Summary of Contents for Smartbox Grid Pad
- Page 1 Eye gaze unit installation guide...
- Page 2 This device is manufactured by Smartbox Assistive Technology Ltd. United Kingdom Smartbox Assistive Technology Ltd Ysobel House, Enigma Commercial Centre Sandys Road Malvern WR14 1JJ United States Smartbox Assistive Technology Inc 167 Hillcrest Shopping Center Lower Burrell PA, 15068 Europe REHAVISTA GmbH Konsul-Smidt-Str.
- Page 3 Eye gaze unit installation guide. The Grid Pad Eye gaze unit enables you to access your Grid Pad communication aid using eye gaze. A large print version is also available online. hub.thinksmartbox.com/topic/eye-gaze...
-
Page 4: What Is Included
What is included Your Grid Pad Eye gaze unit includes: • Eye gaze unit (camera and enclosure) • Installation guide (this booklet) • Socket screwdriver Front Back Side... -
Page 5: Getting Started
Getting started The Grid Pad Eye gaze unit is designed to fit to your Grid Pad communication aid and enables you to use eye gaze access. The installation of the camera has three main steps: Removing and replacing your Grid Pad’s... - Page 6 Lift the desk stand to 90 degrees or greater Place the Grid Pad screen down on a flatsurface. It is recommended to use a cloth to protect the screen Unscrew the outer screws on the left and right hand side of the stand using a socket...
- Page 7 Lift the eye gaze stand to 90 degrees Connect the Eye gaze unit to the bottom of your Grid Pad. The pins will help guide the positioning of the unit. Make sure the unit is in the centre of the device and the camera points outwards.
-
Page 8: Mounting And Positioning
Open the installer and follow the instructions on screen Mounting and positioning Once drivers are installed and the device is ready to use, you will need to place your Grid Pad in an optimal position. Positioning In most situations eye gaze cameras have an... - Page 9 You will also be able to see Positioning guide that can help you find the optimal position for your Grid Pad. The first time you use the camera, it is best to calibrate. This will improve the accuracy of the camera and help identify any difficult areas to access.
-
Page 10: Safety And Compliance
LUMIN-I-KIT13/16 Temperature: -20°C - VIDA-KIT13/16 60°C Description Product care The Eye gaze unit is used to control a Grid Pad with For optimal tracking, your eyes. please keep your Eye gaze unit clean. Additional information See your Grid Pad manual... -
Page 11: Symbols Explanation
Symbols explanation Symbol Meaning Conformity European symbol to declare conformity with EU legislation Federal communications commission symbol to declare conformity with US legislation Waste electrical and electronic equipment symbol to indicate you should dispose of this equipment in accordance with local regulations Power button symbol Read the manual symbol Read the manual symbol... - Page 12 The Eye gaze unit has been tested as • Degenerative neuromuscular a Class 1 medical device when used disease (e.g. muscular dystrophy, with the Grid Pad. Specifications and spinal muscular atrophy) standards have been listed in the • (CVA/stroke), dementia, Compliance section of this manual.
- Page 13 VOCA (in this instance a Grid Pad) to Anti-reflection compensation changes the behaviour of the Infrared LED’s in the communicate given the significant camera from a constant illumination to a enhancement to expressive strobing illumination. communication that a VOCA often...
-
Page 14: Troubleshooting
Troubleshooting If camera is not turning on: • Ensure Grid 3 is up to date • Ensure your Eye gaze driver is up to date. Visit here: • Restart your device If eye tracking performance is deteriorating: • Recalibrate • Check the user’s position •... - Page 15 Getting help online Our website has many guides and articles to help you with more specific questions. Online chat You can chat with our Support team online using the chat window on our website: thinksmartbox.com. If we are not available, you can leave a message and we will get back to you as soon as possible.
- Page 16 thinksmartbox.com Eye Gaze - Manual - UK ENG – A...
