  • Page 1 PCEye Mounting Guide...
  • Page 2 This device is manufactured by Smartbox Assistive Technology Ltd. United Kingdom Smartbox Assistive Technology Ltd Ysobel House, Enigma Commercial Centre Sandys Road Malvern WR14 1JJ United States 167 Hillcrest Shopping Center Lower Burrell PA, 15068 Europe REHAVISTA GmbH Konsul-Smidt-Str. 8c...

  • Page 3: Mounting Guide

    PCEye Mounting Guide This guide provides the basics for getting started with PCEye for Grid Pad. You can find a complete guide on the Smartbox Hub (Large print version available): hub.thinksmartbox.com/knowledgebase/ grid-pad-13-pceye-mounting-guide/...

  • Page 4: What's In The Box

    What’s in the box? Back chassis Front chassis (front view) Front chassis (rear view) Cover plate To be used with: PCEye Eye Gaze camera...
  • Page 5 M2.5x6 M3x6 M2x6 M2x4 Positioning jig (top view) Cable adapter Positioning jig (side view) Also included: foam insulating tape.
  • Page 6 NOTE: Grid Pad 13 will need to have the deskstand changed to the larger one for use with eye gaze. Take the front chassis and, using careful force, push the USB cable through the opening in the back of the chassis.
  • Page 7 Turn the front chassis over and place on a table or flat surface. You may want to place a cloth down to protect the camera. Using the two M3 screws, secure the camera into the front chassis. Place the mounting plate over the rear of the front chassis.
  • Page 8 Pull the USB through the opening and ensure it is clear before securing the plate. At this point, the plate rests on the chassis and is secured (screwed) in place later. There will be a length of cable left and this needs to be tucked securely into the channel in the front chassis so that the front chassis can be mounted to the back chassis.
  • Page 9 You will need the back chassis for this next step. Take the length of the USB cable that is now running from the from chassis and feed the cable through the opening at the top of the enclosure.
  • Page 10 Next, take the cable adapter and place the two halves over the USB cable (the dotted line above shows the gap for the cable). Do not secure yet. The two halves should click together for now but still move freely up and down the cable. Included in the box is a positioning jig.
  • Page 11 Push the cable into the jig and adjust the adapter until it lies against the base of the jig.
  • Page 12 Secure the adapter with the two M2x6 screws and nuts provided. Remove the jig.
  • Page 13 Pull the adapter back into the slot (pulling gently on the cable) on the top of the rear chassis. Secure the adapter with two M2x4 screws.
  • Page 14 The front and back chassis are now connected by the camera USB cable. The next step is to secure the front and back together.
  • Page 15 Align the two parts of the chassis and, using gentle pressure, squeeze the two parts together. Secure with eight M2.5X6 screws. Test the connection and docking. Check the connection. Do not secure at this point.
  • Page 16 Using the foam tape provided, place into the recessed area (where the attachment pins and USB sit) at the top of the eye gaze unit. Use gentle pressure to ensure the tape bonds to the eye gaze unit.
  • Page 17 Connect the eye gaze unit to the communication device and secure with the screws provided. You are ready to go!

  • Page 18: Help And Support

    Help and Support Getting help online Our website has many guides and articles to help you with more specific questions. We also have a short installation video Online chat You can chat with our Support team online using the chat window on our website: thinksmartbox.com.

  • Page 19: Safety And Compliance

    Safety and compliance Model: PCEYE5-KIT13 Intended use: An enclosure for mounting PC Eye 5 on Grid Pad 13 Intended user: For individuals with complex communication and/or access needs. Intended environment: Homes, educational settings, in the community, medical facil- ities. Operating environment Temperature 0 - 35 °C...

  • Page 20: Symbols Explanation

    Symbols explanation Symbol Meaning Conformity European symbol to declare conformity with EU legislation. Federal communications commission symbol to declare conformity with US legislation. Waste electrical and electronic equipment symbol to indicate you should dispose of this equipment in accordance with local regulations. Safety &...

  • Page 21: Troubleshooting

    Your eye gaze camera unit is not a user serviceable device. If your device requires a repair, please contact your local dealer. If a serious incident occurs in relation to the device, please report to Smartbox (repairs@thinksmartbox.com) and the competent authority of your member state. Other safety...
  • Page 22 Please have your serial number ready. The serial number for the device is placed under the stand. SN123456789...
  • Page 24 Grid Pad 13 - PCEye mounting guide - UK ENG - A...
