Summary of Contents for Make Noise PrssPnt

  • Page 2: Table Of Contents

    TABLE OF CONTENTS 1. LIMITED WARRANTY 2. INSTALLATION 3. INTRODUCTION 4. PANEL CONTROLS 5. PLAYING 6. TIPS & TRICKS 7. PATCH IDEAS...

  • Page 3: Limited Warranty

    LIMITED WARRANTY Make Noise warrants this product to be free of defects in materials or construction for a period of one year from the date of purchase (proof of purchase/invoice required). Malfunction resulting from wrong power supply voltages, backwards or reversed eurorack bus board cable connection, abuse of the product, removing knobs, changing faceplates, or any other causes determined by Make Noise to be the fault of the user are not covered by this warranty, and normal service rates will apply.

  • Page 4: Installation

    Eurorack style bus board, minding the polarity so that the RED stripe on the cable is oriented to the NEGATIVE 12 Volt line on both the module and the bus board. On the Make Noise 6U or 3U Busboard, the negative 12 Volt line is indicated by the white stripe.

  • Page 5: Introduction

    Sensitivity and Slew panel controls. The basic function of PrssPnt will be familiar to anyone who has used Pressure Points or 0-CTRL. It could be seen as a single “souped-up” channel of one of these devices. Since it is a single channel, the tuned voltage outputs are not relevant, and instead are replaced with more playable sensitivity controls and alternate pres- sure and gate outputs.

  • Page 6: Panel Controls

    8. Digit Trimmer (located under faceplate): Sets the coarse sensitivity of the touch plate. The ideal setting may vary depending on the system, user, time of year, etc. Please turn the power for PRSSPNT OFF while adjusting the trimmer, and use a light touch to avoid causing any unnecessary damage.

  • Page 7: Playing

    Pressing harder, more of your flesh comes into contact with a sensitive point in the circuit, hence the name PrssPnt. As you press on the touchplate, the Smooth Touch Function will also be generated with a curve and decay/release time affected by the Slew control.

  • Page 8: Tips & Tricks

    TIPS & TRICKS Patch a Gate output to the CV input of X-PAN or other voltage-controlled crossfader to manually switch between two signals - either alternately via the Toggled Gate output, or while touching the PrssPnt via the Momentary Gate output.

  • Page 9: Patch Ideas

    PATCH IDEAS TOGGLE MODES by Sam Turner The PrssPnt’s toggle gate can be used to create a "mode" within your system. LFO Mode Patch negative offset into input of a VCA Patch toggle gate to CV input of the VCA...
