary of Contents for Belling BAFF504SS
- Page 1 Instruction Manual Refrigerator-Freezer BAFF504SS...
-
Page 3: Safety Warnings
Safety warnings Important note: Please read this booklet before installing and switching on this appliance. The manufacturer assumes no responsibility for incorrect installation and usage as described in this booklet. This model uses natural refrigerant gas as part of its cooling system. This gas is known as R600a(Isobutene) and is environmentally friendly but can be combustible. -
Page 6: Your Applianceand The Compartments
When the fridge door is low: Open the door, use a wrench to rotate the adjusting nut anti-clockwise to raise the height of the door. Once the doors are aligned, then tighten the locking nut by rotating it clockwise. When the fridge door is high: Open the door, use a wrench to rotate the adjusting nut clockwise to lower the height of the door. -
Page 7: Usage Information
Usage Information Control panel Button - lock/ unlock, long press for 3 seconds to lock or unlock display screen. Except for the button of DISPENSER, operation for other function keys shall be done after the display screen is unlocked. Lock/ unlock icons, when the display screen is locked, an icon of a locked lock is shown, and icon of an unlocked lock is shown for unlocked display screen. - Page 8 Usage Information Icon of suspension, the icon lights when the function of suspension takes effect, otherwise the icon light is off. The “suspension mode” is designed for situations where the ridge compartment is not used for a long time, then the cooling system of fridge compartment stops working and the freezing chamber operates at a mid-range temperature of 18 °C automatically.
-
Page 9: Equipment Preparation
Usage Information Equipment Preparation Step 1 A new equipment may smell, please clean the inner chamber of the fridge with warm vinegar water to remove it. Do not use soap or irritating, abrasive, alkaline or solvent cleaning agent. Appropriate Location Refrigerant is hazardous! The refrigeration cycle system of combined fridge-freezers contains environmentally friendly but combustible refrigerant iso-butane (R600a). -
Page 10: Connection To Water Supply
Usage Information Connection to Water Supply Water hazards! The water pressure of combined fridge-freezers is 2 - 7 bars. If water pressure is too high, please install a decompressor. Please consult your local water authority or a professional, to determine your water pressure. - Page 11 Usage Information Instructions of ice-making machine – Sounds will be produced during making ice cubes and crushed ice: Water valve will produce buzzing sounds; water flowing into ice vessel will produce sounds; grinding machine's grinding ice into small pieces or ice cubes falling into the container will produce sounds.
- Page 12 Usage Information Dispensing crushed ice 1. Keep pressing the buttons of Water Dispenser until the icon lights up. 2.Press your container close to the dispenser to avoid spillage. 3. Press the container in the direction of dispenser levera 18. Fill the container with crushed ice.
-
Page 13: Bulb Replacement
Usage Information Shelving and rack adjustment Important note: all food and drink should be removed from all shelves and racks before adjusting or removing them You can adjust the shelving in the fridge compartment to your required configuration. To remove a shelf, lift it up slightly so the plastic stabilisers that on either side of the shelf are above the shelf rails and then pull it towards you. -
Page 14: Energy Saving Advice
Energy Saving Advice Do not install the appliance close to sources of heat, such as a cooker, dishwasher or radiator. Locate the appliance in a cool well-ventilated room and make sure that the air vents are clear. Try to avoid keeping the doors open for a long time, as warm air will enter the cabinet and may cause a build-up of ice as well as affecting the energy consumption. -
Page 15: Maintenance And Cleaning
Maintenance & Cleaning Disconnect the appliance from the power supply before cleaning. Internal Cleaning Do not pour water over the appliance. The cavity should be cleaned periodically using a solution of bicarbonate of soda and lukewarm water (5ml to 0.5 litre of water) Clean the accessories separately with soap and water. -
Page 16: Troubleshooting
Trouble shooting Problem Solution Check that the appliance is switched on. Check that there has not been a power cut. Check that the plug is not faulty. The fridge/freezer does Check that the fuse has not blown. not work Check that the voltage is correct for the appliance. Are there any faults with the socket? For this purpose, try the plug of your appliance by connecting it to a socket which you are sure is working. - Page 17 Trouble shooting Problem Solution Ensure there are no obstructions preventing door closure. Check the door compartments and shelves are correctly The doors do not close in place. properly Check the door seal is not warped or torn. Check the appliance is level. Check that the appliance is on a flat, level surface and is stable.
- Page 18 serviceireland@glendimplex.com sparesireland@glendimplex.com www.glendimplexireland.com...
