Sennheiser SKM 945 Specifications

SKM 945 g
RF Wireless Systems |
General Description
A truly professional stage microphone, the super-cardioid SKM 945 g handheld
transmitter easily cuts through the mix, offering clarity and projection even with
high ambient sound levels. It can be combined with any of the receivers from the
ew 500 g Series or the EM 550 g. The SKM 945 g features nine frequency banks
with up to 20 directly accessible presets each – ready for immediate use.
Features
1440 tunable UHF frequencies for interference-free reception
Absolutely reliable transmission and extended range due to high RF output power
Pilot tone squelch for eliminating RF interference when transmitter
is turned off Pilo
Rugged metal housing
Backlit display (lights up when a button is pushed)
User-friendly menu operation
Lock function avoids accidental changing of settings
HDX compander for crystal-clear sound
4-step battery status display, also transmitted to receiver
Mute function
Wide range of accessories adapts the handheld transmitter to any requirement
Delivery includes: 1 SKM 945 g handheld transmitter (dynamic, super-cardioid)
1 MZQ 1 microphone clip, 1 protective pouch
2 batteries AA size
Product Variants
SKM 945 g-A: Frequency range 518–554 MHz
SKM 945 g-B: Frequency range 626–662 MHz
SKM 945 g-C: Frequency range 740–776 MHz
SKM 945 g-D: Frequency range 786–822 MHz
SKM 945 g-E: Frequency range 830–866 MHz
evolution wireless g
Cat. No. 500256
Cat. No. 500257
Cat. No. 500258
Cat. No. 500259
Cat. No. 500260
Technical Data
RF frequency range ...................................... 518–866 MHz
Transmission frequencies .......................................... 1,440
Presets ........................................................................ max. 20
Switching bandwidth ............................................... 36 MHz
Peak deviation ......................................................... ± 48 kHz
Compander ....................................................................... HDX
AF frequency response ................................ 40–18,000 Hz
Signal-to-noise ratio ....................................... > 115 dB(A)
THD ............................................................................... < 0.9 %
In compliance with .... ETS 300422, ETS 300445, CE , FCC
Power supply .................................................. 2 x 1.5 V (AA)
RF output power ........................................................ 30 mW
Operating time ............................................................ > 8 hrs
Dimensions ........................................... d = 50 mm (1.97˝),
Weight ........................................................ 450 g (15.87 oz)
Transducer ................................................................. dynamic
Sensitivity ............................................................. 1,6 mV/Pa
Max. SPL ....................................................................... 154 dB
Pick-up pattern .............................................. super-cardioid
Recommended Accessories
CC 2 system case
MZW 1 foam windshield, anthracite Cat. No. 004839
BA 2015 accu pack
L 2015 charging unit
KEN 1
Mod. No. 21637
l = 225 mm (8.86˝)
Cat. No. 009826
Cat. No. 009950
Cat. No. 009828
Cat. No. 083322
