Sennheiser SKM 2000 Specification

SKM 2000
Handheld Transmitter

Features

Rugged metal housing
Up to 75 MHz switching bandwidth
20 fixed frequency bands with up to 64 compatible presets
6 banks each with up to 64 tunable channels
Frequency setting in 25 kHz steps
Pilot tone squelch for interference-free operation
External charging contacts for recharging battery BA 2015 in the transmitter
Backlit display on transmitter (keystroke activation)
Auto-lock feature to prevent buttons from accidently being pressed
Audio and RF MUTE feature for muting the transmitter
Transmitters can be configured from the receiver menu
Possible to synchronize with the receiver using infrared interface

Architectural Specifications

The wireless microphone transmitter shall operate in the UHF band with a switching bandwidth of up to 75 MHz. The transmitter
shall utilize pilot tone squelch control to suppress unwanted noise and use technologies such as an optimized PLL synthesizer and
HDX noise reduction for improved sound quality, minimized drop-outs, and best possible signal-to-noise ratio.
The transmitter shall be frequency agile with up to 3000 frequencies programmable in 25 KHz steps, with each of the 20 factory
frequency banks providing up to 64 intermodulation-free frequencies. Additional 6 user frequency banks shall allow for custom-
ized setups in order to avoid RF interference.
The transmitting power shall be selectable between 10mW, 30mW, 50mW, and 100mW.
The transmitter shall be menu-driven with an LC display showing current frequency, frequency bank and channel number, me-
tering of AF level, pilot tone evaluation, equalization settings, input sensitivity, muting function, battery status, and lock status.
Programming of the transmitter shall be done via the menu or infra-red synchronization with the receiver. For safety reasons the
RF signal shall be mutable.
A range of microphone capsules shall be available.
The wireless microphone transmitter specified shall be a Sennheiser SKM2000 Handheld Transmitter.

General Description

It's all in the design. The hand-held transmitter of the 2000
series shows its strength: during use, in its performance,
in its features. Sennheiser's technical know-how is shown
through its switchable transmission power, intuitive menu
navigation, an easy-to-read graphic display and external
charging contacts for charging the optional rechargeable
batteries directly. SKM 2000 is compatible with all ew
capsules, including the MMK 965-1 true condenser capsule,
whose wired version, e 965, has already proven to be a
great success. Colors: Nickel and black

Delivery Includes

SKM 2000 hand-held transmitter
2 AA 1.5 V batteries
Microphone clip
8 color-coded rings
Instruction manual
Supplementary frequency sheet
Supplementary RF power sheet
SKM 2000
