Bradley S19-210P Installation

Pedestal-mounted eye/face wash

Download this manual

215-155P Rev. H; ECN 07-526

Page 1 of 5

8/22/07

Installation

S19-210P

Pedestal-Mounted Eye/Face Wash

Table of Contents

Pre-Installation Information . . . . . . . . . . . . . . . . . . .2

Installation Instructions . . . . . . . . . . . . . . . . . . . . . .3

Assembly of Components . . . . . . . . . . . . . . . . . . . .4

Parts List . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .5

P.O. Box 309, Menomonee Falls, WI USA 53052-0309

PHONE 1-800-BRADLEY FAX (262) 251-5817

http://www.bradleycorp.com

Need help?

Do you have a question about the S19-210P and is the answer not in the manual?

Page 1 Parts List ........5 215-155P Rev. H; ECN 07-526 P.O. Box 309, Menomonee Falls, WI USA 53052-0309 © 2007 Bradley Corporation PHONE 1-800-BRADLEY FAX (262) 251-5817 Page 1 of 5 8/22/07 http://www.bradleycorp.com...
Page 2 114-051 For questions regarding the operation or installation of this product, visit www.bradleycorp.com or call 1-800-BRADLEY. Product warranties may also be found under ”Product Information” on our web site at www.bradleycorp.com. 8/22/07 Bradley Corporation • 215-155P Rev. H; ECN 07-526...
Page 3: Installation
1-1/4" IPS drain outlet on the eyewash. 3. Mount the safety sign to the wall using sign-mounting hardware (supplied by installer). 4. Open the water supply lines and test for leaks and adequate water flow. Bradley Corporation • 215-155P Rev. H; ECN 07-526 8/22/07...
Page 4 1/2" IPS 12.4 Supply Inlet 10.3 12.1 10.1 12.2 12.3 1-1/4" IPS Drain Outlet NOTE: Items 4.1–4.12 come preassembled as Item 4. Figure 2 Items 12.1–12.4 come preassembled as Item 12. 8/22/07 Bradley Corporation • 215-155P Rev. H; ECN 07-526...
Page 5: Parts List
Grip Pad (not shown) 169-025 Street Elbow 1/2" Prepack S45-122 includes Items 7, 7.1, 8, 9 Prepack S45-123 includes Items 7.1, 8, 9 Prepack S05-127 includes Items 4.9, 4.10, 4.11, 4.12 Bradley Corporation • 215-155P Rev. H; ECN 07-526 8/22/07...
