Arduino Alvik AKX00066 Product Reference Manual page 8

Part
Qwiic Connector
Servomotor Connector
18650 Li-Ion Battery
Main Chassis
Motor holder
Motors
Rubber wheel
Inox steal ball 9 mm
Ball caster holder
INOX M3 x 5 mm Screws
Battery cover
8 / 17
Quantity
2
2
1
1
Plastic support to hold the motor in place, a screwdriver is required to
2
2
2
1
1
5
1 Cover to hold the battery, a screwdriver is required to open it
Arduino® Alvik
Details
I2C Qwiic Connector to extend robot capabilities
3-pins connector to attach servomotors
Battery of the robot
Main chassis of the robot made in plastic
open it
DC Motor with magnetic relative encoder
Rubber wheel with 34 mm of diameter
Ball that serves as third support for stability
Plastic support to hold the steal ball
Phillips Screws of the robot
