Introduction; Product Description (Fig. 1 - 2); Scope Of Delivery - Scheppach UG200 Translation Of Original Instruction Manual

1.

Introduction

Manufacturer:
Scheppach GmbH
Günzburger Straße 69
D-89335 Ichenhausen
Dear Customer,
We hope your new product brings you much enjoyment
and success.
Note:
In accordance with the applicable product liability laws,
the manufacturer of this product assumes no liability
for damage to the product or caused by the product
arising from:
• Improper handling
• Non-compliance with the operating manual
• Repairs carried out by third parties, unauthorised
specialists
• Installing and replacing non-original spare parts
• Application other than specified
Note:
Read through the complete text in the operating manu-
al before installing and commissioning the device.
This operating manual should help you to familiarise
yourself with your product and to use it for its intended
purpose.
The operating manual includes important instruc-
tions for the safe, proper and economic operation of
the product, for avoiding danger, for minimising repair
costs and downtimes and for increasing the reliability
and extending the service life of the product.
In addition to the safety instructions in this operating
manual, you must also observe the regulations appli-
cable to the operation of the product in your country.
Keep the operating manual package with the power
tool at all times and store it in a plastic cover to pro-
tect it from dirt and moisture. They must be read and
carefully observed by all operating personnel before
starting the work.
Attention
The electric power tools mounted on the tool stand may
only be used by personnel who have been trained in
the use of the electric power tool and who have been
instructed on the associated hazards. The required
minimum age must be observed.
In addition to the safety instructions in this operating
manual and the separate regulations of your country,
the generally recognised technical rules relating to the
operation of such machines must also be observed.
We accept no liability for accidents or damage that
occur due to a failure to observe this manual and the
safety instructions.

2. Product description (Fig. 1 - 2)

1. Tool stand
2. Workpiece support
3. Star grip screw for support arm height adjustment
4. Transport wheels
5. Frame foot
6. Support arm locking lever
7. Star grip screw for tool stand extension
8. Material support
9. Spring pin locking lever
10. Transport handle
11. Tool stand extension
12. Workpiece stop
13. Spring pin lock unfolded
14. Spring pin lock folded in
15. Small parts compartment
16. Adjustable support arm

3. Scope of delivery

Item
1
2
3
4
7
10
16
A
B
C
D
E
F
G
H
I
J
www.scheppach.com
Quantity Designation
1x
Tool stand
2x Workpiece support
2x Star grip screws
2x Transport wheels
2x Star grip screws
1x Transport handle
2x Adjustable support arm
2x M8 flat head screws
6x M8 washers
2x M8 spring washers
2x Wheel axles
2x M10 washers
4x M8 locknuts
4x M6x60 flat head screws
4x M6 washers
4x M6 spring washers
4x M6 hexagonal nuts
GB | 15
