Replacing Pitch Trim Servo (GSA 81) on Citation CJ

Caution: Before starting the software or configuration loading process, certain

items may be required to be recorded first, to prevent loss of

information or settings. See Section 1 for details.

Caution: Make certain that all SD cards are available before starting. These are

usually located in a blue pouch onboard the aircraft.

Caution: Follow all steps in a given section for specific loadings. Failure to do so

will result in probable rework.

Caution: Ensure that power is available through a GPU so that power is not

interrupted during the loading process.

Note:

This document is to supplement, not replace, the Cessna Citation 525

MM, and Garmin G1000 SMM.

Note:

Reference latest revision of the Garmin G1000 SMM 190-00934-00.

Section 1

Section 2

Version 1.0

Garmin G1000 Software Version -02

Table of Contents

Table of Contents

Need help?

Do you have a question about the GSA 81 and is the answer not in the manual?

Page 1 Replacing Pitch Trim Servo (GSA 81) on Citation CJ Garmin G1000 Software Version -02 Caution: Before starting the software or configuration loading process, certain items may be required to be recorded first, to prevent loss of information or settings. See Section 1 for details.
Page 2 Note: Anytime that software or configurations are being loaded, all three displays must be in configuration mode. • GSA 81 (Pitch Trim Servo Actuator) • When the GSA 80 pitch trim servo is replaced, then software and configuration loading is required.
Page 3 19) Acknowledge when ‘Update Config Complete’ is displayed by pressing the ENT key. 20) After the software and configuration files are loaded, turn off the system, and remove the 010-00893-02 software loader card from PFD 1. 21) For testing, complete section 8.2 in the Garmin G1000 SMM. Version 1.0...
Page 4 Section 2 Troubleshooting This section will provide corrective actions for issues seen after the software is loaded. Substitute LRU name for ***. • *** DB Error or *** DB Mismatch o Ensure that the supplemental SD cards are installed in the lower slots of the displays.
