Summary of Contents for Smartbox Grid Pad 13
- Page 1 HeadMouse Nano Mounting Guide...
- Page 2 167 Hillcrest Shopping Center Lower Burrell PA, 15068 Europe REHAVISTA GmbH Konsul-Smidt-Str. 8c 28217 Bremen Germany Grid Pad 13 - Headmouse Nano Mount - Document: Guide - UK ENG - A Device: NANO-KIT13 Language: English Date of issue: March 2024...
- Page 3 HeadMouse Nano Mounting Guide This guide provides the basics for getting started with HeadMouse Nano for Grid Pad. You can find a complete guide on the Smartbox Hub (Large print version available): hub.thinksmartbox.com/topic/headmouse-nano/...
-
Page 4: What Is Included
- HeadMouse Nano (if ordered a bundle) - 50 reflective dots (if ordered a bundle) Getting started The HeadMouse Nano mount is designed to fit your Grid Pad 13 communication aid. The HeadMouse Nano mount bundle comes with the mount pre-assembled. - Page 5 The HeadMouse Nano HeadMouse Nano camera and Mount Red and green LED searching Green found Optical window Camera without mount USB-2.0 Micro...
-
Page 6: Installation
Camera and Mount Front Cover base and back Installation Remove the decorative panel (show highlighted below) from the back of your Grid pad 13. Video tutorial here:... - Page 7 Align the mount pins with the holes on the top of the device. Push to dock. Install two screws to lock the Nano in place (by the grip) Reinstall the decorative panel...
-
Page 8: Device Information
Device information Technical specification Model Number: NANO-KIT13/16 Operating environment Temperature 0 - 35°C Relative humidity 0 - 90% Atmospheric pressure 0kPa to 106kPa Storage and transport environment Temperature: 20°C - 60°C Relative humidity: 5 - 90% Atmospheric pressure: 50kPa to 106kPa Cleaning and decontaminating your device •... - Page 9 Safety Durability choking hazard. Young children and Do not pick up the Grid Pad by the people with cognitive disabilities should HeadMouse Nano. be supervised when using the device. Water and liquids The HeadMouse Nano is not sterile. Do The HeadMouse Nano is not protected not operate with open wounds, or whilst against water ingress.
- Page 10 FCC and CE notice Products bearing the CE marking must accept any interference received, have been tested and are declared by including interference that may cause Origin Instruments Corporation of 854 undesired operation. Greenview Drive, Grand Prairie, Texas 75050, USA to be in conformity with If this product is suspected of causing the following standards or other interference to a radio or television...
-
Page 11: Symbol Explanation
Symbol explanation Symbol Meaning Conformity European symbol to declare conformity with EU legislation Federal communications commission symbol to declare conformity with US legislation Waste electrical and electronic equipment symbol to indicate you should dispose of this equipment in accordance with local regulations UK Conformity Assessed symbol to declare conformity in the UK Support... - Page 12 Grid Pad 13 - Headmouse Nano Mount - Guide - UK ENG - A...
