- Page 1 ADT680A/680P Digital Pressure Gauges ADT680AEx/680PEx/601Ex Digital Pressure Gauges Quick Start Guide [Version: 2403V01]...
-
Page 2: Safety Instructions
◆ Please be sure to store, transport and use this product in the correct direction. ◆ If the product is damaged or malfunctions, please do not use it and contact Additel. ◆ Never use the non-Ex product in an explosive, steam, or dust environment. -
Page 3: Basic Structure
IECEx CSA 23.0046X CSANe 23ATEX1214X 2.CSA: Class I, Division 1,Groups A,B,C and D,T4 Class I, Zone 0,AEx ia IIC T4 Ga CSA 24CA 80172346X Ex ia IIC T4 Ga Ta=-20℃to+50℃ Basic Structure Basic structure of ADT680A/680AEx/601Ex Basic structure of ADT680P/680PEx... - Page 4 Basic structure list Name Description Display Show pressure, menu… Short press: switch units in main display, move to right, “return” Units button Long press: go to Settings in main display Backlight button Short press: backlight on/off in main display or move downward. Long press: view peak values in main display Short press: pressure zero in main display, or “Confirm.”...
-
Page 5: Power Supply
Power Supply 1. ADT680A/680P: Power can be supplied by 3*AA(LR6) battery or 9814 RS232 power supply communication kit (Optional). ADT680A/680P adapter diagram ADT680A/680P battery installation Warning: ◆ When using battery as power supply, please replace batteries if a low battery is indicated. - Page 6 2. ADT680AEx/680PEx/601Ex: Only use approved battery models (see below) ADT680AEx/680PEx/601Ex battery installation Approved battery models: Manufacturer Type (-18~45) ℃ ENERGIZER (-20~60) ℃ Maxell (-30~55) ℃ Rayovac Warning: ◆ When using battery as power supply, please replace batteries if a low battery is indicated.
-
Page 7: Display And Buttons
Display and Buttons 1. Display and buttons description: Display and buttons description... -
Page 8: Menu Structure And Operation
Menu Structure and Operation 1. Menu structure Long press to enter menu and start, please also refer to display and buttons description diagram. Menu structure... -
Page 9: Error Code
2. Basic menu operation Basic menu operation Error Code Code Description Solutions Wrong password Check the password Parameter over The entered value exceeds the range allowed by the pressure range gauge, please enter a new value Operation failed Try again... - Page 10 Link App Connection 1. Scan the QR Code to Download Link App Additel Link is a mobile app available on Android and iOS system. It can connect to pressure gauges through Bluetooth, display real-time pressure reading and status, configure gauge parameters, switch pressure units, pressure zero, start/stop data log, download and view data from the gauge, calibrate pressure gauges and export CSV data for sharing.
- Page 11 3.2 Manual Connection by Searching MAC Address...
-
Page 12: Calibration Example
Calibration Example Enter password “1234” to calibrate, complete the calibration by go to: lower limit calibration point -> show lower limit measured value -> upper limit calibration point -> show upper limit measured value. Calibration example... - Page 13 M e t r o l o g y M a d e S i m p l e Statement The product technical specifications, accessories and other related information in this manual are subject to change without prior notice. Please contact Additel Corporation if you have any questions. Additel Corporation Website: www.additel.com...
