Smartbox Grid Pad 13 Manual

Hide thumbs Also See for Grid Pad 13:

Advertisement

Table of Contents

Manual & Safety

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Grid Pad 13 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Smartbox Grid Pad 13

Summary of Contents for Smartbox Grid Pad 13

  • Page 1 Manual & Safety...
  • Page 2 167 Hillcrest Shopping Center Lower Burrell PA, 15068 Europe REHAVISTA GmbH Konsul-Smidt-Str. 8c 28217 Bremen Germany Document: Grid Pad 13 - Manual & Safety - UK – B Device: GP13A Language: English Date of issue: February 2024 Copyright © 2024 Smartbox Assistive Technology...
  • Page 3 This guide provides the basics for getting started with your Grid Pad 13. You can find a complete guide to all the features for Grid Pad 13 on the Smartbox Hub. A large print version is also available online. hub.thinksmartbox.com/topic/grid-pad-13...
  • Page 4 Your Grid Pad Front Windows Hello IR receiver Camera with Dual Microphone Screen Power charging LEDs Smart Smart Volume Buttons buttons Smartbox Button Eye gaze (optional)
  • Page 5 IR transmitter USB-C 2.0 (Under magnetic cover) Left Right Switch ports USB-C 4.0 USB-A 3.1 USB-A 3.1 (under Charging port cover) Kensington Nano lock Personal speakers Eye gaze (optional) Stand Stand...
  • Page 6 Back Power button Rear Second screen camera Hello! Shall we go for a transmitter coffee? Mounting plate Speakers Radio control compartment Eye gaze (optional) (Under decorative Stand panel) Eye gaze dock on bottom of Grid Pad USB-C 3.0 Eye gaze unit...
  • Page 7 Read more about the specification of Grid Pad 13 Learn more about the materials used in Grid Pad 13 and its packaging: Visit the Smartbox Hub for a large print version of the Grid Pad 13 manual...

  • Page 8: What's In The Box

    Your Grid Pad may also be supplied with an eye gaze unit Your Grid Pad has many features that can be customised and controlled in Grid. For more resources and guides on how to get started with Grid visit the Smartbox Hub. • Get started with Grid •...
  • Page 9 Power To power on your Grid Pad press the power button on the back of the device. A white light on the front of the device will come on and the system will start up. If the device is in sleep mode it will wake up. Shutting down your Grid Pad Tap the Start menu Select the Power icon...
  • Page 10 When the Grid Pad is charging the charging indicator is illuminated white. Power cable socket Attaching PSU Power to device Power lead to mains supply Hello! Shall we go for a coffee? VA13 PSU_V1 Smartbox Assistive Technology thinksmartbox.com...
  • Page 11 When the battery is full the charging indicator is illuminated green. When your Grid Pad requires charging, the charging indicator will be illuminated orange. Mounting Adjustable stand To use the stand, pull from the bottom and adjust the angle to suit you.
  • Page 12 The front of your Grid Pad has five Smart Buttons that are accessible with eye gaze and touch. Buttons 1, 2 and the Smartbox button can help you control and navigate your Grid Pad device when using Grid, or they can be customised using Grid’s set of powerful commands.

  • Page 13: Connecting Switches

    Connecting switches Your Grid Pad has two switch ports which can be configured Switch ports in Grid. 1 & 2 Switch ports S1 and S2 have an LED indicator above that illuminate when a switch is activated. The Remote Power Button also has two additional switch ports, S3 and S4.

  • Page 14: Second Screen

    Second screen The second screen on the back of the Grid Pad can show your Grid messages and Symoji’s to Hello! Shall we go for a coffee? the people around you. The second screen can be toggled on and off in the Grid settings, and using the Set Second Screen command in your grid sets.

  • Page 15: Technical Specification

    Cleaning, decontaminating and storing Cleaning and decontaminating your device Storing your Grid Pad • Before cleaning shut down your device and unplug the PSU When not in use, your Grid Pad should be stored • Remove any cables that are connected to safely.
  • Page 16 Model number: GP13A • It is used to operate external devices via environmental control (EC) Grid Pad 13 has been tested as a Class 1 medical device. Specifications and standards have been Intended User listed in the Compliance section of this manual.
  • Page 17 Accessories individual is likely to wish to utilise it for the above intended use. These settings may include but are Grid Pad 13 is compatible with a number of not limited to: accessories that can be combined together to •...
  • Page 18 Contact with user BF of applied part Applied part Screen, enclosure The screen and enclosure can reach 43°C. This Choking hazard feels warm, but is safe for contact with the user. If damaged, small parts may detach from your There is no time limit for contact at 43°C, but Grid Pad.

  • Page 19: Safety Warnings

    Before reuse of the device, ensure the cleaning and decontamination procedure has been carried Smartbox will provide information such as circuit out. You may also need to remove any personal diagrams and component lists to maintenance data from the device. For support and advice, personnel when necessary.

  • Page 20: Battery Warnings

    2014/30/EU and LVD Directive 2014/35/EU) RoHS Directive 2011/65/EU WEEE Directives EU / CE Statement 2012/19/EU Hereby, Smartbox Assistive Technology Ltd. declares that this radio equipment complies with Harmonised Standards Directive 2014/53/EU. The frequencies used by EN 60601-1:2006/A1:2013...
  • Page 21 EN 60601-1-2:2015 instructions, may cause harmful interference Medical electrical equipment - Part 1-2: to radio communications. However, there is General requirements for basic safety and no guarantee that interference will not occur essential performance - Collateral Standard: in a particular installation. If this equipment Electromagnetic disturbances - Requirements does cause harmful interference to radio or and tests...
  • Page 22 Industry Canada Class B Emissions Compliance Le présent appareil est conforme aux CNR Statement. This Class B digital apparatus d’Industrie Canada applicables aux appareils complies with Canadian ICES003. radio exempts de licence. L’exploitation est autorisée aux deux conditions suivantes : (1) Under Industry Canada regulations, this radio l’appareil ne doit pas produire de brouillage, transmitter may only operate using an antenna...
  • Page 23 Guidance and manufacturer´s declaration – electromagnetic emission The Grid Pad 13 is intended for use in the electromagnetic environment specified below. The customer or the user of the Grid Pad 13 should assure that it is used in such an environment.
  • Page 24 Guidance and manufacturer’s declaration – electromagnetic immunity The Grid Pad 13 is intended for use in the electromagnetic environment specified below. The customer or the user of the Grid Pad 13 should assure that it is used in such an environment.
  • Page 25 RF communications equipment and the model Grid Pad 13 The Grid Pad 13 is intended for use in an electromagnetic environment in which radiated RF disturbances are controlled. The customer or the user of the Grid Pad 13 can help prevent electromagnetic interference by maintaining a minimum distance between portable and mobile RF communications equipment (transmitters) and the Grid Pad 13 as recommended below, according to the maximum output power of the communications equipment.
  • Page 26 Recommended separation distances between RF wireless communications equipment The device is intended for use in an electromagnetic environment in which radiated RF disturbances are controlled. The customer or the user of the device can help prevent electromagnetic interference by maintaining a minimum distance between RF wireless communications equipment and the device as recommended below, according to the maximum output power of the communications equipment.
  • Page 28 Grid Pad 13 - Manual & Safety - UK ENG - B...

This manual is also suitable for:

Gp13a
