Sennheiser UI 760 Instruction Manual

760
UI
The UI 760 is a Universal Amplifier Box offering
superior features:
Dynamic Volume Control
at the same sound level and prevents sudden noises
from coming through to the headset
Sound Clarity System
and enhances the caller's voice
Automatic Power Save function for outstanding
battery lifetime of up to 2 years
Switching between telephone and PC use
Secures compliance with the EU Noise at Work
Directive with a single switch
Integrated Dictaphone interface for economical and
easy call recording
The UI 760 is the ideal headset interface box and even allows for
economical call recording or integration of a PC into the system.
Main features include:
Easy switching option between handset and headset as well as
between phone and PC use
Microphone mute allows the user to privately converse with
others close by
Large volume control dial for adjusting the signal during the
call for optimal comfort
Three position switch and microphone sensitivity adjustment
ensures simple installation
Secures compliance with the Noise at work directive from EU
by simply setting a switch
Compatible with practically any digital or analogue telephone
Contact details
The Multi-Purpose Amplifier
TM
keeps all incoming calls
TM
reduces background noise
Technical data
Connectors........................ modular RJ 9 4/4 and 2.5 mm jack
Battery............................. 1.5 volt (IEC LR 14 C)
Dimensions....................... 32 x 91 x 101 mm
Weight without battery.... 137 grams / 4.9 ounces
Accessories
Included:
1.5 volt C-size battery (IEC LR 14 C)
Telephone connecting cable (RJ 9 4/4)
Modular to Easy Disconnect cable (Headset bottom cable)
Instruction Manual
Hook hanger (hook with self adhesive tape)
Optional:
Headset stand – for easy storage of headset. The 3-in-1
kit consists of headset stand, desk mount, fixation kit
Dictaphone cable 3.5 mm jack to 3.5 mm jack (for voice
recording)
PC interface cable - RJ 9 4/4 to 2 x 3.5 mm jack
PC USB interface cable - modular to USB
.
