- Page 1 Fiber Splice Dome Closure, Model: Up to 576F Ribbon Fiber with N600D-0576-6 6x 96F Splice Trays Este manual está disponible en español en la página de Eaton: Tripplite.Eaton.com/support Ce manuel est disponible en français sur le site Web de Eaton : Tripplite.Eaton.com/support...
-
Page 2: Cable Installation
1. Preparation Please check the type and accessories of optic fiber closure and fiber cable. • Keep the area dry and clean of all accessories. • Keep the work environment clean (dry and without dust) and even. • Use the specified and standard tools during the peeling and installation. •... - Page 3 2. Cable Installation Cable Jacket Cutter Cable Sheath Cutter Cable Cutter (Optional) (Optional) (Optional) Strip the cable with above tools, maintaining an appropriate length as shown in the diagrams above. Notes: • Make sure not to damage the optical fiber. •...
-
Page 4: Installing A Cable
4. Installing a Cable Run the stripped cable through the components in the order shown in the images and table below, then through the closure: Item No. Name Quantity Base 1 set Double clamp 1 set Double clamp 1 pc. For sealing uncut cable Double hole grommet Ø8-Ø14 1 pc. - Page 5 4. Installing a Cable Fix the cable in place with hoop and tighten in place with the metal clamp. Note: When bare fiber is used, EVA tube should be used for protection. Insulation Tape (1 Roll) EVA Tube (1 Roll) Fix the steel strength member to screw by tightening into place.
- Page 6 5. Closure Assembly Push the cabling through the double block, double clamp and double hole grommets. Note: When this double hole cable entry is not used, a choke plug should be used to seal the double hole grommet. Push Tighten the hex screws to secure the double block, double clamp and double hole grommets to the closure base.
- Page 7 6. Installing Branch Cables There are 4 small ports for the uncut cables in the bottom box. Use a Ø8-Ø14 Single Hole Grommet or Ø14-Ø18 Single Hole Grommet depending on the cable diameter size. M31 Plastic Nut Ø8-Ø14 Single Hole Grommet or Ø14-Ø18 Single Hole Grommet Remove the nuts, seals, hoops, armor tableting and steel core using an M31 wrench.
- Page 8 6. Installing Branch Cables Attach the small port cable to the closure. Secure the cable with hoop, then secure the steel core to the press patch (refer to step 3 in the Uncut Armored Cable Installation section). Press the seal gasket (liner only if necessary) and plastic washer to the small port. Screw the M31 nut with spanner tightly to create a seal.
- Page 9 7. Fiber Splice and Mark It is strongly recommended to install fibers from cable ports to the corresponding splice trays: Record the parameter after splicing and making the cable marking. Fusion Splicer OTDR (Optional) (Optional) Put the splice protect pipe clamp in the bracket and the fiber spiral storage in the splice tray.
- Page 10 8. Box Encapsulation Load the cable seals into the box, put together the box top and base, and seal with the plastic hoop. Test the Seal Test the seal after being filled air in the closure and filled other inertia air according to the user application.
- Page 11 9. Closure Installation The closure assembly can be installed in the following ways: 22.5cm Wall Mount Aerial Mount 550735 Description Pole Mounting Quantity 1 Set Pole Mount (Default Installation Kit)
-
Page 12: Warranty
MERCHANTABILITY AND FITNESS FOR A PARTICULAR PURPOSE. Some states do not permit limitation or exclusion of implied warranties; therefore, the aforesaid limitation(s) or exclusion(s) may not apply to the purchaser. Eaton has a policy of continuous improvement. Specifications are subject to change without notice. Photos and illustrations may differ slightly from actual products.
