Sinclair SDV5-17HA Service Manual

Commercial air conditioners
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
INDOOR WALL-MOUNTED UNITS SDV5-17-90HA
C O M M E R C I A L A I R C O N D I T I O N E R S S D V 5

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the SDV5-17HA and is the answer not in the manual?

Questions and answers

Related Manuals for Sinclair SDV5-17HA

Summary of Contents for Sinclair SDV5-17HA

  • Page 1 INDOOR WALL-MOUNTED UNITS SDV5-17-90HA C O M M E R C I A L A I R C O N D I T I O N E R S S D V 5...
  • Page 2 Original instructions IMPORTANT NOTE: Read this manual carefully before installing or operating your new air conditioning unit. Make sure to save this manual for future reference.

  • Page 4: Table Of Contents

    Wall Mounted Specifications ..................4 Dimensions .................... 7 Unit Placement ..................8 Piping Diagram ..................9 Wiring Diagram ..................10 Capacity Tables ..................13 Electrical Characteristics ..............23 Sound Levels ..................24...

  • Page 5: Specifications

    1 Specifications Table 1.1: SDV5-17–28HA specifications SDV5-17HA SDV5-22HA SDV5-28HA Model Power supply 1 phase, 220-240V, 50Hz Capacity Cooling kBtu/h Power input Capacity Heating kBtu/h 10.9 Power input Model ZKFP-20-8-6 ZKFP-20-8-6 ZKFP-20-8-6 Fan motor Type Number of rows Tube pitch × row pitch 21x13.37...
  • Page 6 SDV5-36–56HA Table 1.1:SDV5-36–56HA specifications SDV5-36HA SDV5-45HA SDV5-56HA Model Power supply 1 phase, 220-240V, 50Hz Capacity Cooling kBtu/h 12.3 15.4 19.1 Power input Capacity Heating kBtu/h 13.6 17.1 21.5 Power input Model ZKSP-58-8-1 ZKSP-58-8-1 ZKSP-58-8-1 Fan motor Type Number of rows Tube pitch ×...
  • Page 7 SDV5-71–90HA Table 1.2: SDV5-71–90HA specifications SDV5-71HA SDV5-80HA SDV5-90HA Model Power supply 1 phase, 220-240V, 50Hz Capacity Cooling kBtu/h 24.2 27.3 30.7 Power input Capacity Heating kBtu/h 27.3 30.7 34.1 Power input Model ZKSP-60-8-3 ZKSP-60-8-3 ZKSP-60-8-3 Fan motor Type Number of rows Tube pitch ×...

  • Page 8: Dimensions

    2 Dimensions 2.1 Unit Dimensions Figure2.1: Wall mounted dimensions (unit: mm) SDV5-17–28HA SDV5-36–56HA SDV5-71–90HA...

  • Page 9: Unit Placement

    3 Unit Placement 3.1 Placement Considerations Unit placement should take account of the following considerations:  Units should not be installed in the following locations:  Where exposure to direct radiation from a high-temperature heat source or to interference from a source of electromagnetic radiation may occur.

  • Page 10: Piping Diagram

    4 Piping Diagram Figure 4.1: Wall mounted piping diagram motor flare nut gas side heat exchanger flare nut liquid side Legend Indoor ambient temperature sensor Indoor heat exchanger mid-point temperature sensor Indoor heat exchanger outlet temperature sensor...

  • Page 11: Wiring Diagram

    5 Wiring Diagram Figure5.1: 1.7/2.2/2.8kW Wall mountedwiring diagram...
  • Page 12 Figure5.2: 3.6/4.5/5.6kW Wall mountedwiring diagram...
  • Page 13 Figure5.3: 7.1/8.0/9.0kW Wall mountedwiring diagram  Notes for installers and service engineers Caution  All installation, servicing and maintenance must be carried out by competent and suitably qualified, certified and accreditedprofessionals and in accordance with all applicable legislation.  Units should be grounded in accordance with all applicable legislation. Metal and other conductive components should be insulated in accordance with all applicable legislation.

  • Page 14: Capacity Tables

    6 Capacity Tables 6.1 Cooling Capacity Table Table 6.1: Wall mountedcooling capacity Indoor air temperature (°CWB/DB) Outdoor air Capacity 14/20 16/23 18/26 19/27 20/28 22/30 24/32 temperature (kW) (°CDB) 10.0 12.0 14.0 16.0 18.0 20.0 21.0 23.0 25.0 27.0 29.0 31.0 33.0 35.0...
  • Page 15 Table 6.1: Wall mountedcooling capacity (continued) Indoor air temperature (°C WB/DB) Outdoor air Capacity 14/20 16/23 18/26 19/27 20/28 22/30 24/32 temperature (kW) (°C DB) 10.0 12.0 14.0 16.0 18.0 20.0 21.0 23.0 25.0 27.0 29.0 31.0 33.0 35.0 37.0 39.0 42.0 44.0...
  • Page 16 Table 6.1: Wall mountedcooling capacity (continued) Indoor air temperature (°C WB/DB) Outdoor air Capacity 14/20 16/23 18/26 19/27 20/28 22/30 24/32 temperature (kW) (°C DB) 10.0 12.0 14.0 16.0 18.0 20.0 21.0 23.0 25.0 27.0 29.0 31.0 33.0 35.0 37.0 39.0 42.0 44.0...
  • Page 17 Table 6.1: Wall mountedcooling capacity (continued) Indoor air temperature (°C WB/DB) Outdoor air Capacity 14/20 16/23 18/26 19/27 20/28 22/30 24/32 temperature (kW) (°C DB) 10.0 12.0 14.0 16.0 18.0 20.0 21.0 23.0 25.0 27.0 29.0 31.0 33.0 35.0 37.0 39.0 42.0 44.0...
  • Page 18 Table 6.1: Wall mountedcooling capacity (continued) Indoor air temperature (°C WB/DB) Outdoor air Capacity 14/20 16/23 18/26 19/27 20/28 22/30 24/32 temperature (kW) (°C DB) 10.0 10.6 11.7 12.0 10.6 11.5 14.0 10.6 11.4 16.0 10.6 11.3 18.0 10.6 11.0 20.0 10.6 10.8...
  • Page 19 6.2 Heating Capacity Table Table 6.2: Wall mounted heating capacity Indoor air temperature (°C DB) Outdoor air Capacity temperature(°C) (kW) -19.8 1.23 1.23 1.23 1.23 1.23 1.23 -18.8 1.32 1.32 1.32 1.32 1.32 1.32 -16.7 1.38 1.38 1.38 1.38 1.38 1.38 -14.7 1.43...
  • Page 20 Table 6.2: Wall mountedheating capacity(continued) Indoor air temperature (°C DB) Outdoor air Capacity temperature(°C) (kW) -19.8 1.79 1.79 1.79 1.79 1.79 1.79 -18.8 1.92 1.92 1.92 1.92 1.92 1.92 -16.7 2.02 2.02 2.02 2.02 2.02 2.02 -14.7 2.02 2.02 2.02 2.02 2.02 2.02...
  • Page 21 Table 6.2: Wall mountedheating capacity (continued) Indoor air temperature (°C DB) Outdoor air Capacity temperature(°C) (kW) -19.8 2.80 2.80 2.80 2.80 2.80 2.80 -18.8 3.00 3.00 3.00 3.00 3.00 3.00 -16.7 3.15 3.15 3.15 3.15 3.15 3.15 -14.7 3.25 3.25 3.25 3.25 3.25...
  • Page 22 Table 6.2: Wall mountedheating capacity (continued) Indoor air temperature (°C DB) Outdoor air Capacity temperature(°C) (kW) -19.8 4.48 4.48 4.48 4.48 4.48 4.48 -18.8 4.80 4.80 4.80 4.80 4.80 4.80 -16.7 5.04 5.04 5.04 5.04 5.04 5.04 -14.7 5.20 5.20 5.20 5.20 5.20...
  • Page 23 Table 6.2: Wall mountedheating capacity (continued) Indoor air temperature (°C DB) Outdoor air Capacity temperature(°C) (kW) -19.8 5.60 5.04 5.60 5.60 5.60 5.60 -18.8 6.00 5.40 6.00 6.00 6.00 6.00 -16.7 6.30 6.30 6.30 6.30 6.30 6.30 -14.7 6.50 6.50 6.50 6.50 6.50...

  • Page 24: Electrical Characteristics

    7 Electrical Characteristics Table 7.1: Wall mountedelectrical characteristics Power supply Indoor fan motors Model Rated motor Volts Min. volts Max. volts output (kW) SDV5-17HA 220-240 0.32 0.02 0.25 SDV5-22HA 220-240 0.32 0.02 0.25 SDV5-28HA 220-240 0.32 0.02 0.25 SDV5-36HA 220-240 0.45...

  • Page 25: Sound Levels

    8 Sound Levels 8.1 Overall Table 8.1: Wall mounted sound pressure levels Sound pressure levelsdB(A) Model name SDV5-17HA SDV5-22HA SDV5-28HA SDV5-36HA SDV5-45HA SDV5-56HA SDV5-71HA SDV5-80HA SDV5-90HA Notes: Sound pressure levels are measured in a semi-anechoic chamber. During in-situ operation, sound pressure levels may be higher as a result of ambient noise.
  • Page 26 Figure 8.4: SDV5-45HA octave band levels Figure 8.5: SDV5-56HA octave band levels NC65 NC65 NC60 NC60 NC55 NC55 NC50 NC50 NC45 NC45 NC40 NC40 NC35 NC35 NC30 NC30 NC25 NC25 NC20 NC20 NC15 NC15 1000 2000 4000 8000 1000 2000 4000 8000 Octave band center frequency (Hz) Octave band center frequency (Hz) Figure 8.6: SDV5-71–80HA octave band levels...
  • Page 28 SINCLAIR CORPORATION Ltd. 1-4 Argyll St. London W1F 7LD Great Britain www.sinclair-world.com This product was manufactured in China (Made in China). REPRESENTATIVE SINCLAIR Global Group s.r.o. Purkynova 45 612 00 Brno Czech Republic TECHNICAL SUPPORT SINCLAIR Global Group s.r.o. Purkynova 45...
