  • Page 1 680A/680P/680AEx/680PEx/601Ex Digital Pressure Gauge...
  • Page 3 Additel680A/680P/680AEx/680PEx/601Ex Digital Pressure Gauge -------User Manual [Version：2405V01] Additel Corporation...
  • Page 5 This user manual provides operating and safety instructions for AdditelDigital Pressure Gauges. To ensure correct operation and safety, please follow the instructions in this manual. Additel Corporation reserves the right to change the contents and other information contained in this...

  • Page 7: Table Of Contents

    Content 1.Introduction ..................................2 1.1 General Introduction ..............................2 1.2 Technical Specifications ............................. 3 1.3 Features ..................................5 1.4 Basic Structure ................................6 1.5 Power Supply ................................10 1.6 Battery Life and Configuration ..........................11 2.Display and Operation ..............................14 2.1 Main Display ................................
  • Page 8 2.9 Cycle Selection Keyboard Display and Editing ......................21 3.System Settings ................................23 3.1 Data Log Settings ..............................23 3.1.1 Start/stop Data Log ............................23 3.1.2 Occupied Storage Capacity ..........................24 3.1.3 Interval Setting..............................24 3.1.4 Clear Data ................................. 24 3.2 Configuration ................................
  • Page 9 3.7.2 Bluetooth Auto-off Settings ..........................33 3.7.3 Serial Settings ..............................33 3.8 Operation Error Codes ............................. 33 4.Connect to Additel Link app ............................35 4.1 Download Additel Link .............................. 35 4.2 Enable the Bluetooth..............................35 4.3 Connect to the Gauge .............................. 35 4.3.1 Scan the Code ..............................
  • Page 10 Figure Content Figure 1 Basic Structure of ADT680A/680AEx/601Ex ......................6 Figure 2 Basic Structure of ADT680P/680PEx ........................7 Figure 3 Install batteries ..............................10 Figure 4 Power supply by adapter ............................. 10 Figure 5 Main Display................................ 15 Figure 6 Main Operation Interface ............................. 16 Figure 7 Pressure percentage indication ...........................
  • Page 11 Figure 17 Upper limit calibration ............................31 Figure 18 Calibration status menu ............................ 32 Figure 19 QR code for downloading Additel Link ......................35 Figure 20 Scan code for connection ..........................36 Figure 21 Manual search for connection ........................... 36...
  • Page 13 Safety Instructions Warning: The situation that poses a threat to user safety. Attention: The condition that may cause damage to the gauges or affect the calibration result. Warning: To prevent the user from injury, please followthis user manual for use. To prevent fire, electric shock, or personal injury, please do as follows: 1.

  • Page 14: Introduction

    ADT680A/680P/680AEx/680PEx/601ExDigital Pressure Gauge series is the latest generation digital pressure gauges introduced by Additel Corporation. It is mainly used to calibrate precision pressure gauges, general pressure gauges, sphygmomanometers or other pressure instruments and it can also be widely used for precision pressure measurement.

  • Page 15: Technical Specifications

    1.2 Technical Specifications Table 1Technical Specifications ADT680A ADT680AEx ADT680P ADT680PEx ADT601Ex Item None Ex ia IIC T4 Ga None Ex ia IIC T4 Ga Ex-proof level Ex ia IIC T4 Ga Protection Level IP67 Case Material φ140mm*119mm Dimensions 148mm*105mm*48mm 142mm*92mm*43mm Weight 620g 730g...
  • Page 16 1. Storage Temperature ： (-40 ～ 75) ℃ 2. Operating Temperature ： (-20 ～ 50) ℃ Environmental 3. Humidity：(10～95)%RH, non-condensing Pressure range Please refer to Additel website and accuracy Functional Peak value, filter, tare, pressure unit switch, data logging. features...

  • Page 17: Features

    1.3 Features ◆Ultra-low power consumption design, long-term operation; ◆Wide pressure ranges(100kPa～4200 bar); ◆Data logging up to 800,000 records (Time+Pressure)

  • Page 18: Basic Structure

    1.4 Basic Structure Figure 1Basic Structure of ADT680A/680AEx/601Ex...
  • Page 19 Figure 2Basic Structure of ADT680P/680PEx...
  • Page 20 Table 2 Basic Structure Part Name Icon Description Show pressure, menu…… Display Short press: switch units in main display, move to right, “return” Unit button Long press: go to Settings in main display Short press: in main display, backlight on/off; other menus, move downward Backlight button Long press: view peak values in main display Short press: pressure zero in main display, or “Confirm”...

  • Page 22: Power Supply

    1.5 Power Supply For ADT680A/680P, Power can be supplied by battery or 9814 RS232 power supply communication kit (Optional). Figure 3Install batteriesFigure 4Power supply by adapter...

  • Page 23: Battery Life And Configuration

    For ADT680AEx/680PEx/601Ex, power is supplied by battery. Table 3Approved battery models Manufacturer Type (-18~45) ℃ ENERGIZER (-20~60) ℃ Maxell (-30~55) ℃ Rayovac Warning:  If using battery, please replace battery when the device is automatically powered off due to low power. ...
  • Page 24 4,000 h Low power consumption 3 readings/ 1 s(L) Low power consumption 2 readings/ 1 s (L) 5,000 h Low power consumption 1 reading/ 1 s (L) 9,000 h Low power consumption 1 reading/ 2 s (L) 10,000 h Low power consumption 1 reading/ 3 s (L) 11,000 h Low power consumption...

  • Page 26: Display And Operation

    Display and Operation 2.1 Main Display Main display as shown in Figure 5: ◆Status bar: Including battery, wireless, Bluetooth, REC, button lock,filter, ABS, Min, Max, and tare icon. When the battery power is too low, it will prompt the low battery to automatically turn off and will start to countdown to turn off the gauge automatically.

  • Page 27: Main Operation Interface

    Figure 5 Main Display 2.2 Main Operation Interface After the pressure gauge is turned on, it first displays the interface of the original range of the pressure module. 3 seconds later, it will enter the main display immediately. The main display is divided into: status bar, pressure unit area, pressure value areaand pressure percentage display area, as shown in Figure 6.

  • Page 28: Buttons

    Figure 6 Main Operation Interface 1. Status Bar: Including battery, filter status, absolute pressure, Bluetooth, data log and button lock; 2. Unit ： Pressure unit, press Unit button to switch; 3. Data display area: Display pressure values ； 2.3 Buttons Power button: Short press to unlock the buttons.Long press to power on/off the gauge;...

  • Page 29: Pressure Measurement

    Zero button: Short press: pressure zero in main display, or “Confirm.”Long press: Bluetooth on/off in main display. 2.4 Pressure Measurement When the gauge is in the main display, it will show the current pressure unit and real-time pressure value in unit area and display area.

  • Page 30: Pressure Tare

    2.4.4 Pressure Tare When tare is enabled in the secondary menu, the current pressure value will be assigned to the tare value. At this moment, tare takes effect, and the tare icon will be flashing. Return to the main display and short press the Zero button to disable the tare function.

  • Page 31: Screen Lock And Unlock

    Figure 9 Minimum pressure value Table 5Pressure peaks setting Subject Introductions Maximum Value Minimum Value Zero Reset data 2.6 Screen Lock and Unlock Short press the Power button to lock and unlock the screen. When the screen is locked, a lock icon will be displayed in the status bar.

  • Page 32: Password Keyboard Display And Editing

    2.7 Password Keyboard Display and Editing The password keyboard will pop up when performing pressure gauge calibration, restore tofactory setting and clear the data log. The password keyboard can edit each digit. The digit being edited will flash, short press the Down button to switch numbers, and short press Right button to move to next digit.

  • Page 33: Numeric Keyboarddisplays And Editing

    2.8 Numeric KeyboardDisplays and Editing The pressure gauge provides a numeric keyboard, as shown in Figure 11. Adjust the value for each digit, digit being edited will flash, short press Down button to switch numbers, and short press Right button to move to next digit. Short press Enter button to confirm.Short press Power button to go to previous menu.
  • Page 34 Figure 12Cycle selection keyboard...

  • Page 35: System Settings

    System Settings In the main display, long press the Settings button to enter the system setting, and short press the Settings button in the setting interface to return. In the system settings, short press the Down button to cycle through the various menus. If a menu contains submenus, short press theEnterbutton to switch each submenu.

  • Page 36: Occupiedstorage Capacity

    Figure 13 Data log display 3.1.2 OccupiedStorage Capacity The title bar displays 2.CAP, short press Enter button to view the occupied storage capacity. 3.1.3 Interval Setting The title bar displays 3.GAP, short press Enter button to edit the logging interval, range is from 1 s to 99999 s, or 0.1 s. When editing, short press the Power button to give up and return to previous menu, short press Enter button to save and return to previous menu.

  • Page 37: Pressure Sampling Rate

    3.2.1 Pressure Sampling Rate The display area displays 1.RATE, short press the Enter button to enter the pressure sampling rate setting. 3-1L means that the pressure module takes 3 samples per second. For ADT680A/680AEx/680P/680PEx, the default setting is 3 times per second in low power mode. For ADT601Ex, the default setting is 1 time per second in low power mode. The pressure gauge provides the following sampling rate settings: 10━1(10readings /1sec) 3━1L(3readings /1sec) 2━1 L(2readings /1sec) 1━1 L(1reading /1sec) 1━2 L(1reading /2sec) 1━3 L(1reading /3sec) 1━4 L(1reading /4sec) 1━5 L(1reading /5sec) 1━6 L(1reading...

  • Page 38: Filter

    3.2.5 Filter The display areadisplays 5.FILT, short press Enter button to enter the filter mode settings. OFF means to turn off the filter, 1Ord means to select the first-order filter mode, and 3~10 mean the average filter.(available only for ADT680A/680AEx/680P/680PEx) Table 6 Filter settings Subject Effective values...

  • Page 39: Temperature Unit Settings

    pressure value will be captured once as the Tare value. Press the Zero button again and Tare will no longer take effect. (available only for ADT680A/680AEx/680P/680PEx) 3.2.7 Temperature Unit Settings The display area displays 7.TEMP, short press the Enter button to enter the temperature unit settings. It supports Celsius and Fahrenheit unit switching.

  • Page 40: Calibration Process

    3.5.2Calibration Process There are two situations of calibration. (1) Single-range instrument: 2-point calibration, the default calibration points are upper and lower limits of the range. The order is to calibrate the lower limit first and then the upper limit. After the upper limit is calibrated, it will return to the calibration status interface.
  • Page 41 Figure 14 Lower limit calibration point 2. Start lower limit calibration, as shown in Figure15. The display area shows the measured pressure value, after the pressure stabilized, short press Enter button to confirm. Figure 15 Lower limit calibration...
  • Page 42 3. Display the upper limit calibration point, as shown in Figure 16, the identifier area displays Max to indicate the upper limit of calibration. The display area displays the pressure reference value being edited. If the user wants to change calibration point, just change it directly.
  • Page 43 4. Start upper limit calibration, as shown in Figure18. After the pressure stabilized, short press Enter button to confirm. Figure 17 Upper limit calibration...

  • Page 44: System Settings

    5. Now the calibration is completed, return to calibration status menu and it will show CAL-1, which indicates the calibration takes effect. As shown in Figure 18. Figure 18 Calibration status menu 3.6 System Settings 3.6.1 Restore to Factory Settings The display area displays 1.REST, short press Enter button to enter password, the default password is: 1234.Then short press Enter button torestore to factory settings.

  • Page 45: Pressure Module Version Information

    3.6.4 Pressure Module Version Information The display area displays4.PM, short press Enter button to view the pressure module version. (available only for ADT680P/680PEx) 3.7 Communication Settings 3.7.1 Bluetooth MAC Address The display area displays 1.MAC, short press Enter button to view the Bluetooth MAC address. Only the last five digits of the MAC address will be displayed.
  • Page 46 range, enter a new value Operation execution failed Try it again...

  • Page 47: Connect To Additel Link App

    Connect to Additel Link App 4.1 Download Additel Link Additel Link is a mobile app available on Android and iOS system. It can connect to pressure gauges through Bluetooth, display real-time pressure reading and status, configure gauge parameters, switch pressure units, pressure zero, start/stop data log, download and view data from the gauge, calibrate pressure gauges and export CSV data for sharing.

  • Page 48: Manual Connection By Searching Mac Address

    Figure 20 Scan code for connection 4.3.2 Manual Connection by Searching MAC Address Figure 21 Manual search for connection...

  • Page 49: Copyright

    Copyright Additel owns all copyrights to this system and reserves all rights. Please respect the rights of our company.

  • Page 50: Appendix A：rs232 Module Db9 Pins Description

    Appendix A：RS232 Module DB9 Pins Description Figure 22 RS232 module DB9 female pins description Table 8RS232 Module DB9 Pins Description Pins Description Reserved Reserved...
  • Page 51 Reserved Reserved Reserved Reserved...

  • Page 52: Appendix B: Special Notice For Adt680Aex/680Pex/601Exserial Connection

    Appendix B: Special Notice for ADT680AEx/680PEx/601ExSerial Connection Any data download devices connected to theADT680AEx/680PEx/601Exshall be approved by SELV or Class 2 equipment against IEC 60950 or an equivalent IEC standard. The maximum voltage Um from the device shall not exceed 5.5 Vdc for USB port and 16 Vdc for RS232 port.

  • Page 53: Appendix C：adt680Aex/680Pex/601Ex Ex-Proof Description

    Appendix C：ADT680AEx/680PEx/601Ex EX-Proof Description Conform below intrinsically safe certifications: IECEx&ATEx： Ex ia IIC T4 Ga Ta=-20℃to+50℃ IECEx SIR 21.0018X CSANe 21ATEx2078X CSA： Class I,Division 1,Groups A,B,C and D,T4 Class I,Zone 0,AEx ia IIC T4 Ga CSA 21CA 80045682X Ex ia IIC T4 Ga Ta=-20℃to+50℃...
