Instruction Booklet IB157001EN
Fixed capacitor banks (Unipump, Unipak, and Unipak
detuned filter) low voltage (600 V and below), NEMA 1
(indoor) and NEMA 3R (outdoor) enclosed versions
Effective May 2015
Contents
Description
Introduction . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2
Manual organization . . . . . . . . . . . . . . . . . . . . . . 2
Product overview . . . . . . . . . . . . . . . . . . . . . . . . 2
Safety precautions . . . . . . . . . . . . . . . . . . . . . . . 2
Catalog numbering systems . . . . . . . . . . . . . . . 2
Receiving . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
Installation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
Preparation for installation . . . . . . . . . . . . . . . . . 3
Installation locations . . . . . . . . . . . . . . . . . . . . . . 3
Installation procedures . . . . . . . . . . . . . . . . . . . . 3
Post installation evaluation . . . . . . . . . . . . . . . . . 4
Electrical connections . . . . . . . . . . . . . . . . . . . . 7
Startup and commissioning . . . . . . . . . . . . . . . . 7
Operating features . . . . . . . . . . . . . . . . . . . . . . . . . 8
Maintenance . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
Retorque . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
Troubleshooting . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
General specifications . . . . . . . . . . . . . . . . . . . . . 10
Warranty . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
