TABLE OF CONTENTS
Introduction .......................................................................................2
Caution ............................................................................................... 2
Notes .................................................................................................. 2
TV and radio interference ................................................................... 2
Safety Precautions ...........................................................................3
Symbols .............................................................................................. 3
Part Names and Functions ..............................................................9
Kebab HS System front view .............................................................. 9
Kebab HS System rear view ............................................................... 9
Usable Works ..................................................................................10
Attaching and Detaching the Kebab HS System .........................11
Kebab HS Compatible printers ......................................................... 11
Attaching the Kebab HS System to a printer .................................... 11
Detaching the Kebab HS System from a printer ............................... 21
Setting Up the Work .......................................................................25
type ................................................................................................... 25
When using the same work as previously ........................................ 32
Setting the Printing Start Position ................................................33
Creating Chucks .............................................................................34
For straight media ............................................................................. 35
For tapered media ............................................................................ 36
els .....................................................................................................37
Modifying the magnetic sheet ........................................................... 37
Measuring UV light leakage after setting up the work ...................... 41
Creating Print Data .........................................................................45
Measuring the print area size ........................................................... 45
Creating print data ............................................................................ 45
Test Printing ....................................................................................46
Enabling Kebab Printing ................................................................47
Printing Data ...................................................................................48
Start printing ..................................................................................... 48
Abort printing .................................................................................... 51
Adjustment ......................................................................................54
Origin adjustment .............................................................................. 54
Head spacing adjustment ................................................................. 55
Error List ..........................................................................................57
Machine Specifications ..................................................................58
D203843-10
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for MIMAKI Kebab HS
Summary of Contents for MIMAKI Kebab HS
-
Page 1: Table Of Contents
Usable Works ..................10 Attaching and Detaching the Kebab HS System ......11 Kebab HS Compatible printers ............11 Attaching the Kebab HS System to a printer ........11 Detaching the Kebab HS System from a printer ....... 21 Setting Up the Work ...............25 Setting up the work for the first time after starting up/Changing the work type .................... -
Page 2: Introduction
Thank you for purchasing the Kebab HS system. The Kebab HS System is a dedicated system for printing images designed by the user on to cylindrical work. Read this manual thoroughly to enable you create images to suit your requirements. -
Page 3: Safety Precautions
Safety Precautions Safety Precautions Symbols In this manual, symbols indicate and explain precautions. The indicated symbol varies depending on the nature of the precaution. Make sure you understand the meaning of each symbol and use the machine safely and correctly. Explanation Failure to observe the instructions given with the [Warning] symbol may result in death or serious injuries to personnel. - Page 4 Safety Precautions Warning • Be sure to provide a ventilation system if using the product in a poorly ventilated or enclosed room. Extractor outlet installation The following precautions must be observed to prevent the machine malfunctioning: (1) The shape of the extractor outlet will depend on the customer’s building configuration, but ensure that the opening area accounts for at least 50 % of the duct.
- Page 5 Failure to observe these instructions may result in fire. Handling anti freezing liquid • Use dedicated Mimaki anti freezing liquid. Failure to observe these instructions may result in failure of the cooling system. • Do not touch the anti freezing liquid with your bare hands.
- Page 6 Safety Precautions Safety Precautions Caution Protect from dust Some components must be replaced periodically • Use in a room as free of dust as possible. In • The machine includes parts specified poor conditions, set the refresh level to 2 or separately that must be replaced periodically.
- Page 7 LED UV units or UV power supply units other significantly impaired. If the glass becomes than those recommended by Mimaki. Mimaki dirty, clean using clean gauze moistened with can accept no liability for any faults resulting alcohol. (Do not wipe the outer cover with from the use of LED UV units or UV power alcohol.
- Page 8 Safety Precautions Warning Labels The following warning labels are affixed to the Kebab HS system. Make sure you fully understand the details indicated on the various warning labels. If a warning label is illegible due to stains or has come off, purchase a new one from a dealer or our service office.
-
Page 9: Part Names And Functions
Kebab HS System front view Main unit cover and test printing area Shields against UV light leakage. This area can also be used for test printing when the Kebab HS System is installed on a table. Main unit cover Power supply unit... -
Page 10: Usable Works
Usable Works Usable Works Kebab HS System Form Cylindrical/tapered media (max. slope angle 7.5°) 280 mm* Length 30 mm 100 mm Diameter 50 mm Maximum printing width Max. 300 mm Maximum work weight Max. 3.0 kg * When using the accessory chuck. -
Page 11: Attaching And Detaching The Kebab Hs System
UJF-7151 plusII • The Kebab HS system and the ionizer (optional) cannot be used together. • The ionizer will be disabled if the Kebab HS system is recognized. (The ionizer does not need to be removed. Attaching the Kebab HS System to a printer •... - Page 12 Attaching and Detaching the Kebab HS System Press , then select [SET OPTION M A C H I N E S E T U P 2 / 3 JIG]. S E T O P T I O N J I G >...
- Page 13 Attaching and Detaching the Kebab HS System Remove the table support shafts. Remove the connector cover. • In the center of the printer for the UJF-3042MkIIe and UJF-6042MkIIe • At the front of the printer for the UJF-7151 plusII Connector cover...
- Page 14 Attaching and Detaching the Kebab HS System Reconnect the cable on the table underside to the printer main unit. Attach the positioning plates. • Use the plastic head screws provided to attach the positioning plates. • UJF-3042MkIIe (For honeycomb panel) (1) Align the protrusions on the positioning plates with the holes in the table.
- Page 15 Attaching and Detaching the Kebab HS System • UJF-3042MkIIe (For metal panel) (1) Align the protrusions on the positioning plates with the holes in the table. (2) Use the plastic head screws provided to tempo- rarily secure the positioning plates.
- Page 16 Attaching and Detaching the Kebab HS System (2) Use the plastic head screws provided to temporarily secure the positioning plates. (3) Fully tighten the plastic head screws while pushing the positioning plates in the direction of the arrows. Front • UJF-7151 plusII (1) Align the protrusions on the positioning plates with the holes in the table.
- Page 17 Attaching and Detaching the Kebab HS System Attaching the Kebab HS System (1) Place the Kebab main unit on the table. • Lifting locations (2) Push the Kebab main unit up flush against the positioning plates. • Push toward the rear right of the table.
- Page 18 Attaching and Detaching the Kebab HS System Magnet (4) Attaching the LED unit. • Attach the PCB box to the magnets on the side of the Kebab main unit. • Attach the UV lamp to the Kebab main unit. Engage the slot on the UV lamp with the screw to temporarily secure it in place.
- Page 19 Attaching and Detaching the Kebab HS System Connect the optional relay cable and D-sub cable to the printer main unit. • Be sure to turn off the main power to the printer main unit before connecting the cables. • Connect the cables securely to ensure that they do not become disconnected while the printer is operating.
- Page 20 • If it is touching, remove the clamps and adjust the cable length. : D-sub cable : Optional relay cable Remove from all clamps 30/6042MkIIe 7151plusII Cable Clamp Turn on the power to the printer. • At startup, the printer automatically detects the Kebab HS System.
-
Page 21: Detaching The Kebab Hs System From A Printer
Attaching and Detaching the Kebab HS System Detaching the Kebab HS System from a printer The procedure for detaching the Kebab HS System is as follows: Press the key in local mode. MENU M E N U 2 / 3... - Page 22 Attaching and Detaching the Kebab HS System • UJF-7151 plusII Optional relay cable D-sub cable Detach the Kebab HS System Do not remove • Remove the plastic head screws on the clamping plates, then remove the Kebab HS System. Plastic head screws...
- Page 23 Attaching and Detaching the Kebab HS System Lift up the table to remove it. • Hold both sides of the table and lift it vertically upward. Attach the support shafts to the table. Attach the connector cover. • UJF-3042MkIIe/UJF-6042MkIIe • UJF-7151 plusII Proceed to step 16 after attaching.
- Page 24 Attaching and Detaching the Kebab HS System Reattach the table. Close the front cover. Turn on the power to the printer.
-
Page 25: Setting Up The Work
Open the front cover, then press the key. ENTER • The table moves, and the Kebab HS unit moves forward. • With the UJF-7151 plusII (without full cover option) the Kebab HS unit moves forward automatically. Press to select the work type. W O R K... - Page 26 Setting Up the Work For [Taper]: • When [Taper] is selected for the work type: Enter the large and small diameter values. W O R K S E T • Large diameter input range: 50.0 to 110.0 mm ( P.10) L a r g e D i a m e t e r : 1 0 0 .
- Page 27 Setting Up the Work Set up the work, then press the key. ENTER (1) Set up a work. (2) Push the slide chuck up against the work. (3) Push the slide chuck to compress the slide spring. • Compressing the spring turns on the work sensor.
- Page 28 Setting Up the Work Adjust the UV lamp height, then Scale press the key. ENTER • When [Cylinder] is selected for the work type, taper angle adjustment is not required (at lowest point). Skip this screen. • When [Taper] is selected for the work type: Lifter (1) Refer to the height displayed on the panel, check the scale, and adjust the height of the lifter upper...
- Page 29 Setting Up the Work Mount the light-blocking plate, then press the key. ENTER • Mount the light-blocking plate on the UV lamp accord- ing to the work printing range. Light-blocking plate Light-blocking plate UV lamp Printing area • The edges of the light-blocking plate are sharp. Be sure to wear gloves to avoid the risk of injury.
- Page 30 Setting Up the Work Adjust the cover height, then press key. ENTER (1) Refer to the height displayed on the panel, and adjust the cover height by turning the handle. • Adjust so that the work is at a height approximately 0 to 2 mm above the magnetic sheet.
- Page 31 Setting Up the Work Turn on the UV lamp, and check to confirm that no UV light leaks from gaps between the work set. • The measurement procedure is as follows: “Measuring UV light leakage after setting up the work” on page 41 •...
-
Page 32: When Using The Same Work As Previously
Setting Up the Work When using the same work as previously Press to select [WORK SET]. W O R K S E T U s e s a m e w o r k ? • The next screen is not displayed if the front cover is closed. W o r k T y p e : C y l i n d e r... -
Page 33: Setting The Printing Start Position
O r i g i n S e t > • The [Kebab OriginSet] menu is displayed only when the Kebab MkII/Kebab HS System is attached. • The table height will vary according to the diameter. Enter the work diameter before selecting the menu. ( P.25) -
Page 34: Creating Chucks
Creating Chucks Creating Chucks The customer must create chucks to match the media being printed on. Ensure that the media is as concentric to the axis of rotation as possible. • The following problems may arise if the media is excessively eccentric to the axis of rotation: •... -
Page 35: For Straight Media
Creating Chucks For straight media ① : Use bore A. ② : Use bore B. ③ : Make the chuck mounting diameter smaller than the printing surface diameter. ④ : Rubber should be attached to the chuck to prevent the media slipping. Printing surface Printing Printing... -
Page 36: For Tapered Media
Creating Chucks For tapered media ① : Use bore C. ② : Use bore D. ③ : Make smaller than the large diameter of the tapered media. ④ : Rubber should be attached to the chuck to prevent the media slipping. ⑤... -
Page 37: Modifying The Uv Light-Blocking Cover And Measuring Light Levels
Modifying the UV Light-Blocking Cover and Measuring Light Levels Modifying the UV Light-Blocking Cover and Measuring Light Levels Modifying the magnetic sheet If the work has a complex shape, there is a possibility of UV light leaking from between gaps. This light leakage can be minimized by modifying the magnetic sheet and using a light-blocking cover to suit the work shape. - Page 38 Modifying the UV Light-Blocking Cover and Measuring Light Levels Move the profile gauges to match the work profile. • Move the profile gauges by hand. Slide the left and right profile gauges uniformly. Lock the profile gauges once the profile has been taken. •...
- Page 39 Modifying the UV Light-Blocking Cover and Measuring Light Levels Use a marker pen to trace the shape of the profile gauges on to the magnetic sheet. Remove the magnetic sheet from the cover, then cut along the traced lines. • Cutting slightly inside the pen lines allows the cutting line to be fine adjusted later. Remove the profile gauges, then Work Cover...
- Page 40 Modifying the UV Light-Blocking Cover and Measuring Light Levels Mount the dog cover, then trim the bottom of the magnetic sheet to suit that position. Dog cover • When mounting the dog cover, push it up against the front of the work until it clicks. Cover the opening in front of the slide cover with the remaining magnetic sheet.
-
Page 41: Measuring Uv Light Leakage After Setting Up The Work
Modifying the UV Light-Blocking Cover and Measuring Light Levels Measuring UV light leakage after setting up the work In the case of work comprising transparent bottles containing shielding material or work with complex shapes, there is a possibility of UV light above the permitted levels leaking from between gaps. The light leakage levels can be measured beforehand using a commercially available light meter. - Page 42 Modifying the UV Light-Blocking Cover and Measuring Light Levels Hold down the [RANGE] button to set the minimum range. • Setting is complete once [uW/cm 00.0] is displayed on the screen. Remove the cover from the UV detector, then press the [PH] button once to select peak hold mode.
- Page 43 Modifying the UV Light-Blocking Cover and Measuring Light Levels Check the measured value. • Once measurement is complete, check the reading on the screen. • If the reading is 1.0 μW/cm or less, printing is possi- ble. If it is 1.1 μW/cm or higher, printing is not rec- ommended.
- Page 44 Modifying the UV Light-Blocking Cover and Measuring Light Levels Precautions when replacing batteries • When using the UVV420 for the first time, use the screwdriver provided to open the battery cover on the rear of the unit, then pull out the insulating sheet on top of the batteries to the right.
-
Page 45: Creating Print Data
Width: Not exceeding 3.14 × top face (larger face) diameter (= top face circumference)* * Using the Illustrator (/CorelDraw) plugin “RasterLinkTools” provided by Mimaki allows images to be modified to achieve a natural appearance on a tapered cylindrical shape when viewed from the front. In such cases, the width should be set to 1/6 of the large diameter circumference. -
Page 46: Test Printing
Test Printing Test Printing Before printing, perform a test print to check that there are no printing defects (blurring or missing dots) such as nozzle clogging. Place the media for test printing Attach using tape over the light-blocking cover. • Attach the media using tape. •... -
Page 47: Enabling Kebab Printing
Enabling Kebab Printing Enabling Kebab Printing In order to use Kebab HS to print on work, the Kebab printing function must be enabled in RasterLink7. Select [Printer Management] in [Environments]. • The Printer Management dialog box is displayed. Click Click the printer to be used, then click [Function Icon]. -
Page 48: Printing Data
Kebab HS. • When using Kebab HS, the Illuminance and Additional UV irradiation settings are disabled in [Job Attribute]-[UV Mode] of RasterLink7.(They can be displayed by selecting a job and clicking Job Attributes [Settings] on the Properties screen.) - Page 49 Printing Data Click the (Kebab Jig Print) icon. Click Select the “Kebab Edit” checkbox. Check • To print on to a tapered shape work, select the Click [Print on taper media] checkbox. [0.00 mm] • The [Execute] menu is displayed. •...
- Page 50 Printing Data Click (Execute). • Select [Immediate Print] or [RIP and Print], Select then click [Start]. Click The data to be printed is sent from the PC. • Printing conditions are displayed. • For details of how to send data, refer to the output software operation manual. [For UJF-3042/6042MkIIe] [For UJF-7151 plusII] Resolution...
-
Page 51: Abort Printing
Printing Data Abort printing To abort printing midway, stop the printing operation and delete the data already received from the machine. Stop sending data from the PC. Press the key while printing is in FUNC3 L O C A L 1 3 : 3 2 progress. - Page 52 Printing Data Select the “Reflect diameter” on the “Scale” screen. Check Print using the procedure from step 8 of “Start printing”. • The surface of the work may be hot immediately after printing. Take care not to touch the work until it has sufficiently cooled.
- Page 53 Printing Data...
-
Page 54: Adjustment
This is adjustment to align the Y position on the work rotation axis with the Y position at the center of the head. Adjustment is required if there are multiple printers and the Kebab HS is attached to different printers. -
Page 55: Head Spacing Adjustment
This is adjustment to eliminate drop position offset caused by head spacing offsets. Adjustment is required if there are multiple printers and the Kebab HS is attached to different printers. Set up the work and set the Kebab origin first before adjusting. - Page 56 Adjustment Enter correction values for each head based H E A D 1 - 3 on the print results. A D J U S T V a l u e : • With cylinder selected: - UJF-3042MkIIe: Head 2-3 to Head 4-3 H E A D 2 - 3 - UJF-6042MkIIe: Head 1-3 to Head 4-3...
-
Page 57: Error List
Error List Error List Display Cause Corrective action • Attach the work in the jig so that it does not ATTENTION 4a9 The work is slipping. Or the work is slip. Work rotation speed touching the cover. • Mount the work so that it is not touching the cover. -
Page 58: Machine Specifications
Machine Specifications Machine Specifications Specifications Item Kebab HS System Compatible printers UJF-3042/6042MkIIe, UJF-7151 plusII Printing resolution Printing modes Dependent on printer used Supported inks Form Cylindrical work/tapered media (max. slope angle 7.5°) Supported Length 30 mm to 280 mm* work... -
Page 59: Mimaki Engineering Co., Ltd
Kebab HS System Operation Manual April 2024 © Mimaki Engineering Co., Ltd. 2182-3 Shigeno-otsu, Tomi-shi, Nagano 389-0512 Japan D203608-10-02042024... - Page 60 © Mimaki Engineering Co., Ltd. 2024...
