Eaton TRIPP-LITE N600P-576A-24 Owner's Manual

Eaton TRIPP-LITE N600P-576A-24 Owner's Manual

High-density fiber patch panel 4u with 24x splice cassettes, 576x lc/apc sm 0.9 mm, 1.5m pigtail
Hide thumbs Also See for TRIPP-LITE N600P-576A-24:

Advertisement

Table of Contents

Owner's Manual
High-Density
Fiber Patch Panel
4U with 24x Splice Cassettes,
576x LC/APC SM 0.9 mm,
1.5M Pigtail
Este manual está disponible en español en la página de Eaton:
Tripplite.Eaton.com/support
Ce manuel est disponible en français sur le site Web de Eaton :
Tripplite.Eaton.com/support
Model:
N600P-576A-24
1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the TRIPP-LITE N600P-576A-24 and is the answer not in the manual?

Questions and answers

Related Manuals for Eaton TRIPP-LITE N600P-576A-24

Summary of Contents for Eaton TRIPP-LITE N600P-576A-24

  • Page 1 Fiber Patch Panel N600P-576A-24 4U with 24x Splice Cassettes, 576x LC/APC SM 0.9 mm, 1.5M Pigtail Este manual está disponible en español en la página de Eaton: Tripplite.Eaton.com/support Ce manuel est disponible en français sur le site Web de Eaton : Tripplite.Eaton.com/support...

  • Page 2: Product Overview

    1. Product Overview 3.8 [96.16] 6.3 [159.48] 18.5 [470.1] 19 [485] 18.4 [467.9] 17.9 [454] [176] INCHES [mm] 2. Package Contents Single M3*4 M4*6 Black Splicing Nylon Spiral Countersunk Countersunk Velcro Protective Cable Wrapping Description Head Screw Head Screw Tube Ties Bands Quantity...

  • Page 3: Installation

    3. Installation 3.1 Installing the Panel 1. Unpack the panel chassis and shelf and place on a flat surface. 2. Install the shelf into back side of the chassis and secure the shelf using the included M4 screws. Description M4*6 Screw Quantity 8 Pcs.
  • Page 4 3. Installation 3. Secure the M3 screw on the bottom middle of the chassis. Description M3*4 Screw Quantity 2 Pcs. 4. Install the panel into the rack.

  • Page 5: Installing Cable

    3. Installation 3.2 Installing Cable 1. Remove the splicing cassette from the panel. Note: When removing the cassette module, there is a bolt that prevents the module from being pulled out. The cable connected with the module should be pulled out first, followed by the bolt.
  • Page 6 3. Installation 2. Remove the top cover of the cassette. Note: 24 pcs. of LC pigtail have been preloaded into the cassette. 3. Splice the desired pigtail with the fiber drop cable in accordance with standard industry splicing practices. After splicing the fiber trunk cable, the fanout of the trunk cable should be attached to the shelf with the included nylon cable ties.
  • Page 7 3. Installation Description Nylon Cable Tie Quantity 10 Pcs. Description Single Splicing Protective Tube Quantity 576 Pcs., 24 Pcs. per module Description Spiral Wrapping Bands Quantity 1 Pc. Description Black Velcro Tie Quantity 1 Roll...
  • Page 8 3. Installation 4. To insert the cassette back into the panel after splicing, first pull out the bolt and align the cassette with the panel with port 1 on the left. Then, push the cassette into the panel.
  • Page 9 3. Installation 5. Once a cassette module has been spliced with a fiber drop cable, patch cords can be installed using the connections on the front of the cassette. To prevent the cable from bending, use the integrated cable loops on the module cover to organize cables.
  • Page 12 Eaton has a policy of continuous improvement. Specifications are subject to change without notice. Photos and illustrations may differ slightly from actual products. Eaton 1000 Eaton Boulevard Cleveland, OH 44122 9347A8 United States Eaton.com © 2023 Eaton Eaton is a registered All Rights Reserved trademark.
