Page 1 ECHOMAP ULTRA 2 ™ Owner’s Manual...
Page 2 © 2023 Garmin Ltd. or its subsidiaries All rights reserved. Under the copyright laws, this manual may not be copied, in whole or in part, without the written consent of Garmin. Garmin reserves the right to change or improve its products and to make changes in the content of this manual without obligation to notify any person or organization of such changes or improvements. Go to www.garmin.com...
Page 3: Table Of Contents
Chartplotter........13 Selecting the GPS Source....4 Adjusting the Wind Sensor Orientation......... 14 Customizing the Chartplotter.... 5 Viewing Boat Data on a Garmin Menu Bar..........5 Watch............. 14 Hiding and Showing the Menu Bar..5 Home Screen........... 6 Charts and 3D Chart Views..... 14 Rearranging the Category Items..
Page 4 Mapping a Body of Water Using the Guidance Paths......... 40 Garmin Quickdraw Contours Feature.. 32 Editing a Saved Route....... 40 Adding a Label to a Garmin Quickdraw Finding and Navigating a Saved Contours Map........32 Route..........41 Garmin Quickdraw Community.... 33...
Page 5 Traditional Sonar View......56 Setting a Boundary Alarm....48 Split-Frequency Sonar View....56 Disabling all Boundary Alarms..48 Garmin ClearVü™ Sonar View....57 Deleting a Boundary......48 Garmin SideVü™ Sonar View....58 Deleting All Saved Waypoints, Tracks, SideVü Scanning Technology... 59 Routes, and Boundaries......
Page 6 LiveVü Layer........65 Setting the Garmin FrontVü Depth Alarm..........80 True Motion........66 LiveVü and Garmin FrontVü Garmin FrontVü™ Sonar View... 66 Appearance Settings..... 80 Triple Beam Sonar View....67 LiveVü and Garmin FrontVü Layout LiveScope™ Sonar View......68 Settings.......... 80 Zooming in a Panoptix LiveVü...
Page 7 Editing Information in a Position Autopilot Mode........90 Report..........99 Enabling the Autopilot Controls on a Deleting a Position-Report Call..99 Garmin Watch........90 Viewing Vessel Trails on the Chart 100 Customizing the Autopilot Button Individual Routine Calls...... 100 Actions..........91 Selecting a DSC Channel....
Page 8 Sending a Custom Message....112 Optimus Overlay Symbols....122 inReach SOS Calls....... 112 Optimus Limp Home Mode.... 122 Sending an inReach SOS Call..112 Communicating with the Garmin Tide, Current, and Celestial Response Team During an SOS Information........123 Call........... 113 Cancelling an inReach SOS Call..
Page 9 Saving Messages to a Memory Card. 125 Saving a DAB Station as a Preset........... 132 Clearing all Messages and Warnings 125 Selecting a DAB Preset from a Media Player........ 126 List..........132 Removing DAB Presets....132 Opening the Media Player....126 SiriusXM Satellite Radio.....
Page 10 Backing Up Data to a Computer..146 Restoring Backup Data to a Chartplotter......... 146 Saving System Information to a Memory Card............146 Appendix........147 ActiveCaptain and Garmin Express... 147 Garmin Express App......147 Installing the Garmin Express App on a Computer......... 147 viii Table of Contents...
Page 11: Introduction
The support ® pages will provide answers to frequently asked support questions, and you can download software and chart updates. There is also contact information to Garmin support should you have any questions. Front View Power key...
Page 12: Device Keys
Garmin Marine Network cable port for connection to compatible Panoptix , GCV , and ™ ™ ECHOMAP devices NETWORK NOTE: This device is not compatible with some Garmin Marine Network devices such as GPSMAP ® , GSD , and radar devices. ™ Ground screw NOTICE To prevent corrosion of the metal contacts, cover unused connectors with weather caps.
Page 13: Tips And Shortcuts
3 Select Open. Accessing the Manuals from the Web You can get the latest owner's manual and translations of manuals from the Garmin website. The owner's manual includes instructions for using device features and accessing regulatory information. 1 Go to garmin.com/manuals/echomap_ultra_2.
Page 14: Inserting Memory Cards
If the device loses satellite signals, a flashing question mark appears over the boat position indicator ( ) on the chart. For more information about GPS, go to garmin.com/aboutGPS. For help acquiring satellite signals, see device will not acquire GPS signals, page 151.
Page 15: Customizing The Chartplotter
Customizing the Chartplotter Menu Bar The menu bar along the bottom of the screen provides access to many functions of the chartplotter, the options menu, and the home screen. Engages and disengages the autopilot (when connected to a compatible autopilot system) Allows you to add a toolbar overlay to the current page Mark Creates a waypoint at your location...
Page 16: Home Screen
TIP: To view the available categories tabs, you may need to click and drag a tab to scroll left or right. When multiple displays are installed on the Garmin BlueNet ™...
Page 17: Rearranging The Category Items
Rearranging the Category Items You can customize the screen by rearranging the items in the categories. 1 Select a category to customize, such as Charts 2 Hold the button you want to move, such as Nav. Chart, until the menu appears. 3 Select Rearrange.
Page 18: Automatically Turning Off The System
Automatically Turning Off the System You can set the chartplotter and the whole system to turn off automatically after it has been asleep for the selected length of time. Otherwise, you must press and hold to turn off the system manually. 1 Select >...
Page 19: Deleting A Combination Page
Any use or reliance on the information submitted by users is at your own risk. The ActiveCaptain app provides a connection to your ECHOMAP Ultra 2 chartplotter, maps and charts, and the ActiveCaptain community for a connected boating experience.
Page 20: Activecaptain Roles
You can connect a mobile device to the ECHOMAP Ultra 2 device using the ActiveCaptain app. The app provides a quick and easy way for you to interact with your ECHOMAP Ultra 2 device and complete such tasks as sharing data, registering, updating the device software.
Page 21: Updating Software With The Activecaptain App
The ActiveCaptain app downloads the update to the mobile device. When you reconnect the app to the ECHOMAP Ultra 2 device, the update is transferred to the device. After the transfer is complete, you are prompted to install the update.
Page 22: Wireless Sharing
NOTE: An ECHOMAP Ultra 2 device cannot connect to an ECHOMAP UHD2 5/7 cv set as the host device. You must set up the ECHOMAP Ultra 2 device as the host in this situation.
Page 23: Troubleshooting The Wireless Connection
If you cannot connect two compatible ECHOMAP devices wirelessly, check the following items and try again. • If you are connecting an ECHOMAP Ultra 2 device and a ECHOMAP UHD2 5/7 cv device, you must set up the ECHOMAP Ultra 2 as the network host. A ECHOMAP Ultra 2 device cannot connect to a ECHOMAP UHD2 5/7 cv device set up as the host.
Page 24: Adjusting The Wind Sensor Orientation
6 Select Done. Viewing Boat Data on a Garmin Watch You can connect a compatible Garmin watch to a compatible chartplotter to view data from the chartplotter. 1 Bring the Garmin watch within range (3 m) of the chartplotter. 2 From the watch clock screen, select START > Boat Data > START.
Page 25: Detailed Charts
Activating a Marine Chart Subscription Before you can use the full features of Garmin Navionics+ charts that are preloaded on your device or purchased on a memory card, you must activate your subscription using the ActiveCaptain app.
Page 26: Navigation Chart And Fishing Chart
Navigation Chart and Fishing Chart NOTE: The Fishing chart is available with premium charts, in some areas. The Nav. Chart is optimized for navigation. You can plan a course, view map information, and use the chart as a navigational aid. To open the Nav. Chart, select Charts > Nav. Chart. The Fishing Chart provides a detailed view with more bottom detail and fishing content.
Page 27: Measuring A Distance On The Chart
Measuring a Distance on the Chart 1 From a chart, select a location. 2 Select Measure. A push pin appears on the screen at your present location. The distance and angle from the pin is listed in the corner. TIP: To reset the pin and measure from the current location of the cursor, select Set Reference. Creating a Waypoint on the Chart 1 From a chart, select a location or object.
Page 28: Navigating To A Point On The Chart
Navigating to a Point on the Chart WARNING All route and navigation lines displayed on the chartplotter are only intended to provide general route guidance or to identify proper channels, and are not intended to be precisely followed. Always defer to the navaids and conditions on the water when navigating to avoid groundings or hazards that could result in vessel damage, personal injury, or death.
Page 29: Premium Chart Features
Carefully compare the course to all visual sightings, and avoid any land, shallow water, or other obstacles that may be in your path. NOTE: Not all models support all charts. Optional premium charts, such as Garmin Navionics Vision+ , allow you to get the most out of your chartplotter. ™...
Page 30: Fish Eye 3D Chart View
Fish Eye 3D Chart View Using the depth contour lines of the premium charts, such as Garmin Navionics Vision+, the Fish Eye 3D chart view provides an underwater view of the sea floor or lake bottom. Suspended targets, such as fish, are indicated by red, green, and yellow spheres. Red indicates the largest targets and green indicates the smallest.
Page 31: Animated Tide And Current Indicators
Animated Tide and Current Indicators WARNING Tide and current information is for information purposes only. It is your responsibility to heed all posted water-related guidance, to remain aware of your surroundings, and to use safe judgment in, on, and around the water at all times.
Page 32: Viewing Aerial Photos Of Landmarks
Viewing Aerial Photos of Landmarks Before you can view aerial photos on the Navigation chart, you must turn on the Photo Points setting in the chart setup (Chart Layers, page 27). NOTE: This feature is available with premium charts, in some areas. You can use aerial photographs of landmarks, marinas, and harbors to help orient yourself to your surroundings or to acquaint yourself with a marina or a harbor prior to arrival.
Page 33: Heading And Projected Course Of Activated Ais Targets
NOTE: Vessels being tracked with the Blue Force Tracking feature are indicated with a blue-green color regardless of their status. Heading and Projected Course of Activated AIS Targets When heading and course over ground information are provided by an activated AIS target, the heading of the target appears on a chart as a solid line attached to the AIS target symbol.
Page 34: Showing Ais Vessels On A Chart Or 3D Chart View
Showing AIS Vessels on a Chart or 3D Chart View Before you can use AIS, you must connect the chartplotter to an external AIS device and receive active transponder signals from other vessels. You can configure how other vessels appear on a chart or on a 3D chart view. The display range configured for one chart or one 3D chart view are applied only to that chart or to that 3D chart view.
Page 35: Ais Aids To Navigation
AIS Aids to Navigation An AIS aid to navigation (ATON) is any kind of navigational aid that is transmitted over the AIS radio. ATONs are displayed on the charts and have identifying information, such as position and type. There are three main kinds of AIS ATONs. Real ATONs physically exist and send their identifying and location information from their actual location.
Page 36: Ais Distress Signals
AIS Distress Signals Self-contained AIS distress signal devices transmit emergency position reports when activated. The chartplotter can receive signals from Search and Rescue Transmitters (SART), Emergency Position Indicating Radio Beacons (EPIRB), and other man overboard signals. Distress signal transmissions are different than standard AIS transmissions, so they appear differently on the chartplotter.
Page 37: Chart Menu
(Other Vessels Layer Settings, page 29). Water: Shows and hides depth items (Water Layer Settings, page 29). Quickdraw Contours: Shows and hides Garmin Quickdraw Contours data (Garmin Quickdraw Contours Settings, page 34). Chart Layer Settings From a chart, select > Layers > Chart.
Page 38: Depth Layer Settings
Depth Layer Settings From a chart, select > Layers > Chart > Depth. Depth Shading: Specifies an upper and lower depth to shade between. Shallow Shading: Sets the shades from the shoreline to the specified depth. Spot Depths: Turns on spot soundings and sets a dangerous depth. Spot depths that are equal to or more shallow than the dangerous depth are indicated by red text.
Page 39: User Data Layer Settings
User Data Layer Settings You can show user data, such as waypoints, boundaries, and tracks, on the charts. From a chart, select > Layers > Manage User Data. Waypoints: Shows waypoints on the chart and opens the list of waypoints. Boundaries: Shows boundaries on the chart and opens the list of boundaries.
Page 40: Depth Range Shading
For inland fishing, a maximum of five depth ranges can help reduce map clutter. The depth ranges apply to all charts and all bodies of water. Some Garmin LakeVü and premium supplemental charts have multiple depth range shading by default.
Page 41: Chart Settings
Fish Symbols: Shows suspended targets. Supported Maps To help you have a safe and enjoyable time on the water, Garmin devices only support official maps produced by Garmin or an approved third party producer. You can purchase maps from Garmin. If you purchase maps from a seller other than Garmin, investigate the seller before purchasing.
Page 42: Garmin Quickdraw Contours Mapping
1,500 hours of data onto a 2 GB memory card. When you record data on a memory card in your chartplotter, the new data is added to your existing Garmin Quickdraw Contours map, and is saved on the memory card. When you insert a new memory card, the existing data does not transfer onto the new card.
Page 43: Garmin Quickdraw Community
5 Drag the corners to change the download area. 6 Select Download Area. The next time you connect the ActiveCaptain app to the ECHOMAP Ultra 2 device, the downloaded contours are transferred to the device automatically. Sharing Your Garmin Quickdraw Contours Maps with the Garmin Quickdraw Community Using...
Page 44: Garmin Quickdraw Contours Settings
Survey Coloring: Sets the color of the Garmin Quickdraw Contours display. When this setting is turned on, the colors indicate the quality of the recording. When this setting is turned off, the contour areas use standard map colors.
Page 45: Basic Navigation Questions
For example, the roue segment is red striped when the route crosses under a very low bridge or is in shallow waters. This line is red striped in Garmin Navionics+ and Garmin Navionics Vision+ charts only; it is magenta and gray striped in previous versions of the charts.
Page 46: Destinations
Destinations You can select destinations using various charts and 3D chart views or using the lists. Searching for a Destination by Name You can search for saved waypoints, saved routes, saved tracks, and marine services destinations by name. 1 Select Where To > Services > Search by Name. 2 Enter at least a portion of the name of your destination.
Page 47: Stopping Navigation
Stopping Navigation While navigating, from an applicable chart, select an option: • Select > Stop Navigation. • When navigating with Auto Guidance, select > Navigation Options > Stop Navigation. • Select Waypoints Waypoints are locations you record and store in the device. Waypoints can mark where you are, where you are going, or where you have been.
Page 48: Editing A Saved Waypoint
Editing a Saved Waypoint 1 Select Where To > Waypoints. 2 Select a waypoint. 3 Select Review > Edit. 4 Select an option: • To add a name, select Name, and enter a name. • To change the symbol, select Symbol. •...
Page 49: Browsing For And Navigating To A Saved Waypoint
Browsing for and Navigating to a Saved Waypoint WARNING All route and navigation lines displayed on the chartplotter are only intended to provide general route guidance or to identify proper channels, and are not intended to be precisely followed. Always defer to the navaids and conditions on the water when navigating to avoid groundings or hazards that could result in vessel damage, personal injury, or death.
Page 50: Creating And Navigating A Route From Your Present Location
Creating and Navigating a Route From Your Present Location You can create and immediately navigate a route on the Navigation chart or the Fishing chart. This method does not save the route. 1 From the Navigation chart or Fishing chart, select a destination. 2 Select Route To.
Page 51: Finding And Navigating A Saved Route
Finding and Navigating a Saved Route Before you can browse a list of routes and navigate to one of them, you must create and save at least one route (Creating and Saving a Route, page 40). 1 Select Where To > Routes. 2 Select a route.
Page 52: Initiating A Search Pattern
Initiating a Search Pattern You can initiate a search pattern to search an area. Different patterns are better suited for different search situations. 1 Select Where To > Routes > New > Route Using SAR Pattern. 2 Select a pattern: •...
Page 53: Creating And Saving An Auto Guidance Path
Creating and Saving an Auto Guidance Path 1 Select Where To > Routes > New > Auto Guidance. 2 Select a starting point, and select Next. 3 Select a destination, and select Next. 4 Select an option: • To view a hazard and adjust the path near a hazard, select Hazard Review. •...
Page 54: Auto Guidance Path Configurations
Clearance settings, the section of the Auto Guidance path appears as a solid orange line or a red striped line in Garmin Navionics+ and Garmin Navionics Vision+ charts and appears as a magenta and gray striped line in previous versions. When your boat enters one of those areas, a warning message appears (Route Color Coding, page 35).
Page 55: Adjusting The Distance From Shore
Adjusting the Distance from Shore The Shoreline Distance setting indicates how close to the shore you want the Auto Guidance line to be placed. The Auto Guidance line may move if you change this setting while navigating. The available values for the Shoreline Distance setting are relative, not absolute.
Page 56: Setting The Color Of The Active Track
Setting the Color of the Active Track 1 Select Where To > Tracks > Active Track Options > Track Color. 2 Select a track color. Saving the Active Track The track currently being recorded is called the active track. 1 Select Where To > Tracks > Save Active Track. 2 Select an option: •...
Page 57: Retracing The Active Track
Retracing the Active Track The track currently being recorded is called the active track. 1 Select Where To > Tracks > Follow Active Track. 2 Select an option: • Select the time the active track began. • Select Entire Log. 3 Review the course indicated by the colored line.
Page 58: Creating A Boundary
Creating a Boundary 1 Select Where To > Boundaries > New. 2 Select a boundary shape. 3 Follow the on-screen instructions. Converting a Route to a Boundary 1 Select Where To > Routes. 2 Select a route. 3 Select Review > Edit Route > Save as Boundary. Converting a Track to a Boundary 1 Select Where To >...
Page 59: Sailing Features
Sailing Features Setting the Vessel Type for Sailing Features You must select a sailing vessel type to use the sailing features. 1 Select > My Vessel > Vessel Type. 2 Select Sailboat or Sailing Catamaran. Sail Racing You can use the device to increase the likelihood that your boat will cross the start line of a race exactly when the race begins.
Page 60: Starting The Race Timer
Starting the Race Timer The race timer is added to the Sail Racing combination screen by default. 1 From the Sail Racing combination screen, select Start. 2 When necessary, select Sync to synchronize with the official race timer. Stopping the Race Timer From the Sail Racing combination screen, select Stop.
Page 61: Polar Tables
Importing a Polar Table Manually If you save the polar table file as polar.plr and place it in the Garmin/polars/ folder on the memory card, the chartplotter imports the data automatically after you insert the memory card. If it does not import the data automatically, or if you want to load a different set of data, you can initiate the import manually.
Page 62: Setting The Keel Offset
Setting the Keel Offset You can enter a keel offset to compensate the water depth reading for the transducer installation location. This allows you to view the depth of the water below the keel or the true depth of the water, depending on your needs.
Page 63: Sailboat Autopilot Operation
Sailboat Autopilot Operation WARNING You are responsible for the safe and prudent operation of your vessel. The autopilot is a tool that enhances your capability to operate your boat. It does not relieve you of the responsibility of safely operating your boat. Avoid navigational hazards and never leave the helm unattended CAUTION When engaged, the autopilot controls only the rudder.
Page 64: Engaging Wind Hold
Engaging Wind Hold Before you can engage wind hold, you must connect a NMEA 2000 wind sensor to the autopilot. 1 When the autopilot is in standby mode, select 2 Select an option: • To engage an apparent wind hold, select Engage App. Wind Hold. •...
Page 65: Enabling The Gybe Inhibitor
Enabling the Gybe Inhibitor NOTE: The gybe inhibitor does not prevent you from manually performing a gybe using the helm or step steering. The gybe inhibitor prevents the autopilot from performing a gybe. 1 From the autopilot screen, select > Autopilot Setup > Sailing Setup > Gybe Inhibitor. 2 Select Enabled.
Page 66: Sonar Fishfinder
When properly connected to a compatible transducer, your chartplotter can be used as a fishfinder. For more information about which transducer is best for your needs, go to garmin.com/transducers. Different sonar views can help you view the fish in the area. The sonar views available vary depending on the type of transducer and sonar module connected to the chartplotter.
Page 67: Garmin Clearvü™ Sonar View
NOTE: To receive Garmin ClearVü scanning sonar, you need a compatible transducer. For information about compatible transducers, go to garmin.com/transducers. Garmin ClearVü high-frequency sonar provides a detailed picture of the fishing environment around the boat in a detailed representation of structures the boat is passing over.
Page 68: Garmin Sidevü™ Sonar View
Sonar View ™ NOTE: Not all models provide built-in Garmin SideVü sonar support. If your model does not provide built-in SideVü sonar, you need a compatible sonar module and compatible SideVü transducer. If your model does provide built-in SideVü sonar, you need a compatible SideVü transducer.
Page 69: Sidevü Scanning Technology
SideVü Scanning Technology Instead of a more common conical beam, the SideVü transducer uses a flat beam to scan the water and bottom to the sides of your boat. Measuring Distance on the Sonar Screen You can measure the distance between two points on the SideVü sonar view. 1 From the SideVü...
Page 70: Livevü Down Sonar View
LiveVü Down Sonar View This sonar view shows a two-dimensional view of what is below the boat and can be used to see a bait ball and fish. Panoptix down view history in a scrolling sonar view Boat Range Trails Drop shot rig Bottom Sonar Fishfinder...
Page 71: Livevü Forward Sonar View
LiveVü Forward Sonar View This sonar view shows a two-dimensional view of what is in front of the boat and can be used to see a bait ball and fish. Boat Range Fish Trails Bottom Sonar Fishfinder...
Page 72: Realvü 3D Forward Sonar View
RealVü 3D Forward Sonar View This sonar view shows a three-dimensional view of what is in front of the transducer. This view can be used when you are stationary and you need to see the bottom and the fish approaching the boat. Color legend Boat Ping indicator...
Page 73: Realvü 3D Down Sonar View
RealVü 3D Down Sonar View This sonar view shows a three-dimensional view of what is below the transducer and can be used when you are stationary and want to see what is around your boat. Color legend Boat Sonar beam Range Fish Bottom...
Page 74: Realvü 3D Historical Sonar View
RealVü 3D Historical Sonar View This sonar view provides a three-dimensional view of what is behind your boat as you are moving and shows the entire water column in 3D, from the bottom to the top of the water. This view is used for finding fish. Color legend Boat Range...
Page 75: Livevü Layer
LiveVü Layer You can enable the LiveVü Layer view on the RealVü 3D Historical sonar view only when using a compatible transducer, such as a Panoptix PS70-TH. The LiveVü Layer view adds the LiveVü down view to the RealVü 3D Historical sonar view. To enable the LiveVü...
Page 76: True Motion
The ability to effectively avoid forward collisions with Garmin FrontVü sonar decreases as your speed rises above 8 knots. To see the Garmin FrontVü sonar view, you must install and connect a compatible transducer, such as a PS21 transducer. You may need to update the transducer software.
Page 77: Triple Beam Sonar View
Triple Beam Sonar View The Triple Beam sonar view is available only when using a compatible transducer, such as the Panoptix PS70-TH. This sonar view shows three traditional sonar views on one screen, so you can simultaneously see separate sonar readings from the port side, the starboard side, and the center of the boat. You can add each separate view to combo pages as needed.
Page 78: Livescope™ Sonar View
LiveScope Sonar View ™ This sonar view shows a live view of what is in front of or below the boat and can be used to see fish and structures. Depth information Suspended targets or fish Bottom of the body of water Sonar Fishfinder...
Page 79: Zooming In A Panoptix Livevü Or Livescope Sonar View
Zooming in a Panoptix LiveVü or LiveScope Sonar View You can zoom in on the Panoptix LiveVü and LiveScope 2D sonar views. NOTE: The scrolling history is hidden while the screen is in zoom mode. 1 From a Panoptix LiveVü or LiveScope 2D sonar view, spread two fingers apart to zoom in on the area. An inset window appears and displays a small version of the full-screen image.
Page 80: Flasher View
Flasher View The flasher shows sonar information on a circular depth scale, indicating what is beneath your boat. It is organized as a ring that starts at the top and progresses clockwise. Depth is indicated by the scale inside the ring.
Page 81: Selecting The Transducer Type
When you have more than one transducer providing data for a particular sonar view, you can select the source to use for that sonar view. For example, if you have two transducers providing Garmin ClearVü data, you can select the source to use for the Garmin ClearVü sonar view.
Page 82: Viewing Sonar History
You can control the level of detail and noise shown on the sonar screen either by adjusting the gain for traditional transducers or by adjusting the brightness for Garmin ClearVü transducers. If you want to see the highest intensity signal returns on the screen, you can lower the gain or brightness to remove lower intensity returns and noise.
Page 83: Sonar Setup
NOTE: Not all options and settings apply to all models and transducers. These settings apply to the following types of transducers. • Traditional • Garmin ClearVü • SideVü These settings do not apply to Panoptix transducers. From a sonar view, select >...
Page 84: Setting The Scroll Speed
• To scroll more slowly, select Down. Adjusting the Range You can adjust the range of the depth scale for traditional and Garmin ClearVü sonar views. You can adjust the range of the width scale for the SideVü sonar view.
Page 85: Sonar Noise Rejection Settings
Depth Line: Shows a quick-reference depth line. Edge: Highlights the strongest signal from the bottom to help define the hardness or softness of the signal. View Selection: Sets the direction of the Garmin SideVü sonar view. Fish Symbols: Sets how the sonar interprets suspended targets.
Page 86: Sonar Alarms
Range Sync > On: This setting option is available only when viewing a combo screen using at least two traditional and Garmin ClearVü views in a combo screen. The range is synchronized for all traditional and Garmin ClearVü views in the combo screen.
Page 87: Transducer Installation Settings
From an applicable sonar view, select an option. • From a Traditional sonar view, select > Sonar Setup > Installation. • From a Garmin ClearVü sonar view, select > ClearVü Setup > Installation. • From a Garmin SideVü sonar view, select >...
Page 88: Selecting The Transducer Frequency
Selecting the Transducer Frequency NOTE: You cannot adjust the frequency for all sonar views and transducers. You can select which frequencies appear on the sonar screen. NOTICE Always be aware of local regulations on sonar frequencies. For example, to protect orca whale pods, you might be prohibited from using frequencies between 50 to 80 kHz within ½...
Page 89: Panoptix Sonar Setup
2 Select an option. LiveVü Forward and Garmin FrontVü Sonar Settings From the LiveVü Forward or Garmin FrontVü sonar view, select Gain: Controls the level of detail and noise shown on the sonar screen. If you want to see the highest intensity signal returns on the screen, you can lower the gain to remove lower intensity returns and noise.
Page 90: Setting The Livevü And Garmin Frontvü Transducer Transmit Angle
3 Enter the depth at which the alarm is triggered, and select Done. On the Garmin FrontVü screen, a depth line shows the depth at which the alarm is set. The line is green when you are in a safe depth. The line turns yellow when you are going faster than the forward range gives you time to react (10 seconds).
Page 91: Realvü Appearance Settings
Bow Offset: Sets the distance between the bow and the forward view Panoptix transducer installation location. This allows you to view the forward distance from the bow instead of the transducer location. This applies to Panoptix transducers in the Garmin FrontVü, LiveVü Forward, and RealVü 3D Forward sonar views.
Page 92: Setting The Bow Offset
This allows you to view the forward distance from the bow instead of the transducer installation location. This feature applies to Panoptix transducers in the Garmin FrontVü, LiveVü Forward, and RealVü 3D Forward sonar views.
Page 93: Livescope And Perspective Sonar Settings
LiveScope and Perspective Sonar Settings From the LiveScope or Perspective sonar view, select Gain: Controls the level of detail and noise shown on the sonar screen. If you want to see the highest intensity signal returns on the screen, you can lower the gain to remove lower intensity returns and noise.
Page 94: Livescope And Perspective Appearance Settings
LiveScope and Perspective Appearance Settings From the LiveScope or Perspective sonar view, select > Sonar Setup > Appearance. Color Scheme: Sets the color palette. Color Gain: Adjusts the contrast of colors shown on the screen. You can select a higher color gain value to see minor variances in targets with large color changes. You can select a lower color gain value to see more similar colors in the same situation.
Page 95: Autopilot
The system also allows manual steering and several modes of automatic-steering functions and patterns. When the chartplotter is connected to a compatible Garmin autopilot system, you can engage and control the autopilot from the chartplotter. For information about compatible Garmin autopilot systems, go to garmin.com.
Page 96: Autopilot Screen
Autopilot Screen Actual heading (when in standby mode) Intended heading (when engaged) Actual heading Intended heading (heading the autopilot is steering toward) Step turn to port (to adjust the intended heading by amount shown) Step turn to starboard (to adjust the intended heading by amount shown) Rudder position indicator (available when a rudder sensor is connected) Adjusting the Step Steering Increment 1 From the autopilot screen, select...
Page 97: Enabling The Shadow Drive™ Feature
Enabling the Shadow Drive Feature ™ WARNING If the Shadow Drive feature is disabled, steering the boat manually will not disengage the autopilot system. You must use the helm control or connected chartplotter to disengage the autopilot system. NOTE: The Shadow Drive feature is not available on all autopilot models. If the Shadow Drive feature has been disabled, you must enable it again before you can steer the boat manually to disengage the autopilot system.
Page 98: Adjusting The Heading Using The Helm
Adjusting the Heading Using the Helm NOTE: You must enable the Shadow Drive feature before you can adjust the heading using the helm while the autopilot is engaged . With the autopilot engaged, manually steer the boat using the helm. Shadow Drive and at the top of the heading screen appear in yellow, and you have full steering control using the helm.
Page 99: Following The Williamson Turn Pattern
Following the Williamson Turn Pattern You can use the Williamson turn pattern to steer the boat around with the intent of running alongside the location where the Williamson turn pattern was initiated. The Williamson turn pattern can be used in man overboard situations.
Page 100: Enabling Auto Response
3 To disengage low-speed mode, disengage the autopilot or increase the boat speed above 12 kn. Enabling the Autopilot Controls on a Garmin Watch You can control the Garmin autopilot with a compatible Garmin watch. Go to garmin.com for a list of compatible Garmin watches.
Page 101: Customizing The Autopilot Button Actions
Customizing the Autopilot Button Actions Before you can set the autopilot button actions, you must install and configure a compatible Garmin autopilot. You can select up to three autopilot actions for your Garmin watch to perform. NOTE: Available autopilot actions depend on the autopilot installed.
Page 102: Yamaha Autopilot
Yamaha Autopilot WARNING You can use the autopilot feature only at a station installed next to a helm, throttle, and helm control device. You are responsible for the safe and prudent operation of your vessel. The autopilot is a tool that enhances your capability to operate your boat.
Page 103: Yamaha Autopilot Settings
Yamaha Autopilot Settings From a Yamaha engine screen, select > Autopilot Setting. Pattern Set: Allows you to select an autopilot pattern. Direction: Sets a port or starboard direction for the pattern. Spacing: Sets the spacing for the pattern. Length: Sets the length of the pattern. Amplitude: Sets the angle for the zigzag pattern.
Page 104: Force® Trolling Motor Control
You can connect the Force trolling motor to the chartplotter to view and control the motor using the chartplotter. Connecting to a Trolling Motor You can connect the chartplotter wirelessly to a compatible Garmin Force trolling motor on your boat to control the trolling motor from the chartplotter.
Page 105: Trolling Motor Control Bar
Trolling Motor Control Bar The trolling motor control bar allows you to control a Force trolling motor and see the status of the motor. Select an item to engage it. The button illuminates when selected. Select the item again to disengage it. Trolling motor battery status.
Page 106: Trolling Motor Settings
Trolling Motor Settings From the trolling motor bar, select Calibrate: Calibrates the trolling motor compass (Calibrating the Trolling Motor Compass, page 96) and sets the trolling motor bow offset (Setting the Bow Offset, page 97). Anchor Gain: Sets the response of the trolling motor when in anchor lock mode. If you need the trolling motor to be more responsive and move quicker, increase the value.
Page 107: Setting The Bow Offset
• The chartplotter can track the positions of vessels sending position reports. If you have a Garmin NMEA 2000 VHF radio connected to your chartplotter, these features are also enabled. • The chartplotter allows you to quickly set up and send individual routine call details to your Garmin VHF radio.
Page 108: Viewing The Dsc List
Viewing the DSC List Before you can view the DSC list, the chartplotter must be connected to a VHF radio that supports DSC. From a chart or 3D chart view, select > Layers > Other Vessels > DSC > DSC List. TIP: You can quickly access the DSC list from the messages and warnings menu (Messages and Warnings, page 125).
Page 109: Viewing A Position Report
Viewing a Position Report 1 From a chart or 3D chart view, select > Layers > Other Vessels > DSC > DSC List. TIP: You can quickly access the DSC list from the messages and warnings menu (Messages and Warnings, page 125).
Page 110: Viewing Vessel Trails On The Chart
Individual Routine Calls When you connect the chartplotter to a Garmin VHF radio, you can use the chartplotter interface to set up an individual routine call. When setting up an individual routine call from your chartplotter, you can select the DSC channel on which you want to communicate.
Page 111: Gauges And Graphs
Gauges and Graphs The gauges and graphs provide various information about the engine and environment. To view the information, a compatible transducer or sensor must be connected to the network. Viewing the Gauges 1 Select Vessel. 2 Select a gauge, such as Vessel. 3 Select to view a different gauge page, if applicable.
Page 112: Customizing The Gauges
Customizing the Gauges You can add a gauge page, change the layout of the gauge page, change how the gauges are displayed, and change the data in each gauge. 1 Open a gauge page. 2 Select > Edit Gauge Pages. 3 If necessary, select a gauge view or gauge to edit.
Page 113: Enabling Some Engine Gauge Status Alarms
Enabling Some Engine Gauge Status Alarms 1 From the engine gauges screen, select > Installation > Status Alarms > Custom. 2 Select one or more engine gauge alarms to turn on or off. Yamaha Engine Gauges Select Vessel > YAMAHA to view the Yamaha engine gauges. This screen varies based on the engine network and throttle controller.
Page 114: Engine Condition Icons
Data fields Hold to replace the data. Current time Hold to view trip data. Select to toggle the autopilot bar on and off (Helm Master EX). ® Select to set the joystick button for Set Point functions (Helm Master). Tank level information Hold a tank to view detailed tank level sensor information.
Page 115: Engine Alert Icons
Engine Alert Icons Red icons indicate engine abnormalities. NOTICE Consult your Yamaha dealer if the problem cannot be located and corrected. Low cooling water pressure. Low oil pressure. Stop the engine. Check the engine oil level, and add more oil if necessary. NOTICE Do not continue to run the engine if this indicator is on.
Page 116: Configuring The Tank Level Sensors
Helm Master EX system equipped with an autopilot or joystick. GPS is not available on the Helm Master system. Autopilot Setting: Configures the Yamaha autopilot settings. Available on the Helm Master EX system equipped with an autopilot. For Garmin autopilot information, see (Autopilot, page 85).
Page 117: Mercury Engine Gauges
Mercury Engine Gauges ® NOTE: This feature is available only when connected to the Mercury SmartCraft Connect gateway. The available data varies based on the engine network and may include RPM, engine hours, coolant pressure, oil pressure, and other data. Select Vessel >...
Page 118: Setting The Fuel Alarm
Setting the Fuel Alarm CAUTION The Beeper setting must be turned on to make alarms audible (Sounds and Display Settings, page 135). Failure to set audible alarms could lead to injury or property damage. Before you can set a fuel level alarm, you must connect a compatible fuel flow sensor to the chartplotter. You can set an alarm to sound when the total amount of remaining onboard fuel reaches the level you specify.
Page 119: Configuring The Heading Source Of The Wind Gauge
Configuring the Heading Source of the Wind Gauge You can specify the source of the heading displayed on the wind gauge. Magnetic heading is the heading data received from a heading sensor, and GPS heading is calculated by your chartplotter GPS (course over ground). 1 From the wind gauge, select >...
Page 120: Setting The Graph Range And Time Scales
Setting the Graph Range and Time Scales You can indicate the amount of time and the range of sensor data that appears in the depth, wind, and water temperature graphs. 1 Select a graph in a Combo page, and select 2 Select an option: •...
Page 121: Receiving Messages
Receiving Messages When your inReach device receives a message, a pop-up notification appears briefly on the ECHOMAP Ultra 2 screen. • To review the full message, select View Message. • To dismiss the pop-up notification, select OK or wait for the notification to close automatically.
Page 122: Sending A Quick Message
Some jurisdictions regulate or prohibit the use of satellite communications devices. It is the responsibility of the user to know and follow all applicable laws in the jurisdictions where the device is intended to be used. When a compatible inReach device is paired to the chartplotter, you can contact the Garmin Response center to request help.
Page 123: Communicating With The Garmin Response Team During An Sos Call
NOTE: You can use the default vessel image or use a custom image of your vessel. You should save the custom image to the /Garmin folder on the memory card. You can also adjust the view and placement of the image.
Page 124: Enabling The Power-Pole Anchor Or Charge™ Overlay
Enabling the Power-Pole Anchor or CHARGE Overlay ™ You must enable an overlay on the chartplotter to control the Power-Pole anchor system or a CHARGE power management system on your vessel. 1 From the page to which you will add the overlay, select >...
Page 125: Power-Pole Advanced Boat Control
Starboard side anchor control buttons Power-Pole Advanced Boat Control When the chartplotter is connected to a compatible Garmin trolling motor and a compatible Power-Pole anchor system, you can enable advanced boat control functions that use both the Power-Pole anchors and the trolling motor.
Page 126: Charge Overlay
C-Monster control system. Both of these systems are Power-Pole products and not produced by Garmin. After installing this hardware, you must configure the CHARGE power management system and the C-Monster control system so the chartplotter can access and control the charge functions. See the owner's manual provided with your CHARGE power management system for more information.
Page 127: Adding The Mercury Troll Control Overlay
Adding the Mercury Troll Control Overlay When connected to a compatible Mercury engine, you can set and adjust the target speed using the Mercury Troll overlay on the chartplotter. 1 From the page where you want to add the overlay, select >...
Page 128: Mercury Cruise Control Overlay
Mercury Cruise Control Overlay Select to decrease the target speed Target speed Select to increase the target speed Actual speed Enable Select to engage the cruise control Disable Select to disengage the cruise control Mercury Engine Details WARNING You are responsible for the maintenance of the engines on your vessel. Failure to properly maintain the engines could result in an accident causing property damage, serious personal injury, or death.
Page 129: Mercury Engine Overlay
Mercury Engine Overlay You can use the Mercury Engine Overlay to view engine data (Adding the Mercury Engine Overlay, page 118). NOTE: Due to space constraints on the overlay, some items may not appear if the vessel has multiple engines. Port engine RPM Starboard engine RPM Total available fuel Fuel usage...
Page 130: Mercury Active Trim Overlay
Mercury Active Trim Overlay When enabled, you can manually adjust the trim. When enabled, you can change between Mercury active trim preset profiles. Active trim system status. Enable or Disable Select to turn the active trim system on or off. Skyhook Digital Anchor Control ®...
Page 131: Skyhook Digital Anchor Overlay
Skyhook Digital Anchor Overlay When connected to a compatible Mercury engine, you can use the Skyhook overlay on the chartplotter to control the Skyhook digital anchor functions. TIP: When the Skyhook digital anchor, Drifthook feature, or Bowhook feature is active, you can select Standby on the menu bar to disengage the active digital anchor feature and resume manual control of the boat.
Page 132: Optimus Overlay Bar Overview
Optimus Overlay Bar Overview To use the overlay bar, you must connect your Optimus system to your chartplotter and add the overlay bar to the necessary screens (Activating the Optimus Overlay Bar, page 121). Control mode Optimus control buttons Rudder Standby button You must press a mode button on the overlay bar to engage or disengage the mode.
Page 133: Tide, Current, And Celestial Information
Tide, Current, and Celestial Information Tide and Current Overlays Tide station overlay bar. Current station overlay bar. Name of the selected tide or current station. Select to change to a different tide or current station. Tide or current station graph. Present time, indicated on the tide or current station graph as a white line.
Page 134: Tide Station Information
Tide Station Information WARNING Tide and current information is for information purposes only. It is your responsibility to heed all posted water-related guidance, to remain aware of your surroundings, and to use safe judgment in, on, and around the water at all times. Failure to heed this warning could result in property damage, serious personal injury, or death. You can view information about a tide station for a specific date and time, including the tide height, and when the next high and low tides will occur.
Page 135: Messages And Warnings
Messages and Warnings You can open a menu to view important messages and warnings, and to access other communications such as DSC. Select During an active warning, an indicator ( ) replaces the icon on the menu bar ( ). This color-coded icon conveys the nature of the warning, and if you have more than one message to review, it prioritizes the highest- severity warning.
Page 136: Media Player
As long as you have one of the networked Fusion stereos connected to the NMEA 2000 network or the Garmin Marine Network, the chartplotter should automatically detect the stereos.
Page 137: Selecting The Media Device And Source
Selecting the Media Device and Source You can select the media source connected to the stereo. When you have multiple stereo or media devices connected on a network, you can select the device from which you want to play music. NOTE: You can play media only from sources that are connected to the stereo.
Page 138: Stereo Zones And Groups
Stereo Zones and Groups NOTE: The Zones button appears only for stereos that support multiple speaker zones. NOTE: The Groups option appears only when you have multiple Fusion stereos connected to one another using Fusion PartyBus networking. If a connected stereo is set up to support multiple speaker zones, you can control the audio of the zones individually from the media screen on the chartplotter.
Page 139: Creating A Group
Creating a Group If you have multiple Fusion stereos connected to each other using Fusion PartyBus networking, you can create stereo groups and control the networked stereos and groups using the chartplotter. One stereo must be connected to the chartplotter through the NMEA 2000 network. See the installation instructions and owner's manual provided with your compatible Fusion stereo for full information about how to install and configure a Fusion PartyBus network.
Page 140: Playing Music
Playing Music Browsing for Music You can browse for music in some media sources. 1 From the media screen and an applicable source, select the button with the source name, such as USB. 2 Browse for, and select an item to play. Enabling Alphabetical Search You can enable the alphabetical search feature to find a song or album in a large list.
Page 141: Changing The Radio Station
Changing the Radio Station 1 From the media screen, select an applicable source, such as FM. 2 Select to tune to a station. Changing the Tuning Mode You can change how you select a station for some media types, such as FM or AM radio. NOTE: Not all tuning modes are available for all media sources.
Page 142: Scanning For Dab Stations
Scanning for DAB Stations 1 Select the DAB source. 2 Select Scan to scan for available DAB stations. When scanning is complete, the first available station in the first ensemble found begins playing. NOTE: After the first scan is complete, you can select Scan again to re-scan for DAB stations. When the re-scan is complete, the system starts playing the first station in the ensemble you were listening to when you started the re-scan.
Page 143: Locating A Siriusxm Radio Id
Locating a SiriusXM Radio ID Before you can activate your SiriusXM subscription, you must have the radio ID of your SiriusXM Connect Tuner. You can locate the SiriusXM Radio ID on the back of the SiriusXM Connect Tuner, on the back of its packaging, or by tuning your chartplotter to channel 0.
Page 144: Setting Parental Controls On Siriusxm Radio Channels
Updating the Media Player Software You can update the software on compatible connected stereos and accessories. See the stereo Owner's Manual at support.garmin.com for instructions on updating the software. Configuring a Stereo from the Chartplotter You can configure various features of a compatible connected stereo using the chartplotter.
Page 145: Device Configuration
You can view the software version, the basemap version, all supplemental map information (if applicable), the software version for an optional Garmin radar (if applicable), and the unit ID number. You may need this information to update the system software or to purchase additional map data information.
Page 146: Viewing The Event Log
Viewing the Event Log The event log shows a list of system events. 1 Select > System > System Information > Event Log. 2 If necessary, select an event in the list, and select Review to view more information about the event. Sorting and Filtering Events 1 From the Event Log, select Sort By.
Page 147: Navigation Settings
Clearance settings, the section of the Auto Guidance path appears as a solid orange line or a red striped line in Garmin Navionics+ and Garmin Navionics Vision+ charts and appears as a magenta and gray striped line in previous versions. When your boat enters one of those areas, a warning message appears (Route Color Coding, page 35).
Page 148: Adjusting The Distance From Shore
Adjusting the Distance from Shore The Shoreline Distance setting indicates how close to the shore you want the Auto Guidance line to be placed. The Auto Guidance line may move if you change this setting while navigating. The available values for the Shoreline Distance setting are relative, not absolute.
Page 149: Communications Settings
NMEA 2000 network. Label Devices: Changes the labels for available connected devices. Naming Devices and Sensors on the Network You can name devices and sensors connected to the Garmin Marine Network and the NMEA 2000 network. 1 Select > Communications.
Page 150: Setting The Anchor Drag Alarm
(Setting the Garmin FrontVü Depth Alarm, page 80). This alarm is available only with Panoptix Garmin FrontVü transducers. Water Temp.: Sets an alarm to sound when the transducer reports a temperature that is 2°F (1.1°C) above or below the specified temperature.
Page 151: Setting The Fuel Alarm
Setting the Fuel Alarm CAUTION The Beeper setting must be turned on to make alarms audible (Sounds and Display Settings, page 135). Failure to set audible alarms could lead to injury or property damage. Before you can set a fuel level alarm, you must connect a compatible fuel flow sensor to the chartplotter. You can set an alarm to sound when the total amount of remaining onboard fuel reaches the level you specify.
Page 152: Setting The Keel Offset
Setting the Keel Offset You can enter a keel offset to compensate the water depth reading for the transducer installation location. This allows you to view the depth of the water below the keel or the true depth of the water, depending on your needs.
Page 153: Setting The Water Temperature Offset
4 If the message appears again, stop the boat, and ensure the speed-sensor wheel is not stuck. 5 If the wheel turns freely, check the cable connections. 6 If you continue to get the message, contact Garmin product support. Device Configuration...
Page 154: Other Vessels Settings
• To clear saved data and reset device settings to the factory default values, disconnect the chartplotter from the Garmin Marine Network, and select Delete Data and Reset Settings. This does not affect maps or software updates. Sharing and Managing User Data WARNING This feature allows you to import data from other devices that may have been generated by third parties.
Page 155: Selecting A File Type For Third-Party Waypoints And Routes
2 Select Where To > Manage User Data > Data Transfer > File Type. 3 Select GPX. To transfer data with Garmin devices again, select the ADM file type. Copying User Data from a Memory Card You can transfer user data from a memory card to transfer from other devices. User data includes waypoints, routes, Auto Guidance paths, tracks, and boundaries.
Page 156: Updating Built-In Maps With A Memory Card And Garmin Express
(Inserting Memory Cards, page 4). 2 Open the Garmin Express application. If you do not have the Garmin Express application installed on your computer, you can download it from garmin.com/express. 3 If necessary, register your device (Registering Your Device Using the Garmin Express App, page 148).
Page 157: Appendix
Garmin Express App The Garmin Express desktop app allows you to use your computer and a memory card to download and update Garmin device software and charts and register your devices. We recommend it for larger downloads and updates for faster data transfer and to avoid possible data charges with some mobile devices.
Page 158: Registering Your Device Using The Garmin Express App
The Garmin Express application searches the memory card for the device information. 12 Select Add Device to register the device. When registration is complete, the Garmin Express application searches for additional charts and chart updates for your device. When you add devices to the chartplotter network, repeat these steps to register the new devices using the Garmin Express app.
Page 159: Updating Your Charts Using The Garmin Express App
You can use the ActiveCaptain mobile app to update the device software (Updating Software with the ActiveCaptain App, page 11). You can also use the Garmin Express desktop app to update your chartplotter software (Loading the New Software on a Memory Card Using Garmin Express, page 150).
Page 160: Loading The New Software On A Memory Card Using Garmin Express
Loading the New Software on a Memory Card Using Garmin Express You can copy the software update to a memory card using a computer with the Garmin Express app. As of software version 34.00, this device supports two microSD memory cards up to 1 TB, formatted to exFAT with speed class 10 or higher.
Page 161: Viewing Images On A Memory Card
1 Remove the memory card from the chartplotter, and insert it into a card reader that is attached to a computer. 2 From Windows Explorer, open the Garmin\scrn folder on the memory card. 3 Copy the image file from the card and paste it to any location on the computer.
Page 162: My Device Will Not Turn On Or Keeps Turning Off
To check the voltage, measure the female power and ground sockets of the power cable for DC voltage. If the voltage is less than 12 Vdc, the device will not turn on. • If the device is receiving enough power but does not turn on, contact Garmin product support. My device is not creating waypoints in the correct location You can manually enter a waypoint location to transfer and share data from one device to the next.
Page 163: Specifications
10 cm (3.9 in.) The device withstands incidental exposure to water of up to 1 m for up to 30 min. For more information, go to www.garmin.com/waterrating. As of software version 35.00, this device is compatible with up to 1 TB memory cards formatted to exFAT.
Page 164: Recommended Startup Image Dimensions
120 Series Models Dimensions, device only (W x H x D) 341 x 229 x 98 mm (13 x 9 x 3 in.) Dimensions, in bail mount with sun cover (W x H x D) 352 x 235 x 114 mm (13 x 9 x 4 in.) 262 x 164 mm (10 x 6 in.) Display size (W x H) 309 mm (12 in.) diagonal Weight 2.46 kg (5 lb.
Page 165: Nmea 2000 Pgn Information
NMEA 2000 PGN Information Transmit and Receive Description 059392 ISO acknowledgment 059904 ISO request 060160 ISO transport protocol, data transfer 060416 ISO transport protocol, connection management - RTS group function 060928 ISO address claim 126208 NMEA : Command, request, and acknowledge group function ®...
Page 166 Transmit Description 126464 Transmit and receive PGN list group function 126984 Alert response 127258 Magnetic variance 127502 Switch bank control 129025 Position: Rapid update 129026 COG and SOG: Rapid update 129029 GNSS position data 129283 Cross track error 129284 Navigation data 129285 Navigation route and waypoint info Receive...
Page 167 Description 127504 AC output status 127505 Fluid level 127506 DC detailed status 127507 Charger status 127508 Battery status 127509 Inverter status 128000 Nautical leeway angle 128275 Distance log 128780 Linear actuator control and status 129025 Position, rapid update 129026 COG and SOG, rapid update 129029 GNSS position data 129038...
Page 168: 联系信息
Description 130576 Trim tab status 130578 Vessel speed components 联系信息制造厂商 : 台湾国际航电股份有限公司销售厂商 : 上海佳明航电企业管理有限公司联络地址 : 上海市徐汇区桂平路 391 号 ( 新漕河泾国际商务中心 A 座 37 层 ) 电话 : 021-60737675 客服专线 : 400-819-1899 Appendix...
Page 170 March 2024 GUID-9A17B80C-F7A5-4535-8E7D-E8F0ECD1DCD4 v3...
Page 171 When drilling or cutting, always check what is on the opposite side of the surface to avoid damaging the vessel. Read all installation instructions before proceeding with the installation. If you experience difficulty during the installation, contact Garmin ® Product Support.
Page 172 Mounting Considerations You can flush mount the device in the dashboard or bail mount the device on the dashboard. When selecting a mounting location, observe these considerations. • The mounting location must provide a clear view of the screen and access to the keys on the device. •...
Page 173 Flush Mounting the Device NOTICE Be careful when cutting the hole to flush mount the device. There is only a small amount of clearance between the case and the mounting holes, and cutting the hole too large could compromise the stability of the device after it is mounted.
Page 174 Garmin Marine Network cable port for connection to compatible Panoptix , GCV , and ™ ™ ECHOMAP devices NETWORK NOTE: This device is not compatible with some Garmin Marine Network devices such as GPSMAP , GSD , and radar devices. ® ™ Ground screw NOTICE To prevent corrosion of the metal contacts, cover unused connectors with weather caps.
Page 175 Connecting the Device to a Transducer Go to garmin.com/transducers or contact your local Garmin dealer to determine the appropriate type of transducer for your needs. NOTE: If you use an existing transducer and the transducer cable pin connector does not match the device port, you may be able to use a transducer cable adapter to connect your existing transducer to this device.
Page 176 (Connecting to Power, page 4). If you are unfamiliar with NMEA 2000, you should read the Technical Reference for NMEA 2000 Products at garmin.com/manuals/nmea_2000. The port labeled NMEA 2000 on the cradle is used to connect it to a standard NMEA 2000 network.
Page 177 Item Description ECHOMAP Ultra 2 device GPS antenna or other NMEA 2000 device Ignition or in-line switch NMEA 2000 power cable NMEA 2000 drop cable 12 Vdc power source NMEA 2000 female terminator or backbone extension cable NMEA 2000 T-connector NMEA 2000 male terminator or backbone extension cable Installing Locking Rings on the Cables To help make the cable-routing process easier, some locking rings are packaged separately from the cables.
Page 178 Installing the Device in the Cradle After the cables are connected to the cradle, you can quickly place the device in the cradle. 1 Press the button on the release lever and lift the lever to unlock it. 2 Place the base of the device in the bottom of the cradle. 3 Lift the lever.
Page 179 5 A Compass-safe distance 10 cm (3.9 in.) The device withstands incidental exposure to water of up to 1 m for up to 30 min. For more information, go to www.garmin.com/waterrating. Dependent upon the transducer. Dependent upon the transducer rating and depth. Dependent upon the transducer, water salinity, bottom type, and other water conditions.
Page 180 120 Series Models Dimensions, device only (W x H x D) 341 x 202 x 80 mm (13 x 7 x 3 in.) Dimensions, in bail mount with sun cover (W x H x D) 352 x 235 x 114 mm (13 x 9 x 4 in.) 262 x 164 mm (10 x 6 in.) Display size (W x H) 309 mm (12 in.) diagonal Weight 2.46 kg (5 lb.
Page 181 Transmit Description 126464 Transmit and receive PGN list group function 126984 Alert response 127258 Magnetic variance 127502 Switch bank control 129025 Position: Rapid update 129026 COG and SOG: Rapid update 129029 GNSS position data 129283 Cross track error 129284 Navigation data 129285 Navigation route and waypoint info Receive...
Page 182 Description 127505 Fluid level 127506 DC detailed status 127507 Charger status 127508 Battery status 127509 Inverter status 128000 Nautical leeway angle 128275 Distance log 128780 Linear actuator control and status 129025 Position, rapid update 129026 COG and SOG, rapid update 129029 GNSS position data 129038...
Page 183 Description 130578 Vessel speed components 物質宣言有毒有害物质或元素邻苯二甲酸邻苯二甲部件名称多溴二苯邻苯二甲邻苯二甲铅汞镉六价铬多溴联苯二(2-乙基酸二异丁醚酸丁苄酯酸二丁酯己)酯酯印刷电路板组件屏幕/背光金属零件电缆电缆组件连接器塑料和橡胶零件本表格依据 SJ/T11364 的规定编制。 : 代表此种部件的所有均质材料中所含的该种有害物质均低于 (GB/T26572) 规定的限量产品 : 代表此种部件所用的均质材料中, 至少有一类材料其所含的有害物质高于...
Page 184 電　　話:(02)2642-8999 客服專線:(02)2642-9199 © 2023 Garmin Ltd. or its subsidiaries Garmin and the Garmin logo are trademarks of Garmin Ltd. or its subsidiaries, registered in the USA and other countries. ECHOMAP is a trademark of Garmin Ltd. or its ® ™...
Page 185 2), basic NMEA 2000 network-building instructions (NMEA 2000 Network Planning and Construction, page 4), and a list of NMEA 2000 data that may be used by some Garmin NMEA 2000 certified devices (General NMEA 2000 Data Types, page 12). What is NMEA 2000?
Page 186 NMEA 2000 Components Item Description Garmin Part Number Notes Connects devices to the backbone. You must use T-connectors properly when T-connector 010-11078-00 connecting devices to your NMEA 2000 network (Linear Backbone Construction, page You can use this instead of a T-connector and...
Page 187 Field-installable pictured connector 010-11095-00: female Can be used to shorten any Garmin NMEA 2000 backbone or drop cable NMEA 2000 Glossary Backbone: This is the main communication path of the NMEA 2000 network. The backbone can be as simple as three T-connectors connected side to side with terminators on both ends, or can expand to include many T-connectors separated by backbone cables.
Page 188 NMEA 2000 Network Planning and Construction The backbone is the main communication channel of an NMEA 2000 network to which your NMEA 2000 devices connect. You must connect each NMEA 2000 device to the backbone using a T-connector. You must connect the NMEA 2000 backbone to a power source, and you must install terminators at both ends of the network for proper functionality.
Page 189 Sample NMEA 2000 Network NOTE: This diagram illustrates only the NMEA 2000 data connections to each device or sensor on the network. Some devices or sensors can be powered by the NMEA 2000 network, and others may require a separate power connection.
Page 190 Linear Backbone Construction The backbone is the main communication path of the NMEA 2000 network, so it is extremely important to construct the backbone properly. An improperly constructed backbone may prevent the network from functioning, or you may experience unexpected performance. The backbone consists of a combination of T-connectors and cables, terminated on both ends.
Page 191 Power Connection Considerations NOTICE Connecting the NMEA 2000 network to a power source greater than 12 Vdc may damage devices connected to the network. You must connect the NMEA 2000 network to power through the ignition or other external switch, or it will drain the boat battery when not in use.
Page 192 Voltage drop = resistance × distance × load × 0.1 Resistance: Refers to cable resistance (ohms/m). The Garmin cable resistance value is 0.053. Distance: Refers to the distance from the power connection to the device located furthest away on the network (in meters).
Page 193 Backbone cable Length = 10 m Backbone cable Length = 6 m When the voltage-drop formula is applied to this example, the voltage drop is less than 1.67 Vdc. This NMEA 2000 network will function correctly when powered at the end: Resistance ×...
Page 194 Middle-Powered NMEA 2000 Network Designed Correctly Drop cable Length = 2 m Power cable Length = 2 m Drop cable Length = 4 m Drop cable Length = 6 m Backbone cable Length = 10 m Backbone cable Length = 6 m When the NMEA 2000 network is redesigned with the power source in the center, calculate the voltage drop in both directions.
Page 195 Network Termination You must install terminators at the ends of an NMEA 2000 backbone for it to function correctly. You can install either two standard terminators or one female terminator and an in-line terminator on an NMEA 2000 network. NOTE: You must not install more than two terminators on an NMEA 2000 network. If the NMEA 2000 network is built using correct linear backbone construction, you should install one female terminator and one male terminator on the sides of the final T-connectors on opposite ends of the backbone.
Page 196 • No more than 50 NMEA 2000 devices can be connected to an NMEA 2000 network. Considerations for Existing NMEA 2000 Networks If a boat has an existing NMEA 2000 installation, and you would like to add Garmin NMEA 2000 equipment, you should observe these considerations.
Page 197 NMEA 2000 Engine Data Data Type PGN Data Required Typical Sender Battery voltage 127489: Dynamic engine parameters NMEA 2000 compatible engine Fuel flow rate 127489: Dynamic engine parameters Fuel flow sensor Hours 127489: Dynamic engine parameters NMEA 2000 compatible engine Oil pressure 127489: Dynamic engine parameters NMEA 2000 compatible engine...
Page 198 PGN Data Required Typical Sender 129026: COG and SOG 129029: GNSS position data Course made good 129284: Nav data Garmin chartplotter and GPS antenna 129285: Navigation (route and waypoint) 129283: Cross track error 129026: COG/SOG 129029: GNSS position Distance made good...
Page 199 NMEA 2000 Trip Data Data Type PGN Data Required Typical Sender 129026: COG and SOG Odometer GPS antenna 129029: GNSS position data 129026: COG and SOG Trip odometer GPS antenna 129029: GNSS position data 129026: COG and SOG Average GPS speed GPS antenna 129029: GNSS position data 129026: COG and SOG...
Page 200 NMEA 2000 Weather Data Data Type PGN Data Required Typical Sender 130310 and 130311: Environmental parame ters (old) Barometer Barometric pressure sensor 130314: Actual pressure 130310 and 130311: Environmental parame ters (old) 130312: Temperature (old) Air temperature Air temperature sensor 130316: Temperature, extended range 130311: Environmental parameters Humidity...
Page 201 Data Type PGN Data Required Typical Sender 130306: Wind data 127250: Vessel heading Cardinal wind direction A wind sensor, a water speed sensor, 128259: Water speed (less-accurate and a heading sensor 130306: Wind data 127250: Vessel heading 128259: Water speed A wind sensor, a water speed sensor, Beaufort scale 129026: COG/SOG...
Page 202 Wind VMG (less-accurate 129029: GNSS position Wind sensor and a GPS antenna 130306: Wind data Waypoint VMG 129284: Nav data Garmin chartplotter and a GPS antenna Maximum apparent wind speed 130306: Wind data Wind sensor 128259: Water speed Maximum true wind speed...
Page 203 NMEA 2000 System Data Data Type PGN Data Required Typical Sender 129026: COG/SOG Time of day GPS antenna 129029: GNSS position data 129026 - COG/SOG Date GPS antenna 129029 - GNSS position data © 2008 Garmin Ltd. or its subsidiaries...
Page 205 Declaration of Conformity or collision. Supplement depth data readings with Hereby, Garmin declares that this product is in compliance information from applicable paper charts and visual with the Directive 2014/53/EU. The full text of the EU indicators.
Page 206 Limited Warranty, by anyone who is not an authorized service provider of then Garmin will, at its option: (i) repair the device using Garmin; (v) damage to a product that has been modified new parts or previously used parts that satisfy Garmin's or altered without the written permission of Garmin;...
Page 207 Garmin product (new or a Garmin Recertified replacement), or require you to ship your product to a Garmin Authorized Service facility in the country of original purchase or to a Garmin Authorized service facility in another country...
Page 208 ตั ้ ง กำหนดไว เ ท า นั ้ น อุ ป กรณ ท ี ่ ซ ื ้ อ ในประเทศสหรั ฐ อเมริ ก าหรื อ แคนาดาจะต อ งถู ก ส ง กลั บ ไปที ่ ศ ู น ย บ ริ ก ารของ Garmin ในสหราช...
Page 209 100% scale. NOTICE Garmin is not responsible for any damages or expenses resulting from a miscut mounting surface arising from a failure to follow these instructions.
Page 210 240.5 mm in.) 204 mm (8 ¹/ in.) ECHOMAP Ultra 2 12X Series Flush Mount Template ™ 325.3 mm in.) 217.3 mm in.) 13 mm (¹/ in.) 3.2 mm (¹/ in.) Printed in Taiwan October 2023 190-03083-08_0A...
Page 211 If your transducer cable is not long enough to reach the chartplotter, you can add an extension cable (Garmin part GT36UHD/GT56UHD number 010-11617-42 or 010-11617-32, not included). To avoid signal degradation, do not extend the cable more than 9 m (30 TRANSDUCERS ft.).
Page 212 The transducer must be in clean (non-turbulent) water for optimal performance. • On single-drive boats, the transducer must not be mounted in the path of the propeller. The transducer can cause cavitation that can degrade the performance of the boat and damage the propeller. •...
Page 213 Place the cable-entry cover over the hole and the cable, with the opening pointing downward, and mark the location of the two pilot holes. Before tightening the screws, route the cable inside the mount to a cable exit. The trolling motor mount is designed with multiple cable exits. You should use a cable exit that allows the cable to be on the Remove the cable-entry cover, and, using a 3.2 mm ( in.)
Page 214 Appendix trademarks of Garmin Ltd. or its subsidiaries. These trademarks may not be used without the express permission of Garmin. Specifications All models Dimensions (L x W x H) 218.5 x 51.8 x 27.7 mm (8.61 x 2.04 x 1.09 in.) Operating temperature range From 0°...
Page 215 Introduction Getting optimal performance from your marine transducer depends on its optimal placement on your boat. This document provides assistance when selecting the optimal mounting location for Garmin ® transom-mount, thru-hull, and in-hull transducers. Transducer Types Before you can select the best mounting location for a transducer, you must identify its type.
Page 216 • Not recommended for use with vessels with stepped hulls Thru-Hull Transducers Overview These transducers require installation through a hole in the hull. Garmin thru-hull transducers include the following: • Traditional sonar models • GT-TH models with ClearVü and SideVü sonar •...
Page 217 In-Hull Transducers Overview These transducers attach to the inside floor of the hull. The following list describes in-hull transducers. • Do not require a hole through the hull • Send the signal from within the vessel which reduces signal strength •...
Page 218 Transducer Beam Angle Your transducer sends a sonar signal outward through the water. When the signal hits a fish or an object, the signal bounces back to the transducer . Your transducer works with your chartplotter to interpret the signal and display an image.
Page 219 Transducer Signal Interference Signal interference detracts from your transducer's performance. You can reduce signal interference by mounting the transducer away from common sources of interference. Type of interference Source/Example Electronic devices • Audio equipment Electromagnetic interference (EMI) • Motors • Radar Hull features •...
Page 220 Electromagnetic Signal Interference Electromagnetic interference (EMI) is created by a device and transmitted in the form of an electrical current through a power cord or emitted as an electromagnetic field. Sources can include trolling motors, power cables, bilge pumps, magnetic sources, stereos, radar, and VHF radios. Widely spaced vertical lines on the chartplotter sonar view may indicate acoustic or electromagnetic interference.
Page 221 Placement Considerations for Transom-Mount Transducers You should consider the placement of your transom-mount transducer with regard to the waterline, engines, propeller, and hull. Vessel Waterline and Your Transom-Mount Transducer The vessel's waterline is an important placement consideration for a transom-mount transducer. The vessel's waterline is the level at which the vessel sits in the water.
Page 222 Hull Features and Your Transom-Mount Transducer Hull features that generate turbulence can affect your transducer's performance and cause it to wear prematurely. In general, if you use your transom-mount transducer while operating at higher speeds, you should mount the transducer close to the keel (centerline of the boat). Item Boat Feature Transom...
Page 223 TIP: Garmin transducer accessories can help reduce interference from turbulence. • For vessels with a jack plate, Garmin offers a jack plate mount to enable you to mount the transom-mount transducer on the jack plate (Transducer Jack Plate Mount, page 14).
Page 224 External Thru-Hull Type An external thru-hull type extends beyond the outer surface of the hull. Optimal placement is parallel with the waterline. When mounted on a flatter area of the hull, this type does not require a fairing block When mounted on an area of the hull with a greater deadrise angle (Deadrise Angle, page 4), a fairing block enables you to position the device parallel with the waterline...
Page 225 Propulsion and Your Thru-Hull Transducer Your boat's propulsion system generates turbulence when the boat is moving, and turbulence can affect your thru-hull transducer's performance. These placement recommendations help keep your thru-hull transducer away from turbulence from the propulsion system. In general, optimal placement for your thru-hull transducer is in the bilge near the keel and transom where the water under the hull is smoothest while the boat is moving.
Page 226 Sending the sonar signal through the hull can reduce the transducer's depth capability, so mounting it over the smoothest water helps optimize the transducer's performance. Garmin offers in-hull models that are optimized for higher speeds and greater depths and for hull deadrise angles of 0 to 25 degrees (Deadrise Angle, page 4).
Page 227 If your in-hull transducer is not performing as expected, you may need to refill its tank or chamber using non-toxic RV/marine antifreeze or mineral oil Garmin Transducer Accessories Garmin transducer accessories can provide extra placement options and optimize your transducer's performance. For more information, go to garmin.com/transducers about Garmin accessories.
Page 228 The Garmin stainless steel spray shield is for Garmin transom-mount transducers with compatible stainless steel mounts only. Some Garmin transducers have built-in spray shields.Garmin also offers mounting brackets for compatible transducers that allow adjustment to reduce excessive spray.
Page 229 © 2022 Garmin Ltd. or its subsidiaries Garmin ® and the Garmin logo are trademarks of Garmin Ltd. or its subsidiaries, registered in the USA and other countries. These trademarks may not be used without the express permission of Garmin.

Garmin ECHOMAP ULTRA 2 Owner's Manual

Quick Links

Troubleshooting

Need help?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Garmin ECHOMAP ULTRA 2

Summary of Contents for Garmin ECHOMAP ULTRA 2
