Eaton TRIPP-LITE N600H-0096-4 Manual

Eaton TRIPP-LITE N600H-0096-4 Manual

Fiber splice horizontal closure
Hide thumbs Also See for TRIPP-LITE N600H-0096-4:

Advertisement

Quick Links

Download this manual
Fiber Splice Horizontal
Closure
Este manual está disponible en español en la página de Eaton:
Tripplite.Eaton.com/support
Ce manuel est disponible en français sur le site Web de Eaton :
Tripplite.Eaton.com/support
04-062-9347BD-EN.indd 1
04-062-9347BD-EN.indd 1
Model:
N600H-0096-4
1/2/2024 10:08:16 AM
1/2/2024 10:08:16 AM
1

Advertisement

loading
Need help?

Need help?

Do you have a question about the TRIPP-LITE N600H-0096-4 and is the answer not in the manual?

Questions and answers

Related Manuals for Eaton TRIPP-LITE N600H-0096-4

Summary of Contents for Eaton TRIPP-LITE N600H-0096-4

  • Page 1 Fiber Splice Horizontal Model: Closure N600H-0096-4 Este manual está disponible en español en la página de Eaton: Tripplite.Eaton.com/support Ce manuel est disponible en français sur le site Web de Eaton : Tripplite.Eaton.com/support 04-062-9347BD-EN.indd 1 04-062-9347BD-EN.indd 1 1/2/2024 10:08:16 AM 1/2/2024 10:08:16 AM...
  • Page 2 1. Closure Assembly 1.1 Open the Closure Using the included tool, open the buckles of the closure (Figure 1-1). Description M8 Alien Spanner Quantity 1 Pc. Figure 1-1: Open the buckle of the closure 04-062-9347BD-EN.indd 2 04-062-9347BD-EN.indd 2 1/2/2024 10:08:17 AM 1/2/2024 10:08:17 AM...
  • Page 3 1. Closure Assembly 1.2 Install the Uncut Cable Unlock the limiting button to turn over all the splicing trays from the bottom (Figure 1-2). Figure 1-2: Turn over all the trays Remove the cable clamp from the cable entry (Figure 1-3). Figure 1-3: Remove cable clamp 04-062-9347BD-EN.indd 3 04-062-9347BD-EN.indd 3...
  • Page 4 1. Closure Assembly Strip the sheath of the uncut cable for a suitable length ≥4 ft. (1.2 m) (Figure 1-4). Bare fiber protecting sleeve Bare fiber Bare fiber loose tube Cable sheath Figure 1-4: Strip the uncut cable Cut the strength member of the cable from the stripped cable sheath to 2.4 in.
  • Page 5 1. Closure Assembly Wrap the un-vulcanized rubber tape around the cable (Figure 1-6). Description Un-vulcanized Rubber Tape Quantity 1 Pc. Figure 1-6: Wrap un-vulcanized rubber tape Run the cable through the cable entry (Figure 1-7). Note: When bare fiber is used, EVA tube should be used to protect bare fiber. Use insulation tape to wrap the EVA tube and cable.
  • Page 6 1. Closure Assembly Secure the plastic clamp, hoop and strength member (Figure 1-8). Description Ø10-Ø19 Hoop Quantity 4 Pcs. Figure 1-8: Secure the plastic clamp, hoop and strength member 04-062-9347BD-EN.indd 6 04-062-9347BD-EN.indd 6 1/2/2024 10:08:19 AM 1/2/2024 10:08:19 AM...
  • Page 7 1. Closure Assembly Store the slack cable in the bottom of the case (Figure 1-9). Figure 1-9: Store the slack cable Manage cable with the magic band tie (Figure 1-10). Figure 1-10: Manage cable 04-062-9347BD-EN.indd 7 04-062-9347BD-EN.indd 7 1/2/2024 10:08:20 AM 1/2/2024 10:08:20 AM...
  • Page 8 1. Closure Assembly Install the pass-through on the other side (Figure 1-11). Figure 1-11: Install pass-through cable through other cable entry For the unused cable entry, use the choke plug to seal cable entry (Figure 1-12). Description Choke Plug (Ø12.5mm) Quantity 6 Pcs.
  • Page 9 1. Closure Assembly 1.3 Install the Branching Cable Turn over the splice tray and remove the cable clamp from the tray (Figure 1-13). Figure 1-13: Remove cable clamp Strip the branching cable to a suitable length of ≥4 ft. (1.2 m) (Figure 1-14). Bare fiber Bare fiber protective sleeve Figure 1-14: Strip the branching cable...
  • Page 10 1. Closure Assembly 1.4 Splice and Store the Fiber Cut the loose tube with a loose tube stripper. Pull out the loose tube, then clean the bare fiber with cleaning paper (Figure 1-16). Description Clean Paper Quantity 1 Pc. Figure 1-16: Strip the fiber 04-062-9347BD-EN.indd 10 04-062-9347BD-EN.indd 10 1/2/2024 10:08:21 AM...
  • Page 11 1. Closure Assembly Insert the bare fiber into the EVA tube, then secure the EVA tube and fiber in the splice tray with a tie (Figure 1-17). Description Nylon Cable Tie 20 Pcs. (use as Quantity required) Description EVA Tube Quantity 1 Roll Figure 1-17: Secure the EVA tube and fiber...
  • Page 12 1. Closure Assembly Coil the bare fiber in the splicing tray (Figure 1-18). Single Splicing Description Protective Tube Quantity 96 Pcs. Figure 1-18: Coil the bare fiber 04-062-9347BD-EN.indd 12 04-062-9347BD-EN.indd 12 1/2/2024 10:08:21 AM 1/2/2024 10:08:21 AM...
  • Page 13 1. Closure Assembly Close the cover of the splicing tray and tie them up with the bondage belt (Figure 1-19). Figure 1-19: Close the splicing tray cover 04-062-9347BD-EN.indd 13 04-062-9347BD-EN.indd 13 1/2/2024 10:08:21 AM 1/2/2024 10:08:21 AM...
  • Page 14 1. Closure Assembly 1.5 Close the Closure Put the cover on the bottom case. Take note of the direction of the cover. Secure the screws that connect the cover and the bottom case according to the sequence shown in Figure 1-20. Figure 1-20: Secure the closure 04-062-9347BD-EN.indd 14 04-062-9347BD-EN.indd 14...
  • Page 15 2. Closure Installation 2.1 Aerial Installation (Default Installation Configuration) The aerial installation accessory is shown in Figure 2-1. Description Aerial Mounting Hardware Quantity 1 Set Figure 2-1: Aerial installation accessory Fix the aerial clasps into the slots at the edge of the bottom base (Figure 2-2). Figure 2-2: Install the clasps 04-062-9347BD-EN.indd 15 04-062-9347BD-EN.indd 15...
  • Page 16 2. Closure Installation Mount the closure to the wire and fasten the bolts (Figure 2-3). Figure 2-3: Mount the closure to the wire 04-062-9347BD-EN.indd 16 04-062-9347BD-EN.indd 16 1/2/2024 10:08:23 AM 1/2/2024 10:08:23 AM...
  • Page 17 2. Closure Installation 2.2 Wall Installation (Optional) The wall-mounting accessory is shown in Figure 2-4. Figure 2-4: Wall-mounting accessory Drill two holes in the wall using a percussion drill (Figure 2-5). Wall Figure 2-5: Drill holes in the wall 04-062-9347BD-EN.indd 17 04-062-9347BD-EN.indd 17 1/2/2024 10:08:23 AM 1/2/2024 10:08:23 AM...
  • Page 18 2. Closure Installation Position the two holes 14 in. (360 mm) apart (Figure 2-6). Unit: mm Figure 2-6: Position of the holes Hammer the expansion bolt completely into the drilled holes. Rotate the bolt clockwise to make the expansion sleeve wholly expanded, then rotate the nut counterclockwise and remove the spring washer, flat washer and nut (Figure 2-7).
  • Page 19 2. Closure Installation Fix the wall-mounted clasps into the slots at the edge of the bottom base (Figure 2-8). Figure 2-8: Install the clasps Put the closure with the wall-mounted clasps onto the wall (Figure 2-9). Figure 2-9: Put the closure onto wall 04-062-9347BD-EN.indd 19 04-062-9347BD-EN.indd 19 1/2/2024 10:08:24 AM...

  • Page 20: Warranty

    (3) years from the date of initial purchase. Our obligation under this warranty is limited to repairing or replacing (at its sole option) any such defective products. Visit Tripplite.Eaton.com/ support/product-returns before sending any equipment back for repair. This warranty does not apply to equipment which has been damaged by accident, negligence or misapplication or has been altered or modified in any way.
