Sennheiser SKM 935 G2 Product Sheet

SKM 935 g
RF Wireless Systems |
General Description
A truly professional stage microphone, the cardioid SKM 935 g hand-held trans-
mitter easily cuts through the mix, offering clarity and projection even with
high ambient sound levels. It can be combined with any of the receivers from the
ew 500 g Series or the EM 550 g. The SKM 935 g features nine frequency banks
with up to 20 directly accessible presets each – ready for immediate use.
Features
Absolutely reliable transmission and extended range due to high RF output power
Pilot tone squelch for eliminating RF interference
Rugged metal housing
Backlit display (lights up when a button is pushed)
User-friendly menu operation
Lock function avoids accidental changing of settings
HDX compander for crystal-clear sound
4-step battery status display, also transmitted to receiver
Mute function
Wide range of accessories adapts the hand-held transmitter to any requirement
Delivery includes: 1 SKM 935 g hand-held transmitter (dynamic, cardioid)
1 MZQ 1 microphone clip
1 protective pouch
2 batteries
Recommended Accessories
CC 2 system case
MZW 1 foam windshield, anthracite
BA 2015 accu pack
L 2015 charging unit
Product Variants
SKM 565 g -A: Frequency range 518–554 MHz
SKM 565 g -B: Frequency range 626–662 MHz
SKM 565 g -C: Frequency range 740–776 MHz
SKM 565 g -D: Frequency range 786–822 MHz
SKM 565 g -E: Frequency range 830–866 MHz
evolution wireless g
Cat. No. 009826
Cat. No. 004839
Cat. No. 009950
Cat. No. 009828
Cat. No. 009777
Cat. No. 009778
Cat. No. 009779
Cat. No. 009780
Cat. No. 009781
Technical Data
RF frequency range ...................................... 518–866 MHz
Transmission frequencies .......................................... 1,440
Presets........................................................................ max. 20
Switching bandwidth............................................... 36 MHz
Peak deviation ......................................................... ± 48 kHz
Compander ....................................................................... HDX
AF frequency response ................................ 40–18,000 Hz
Signal-to-noise ratio....................................... > 115 dB(A)
THD ............................................................................... < 0.9 %
In compliance with.... ETS 300422, ETS 300445, CE , FCC
Power supply.................................................. 2 x 1.5 V (AA)
RF output power ........................................................ 30 mW
Operating time ............................................................ > 8 hrs
Dimensions .................................... d = 50 mm, l = 225 mm
Weight ............................................................................ 450 g
Transducer ................................................................. dynamic
Sensitivity ................................................................. 2 mV/Pa
Max. SPL ....................................................................... 154 dB
Pick-up pattern .......................................................... cardioid
SKM 935 G2
Cat. No. 021636
