ACTION GRIP
BASKETBALL SYSTEM
MODEL 1084
BEFORE BEGINNING ASSEMBLY:
• Requires at least 420 lb (≈191kg) of cement mix to fi ll a
volume of 3.07 ft (≈0.087 m
3
• Requires, at least, 3 days for concrete to cure, plus
3–4 hours to complete assembly steps. If you're using
a quick-setting concrete, check the bag for required
cure time.
• At least 3 people recommended for setup.
WATCH THE INSTRUCTIONAL VIDEO ON YOUTUBE
Scan the code, or visit go.lifetime.com/1084-fullassembly
YouTube and the YouTube logo are trademarks of Google, LLC.
®
IMPORTANT, RETAIN FOR FUTURE REFERENCE: READ CAREFULLY
TOOLS REQUIRED (NOT INCLUDED)
7/16" (≈11mm), 1/2" (≈13mm), 3/8" (≈10mm)
9/16" (≈14mm), 3/4" (≈19mm)
(x2)
(x1)
#2 Phillips Bit
(x1)
(x1)
QUESTIONS?
CONTACT LIFETIME
Dial 1-800-225-3865
®
).
3
(x1)
(x1)
(x1)
(x1)
Cement Mix
60-lb Bag (x7)
(420 lb (≈191kg))
CUSTOMER SERVICE:
®
Live Chat:
www.lifetime.com/customerservice/home
(Click on the "LIVE CHAT" tab)
ASSEMBLY INSTRUCTIONS
Pour le français, voir la page 2. Para el español, ver la página 3.
(x1)
(x3)
(x1)
Bricks (x4–6)
(x1)
For Customer Service in Mainland Europe
and the United Kingdom,
E-mail: csinternational@lifetime.com
TABLE OF CONTENTS
Icon legend.................................4
Warnings & notices......................5
Initial setup................................6
Pole assembly...........................12
(x1)
Backboard-to-rim assembly........17
Backboard-to-pole assembly......24
Parts identifi er..........................i – iv
Handle assembly.......................28
3/8" Nut Driver
Final assembly..........................35
(x1)
Maintenance.................. ..........42
Registration........................43
Warning sticker.........................44
Warranty................................45
(x1)
Model Number: 1084
Product ID:
