STREET AERO Straight Faded Installation Manual

STEP: 1
Carefully place Side Splitter Fin onto the Side Splitter
(Logo should face outwards)
Secure with Black Screw
Black
Screw
DIAGRAM
Use Diagram chart below for the recommended spacing for pre-drilling the
Screws on STEP: 2
NOTE: Spacing may differ based on your side skirt
Side Splitter Size
1
Black
Screw
x4
Estimated Spacing
8 inches
8.5 inches
9.25 inches
9.8 inches
STEP: 2
Position the jack stand near the back and front of the side skirt
Position the Side Splitter to the side skirt
(Street Aero Logo towards the rear bumper)
(Side Splitter should reach from one end to the other)
NOTE: Remove Mud Guards/Splash Guards if needed
Pre-drill the side skirt and Side Splitter with 3/32" or smaller bit size
Amount of screws needed varies on Side Splitter size
Pre drill holes
approximately spaced apart
STEP: 3
Secure the Side Splitter to the side skirt with provided finishing washer and screw
(Start from the center outwards)
Use extra hardware if needed
Amount of screws needed varies on Side Splitter size
Repeat for the other side
Finishing
Screw
Washer
Start Mounting Here
2
