  • Page 1 INDOOR HIGH STATIC PRESSURE DUCT UNITS SDV5-xxDHA C O M M E R C I A L A I R C O N D I T I O N E R S S D V 5...

  • Page 2: Important Note

    Original instructions IMPORTANT NOTE: Read this manual carefully before installing or operating your new air conditioning unit. Make sure to save this manual for future reference.
  • Page 3 High Static Pressure Duct 1 Specifications ..................4 2 Dimensions ..................... 8 3 Unit Placement ..................12 4 Piping Diagrams ..................13 5 Wiring Diagrams ..................14 6 Fan Performance ................... 19 7 Capacity Tables ..................24 8 Electrical Characteristics ................ 34 9 Sound Levels ..................

  • Page 4: Specifications

    1 Specifications SDV5-71DHA / SDV5-80DHA / SDV5-90DHA Table 1.1: SDV5-71DHA, SDV5-80DHA, SDV5-90DHA specifications SDV5-71DHA SDV5-80DHA SDV5-90DHA Model name Power supply 1-phase, 220-240V, 50Hz Capacity Cooling kBut/h 24.2 27.3 30.7 Input Capacity Heating kBut/h 27.3 30.7 34.1 Input Model WZDK240-38G WZDK240-38G WZDK750-38G-W Type Fan motor...

  • Page 5: Sdv5-112Dha

    SDV5-112DHA / SDV5-140DHA / SDV5-160DHA Table 1.2: SDV5-112DHA, SDV5-140DHA, SDV5-160DHA specifications SDV5-112DHA SDV5-140DHA SDV5-160DHA Model name Power supply 1-phase, 220-240V, 50Hz 11.2 Capacity Cooling kBut/h 38.2 47.8 54.6 Input 12.5 Capacity Heating kBut/h 42.7 54.6 Input Model WZDK750-38G-W WZDK750-38GS-W WZDK750-38GS-W Type Brand Panasonic/ Welling...
  • Page 6 SDV5-200DHA / SDV5-250DHA / SDV5-280DHA Table 1.3: SDV5-200DHA, SDV5-250DHA, SDV5-280DHA specifications SDV5-200DHA SDV5-250DHA SDV5-280DHA Model name Power supply 1-phase, 220-240V, 50Hz Capacity Cooling kBut/h 68.2 85.3 95.5 Input 1200 1200 22.5 31.5 Capacity Heating kBut/h 76.8 88.7 107.5 Input 1200 1200 Model ZKSN-920-8-12...
  • Page 7 SDV5-400DHA / SDV5-450DHA / SDV5-560DHA Table 1.4: SDV5-400DHA, SDV5-450DHA, SDV5-560DHA specifications SDV5-400DHA SDV5-450DHA SDV5-560DHA Model name 1-phase, 220-240V, 50Hz Power supply Capacity 136.5 153.6 Cooling kBut/h 191.1 1800 1800 Input 2272 Capacity 153.6 191.1 Heating kBut/h 215.0 1800 1800 Input 2272 ZKSN-920-8-12-1 Model...

  • Page 8: Unit Dimensions

    2 Dimensions 2.1 Unit Dimensions SDV5-71DHA / SDV5-80DHA / SDV5-90DHA / SDV5-112DHA Figure 2.1: SDV5-71DHA, SDV5-80DHA, SDV5-90DHA, SDV5-112DHA dimensions (unit: mm) 201906...
  • Page 9 SDV5-140DHA / SDV5-160DHA Figure 2.2: SDV5-140DHA, SDV5-160DHA dimensions (unit: mm) 201906...
  • Page 10 SDV5-200DHA / SDV5-250DHA / SDV5-280DHA Figure 2.3: SDV5-200DHA, SDV5-250DHA, SDV5-280DHA dimensions (unit: mm) 201906...
  • Page 11 SDV5-400DHA / SDV5-450DHA / SDV5-560DHA Figure 2.4: SDV5-400DHA, SDV5-450DHA, SDV5-560DHA dimensions (unit: mm) R epair hole 201906...

  • Page 12: Unit Placement

    3 Unit Placement 3.1 Placement Considerations Unit placement should take account of the following considerations:  Units should not be installed in the following locations:  Where exposure to direct radiation from a high-temperature heat source or to interference from a source of electromagnetic radiation may occur.

  • Page 13: Piping Diagrams

    4 Piping Diagrams SDV5-71DHA / SDV5-80DHA / SDV5-90DHA / SDV5-112DHA / SDV5-140DHA / SDV5-160DHA / SDV5-200DHA / SDV5-250DHA / SDV5-280DHA / SDV5-400DHA / SDV5-450DHA / SDV5-560DHA Figure 4.1: SDV5-XXXDHA piping diagram Legend motor Indoor ambient temperature sensor Indoor heat exchanger mid-point temperature sensor Indoor heat exchanger outlet temperature sensor flare nut gas side...

  • Page 14: Wiring Diagrams

    5 Wiring Diagrams SDV5-71DHA / SDV5-80DHA Figure 5.1: SDV5-71DHA, SDV5-80DHA Duct wiring diagram 201906...
  • Page 15 SDV5-90DHA / SDV5-112DHA / SDV5-140DHA / SDV5-160DHA Figure 5.2: SDV5-90DHA, SDV5-112DHA, SDV5-140DHA, SDV5-160DHA wiring diagram 201906...
  • Page 16 SDV5-200DHA / SDV5-250DHA / SDV5-280DHA Figure 5.3: SDV5-200DHA, SDV5-250DHA, SDV5-280DHA wiring diagram 201906...
  • Page 17 SDV5-400DHA / SDV5-450DHA / SDV5-560DHA Figure 5.4: SDV5-400DHA, SDV5-450DHA, SDV5-560DHA wiring diagram 201906...
  • Page 18  Notes for installers and service engineers Caution  All installation, servicing and maintenance must be carried out by competent and suitably qualified, certified and accredited professionals and in accordance with all applicable legislation.  Units should be grounded in accordance with all applicable legislation. Metal and other conductive components should be insulated in accordance with all applicable legislation.

  • Page 19: Fan Performance

    6 Fan Performance Figure 6.1: SDV5-71DHA, SDV5-80DHA fan performance 200Pa 190Pa 180Pa 170Pa 160Pa 150Pa 140Pa 130Pa 120Pa 110Pa 100Pa(default) 90Pa 80Pa 70Pa 60Pa 50Pa 30Pa 1150 1200 1250 1300 1350 Air flow (m Figure 6.2: SDV5-90DHA fan performance 200Pa 190Pa 180Pa 170Pa...
  • Page 20 Figure 6.3: SDV5-112DHA fan performance 200Pa 190Pa 180Pa 170Pa 160Pa 150Pa 140Pa 130Pa 120Pa 110Pa 100Pa(default) 90Pa 80Pa 70Pa 60Pa 50Pa 30Pa 1340 1390 1440 1490 1540 1590 1640 1690 1740 1790 1840 1890 Air flow (m Figure 6.4: SDV5-140DHA fan performance 200Pa 190Pa 180Pa...
  • Page 21 Figure 6.5: SDV5-160DHA fan performance 200Pa 190Pa 180Pa 170Pa 160Pa 150Pa 140Pa 130Pa 120Pa 110Pa 100Pa(default) 90Pa 80Pa 70Pa 60Pa 50Pa 30Pa 1870 1920 1970 2020 2070 2120 2170 2220 2270 2320 2370 2420 2470 2520 2570 2620 2670 Air flow (m Figure 6.6: SDV5-200DHA, SDV5-250DHA, SDV5-280DHA fan performance 250Pa 230Pa...
  • Page 22 Figure 6.7: SDV5-400DHA, SDV5-450DHA fan performance 400Pa 380Pa 360Pa 340Pa 300Pa 280Pa 250Pa 220Pa 190Pa 160Pa 130Pa 100Pa 4300 4800 5300 5800 6300 6800 Air flow （m /h） Figure 6.7: SDV5-560DHA fan performance 4 2 5 4 0 0 P a 3 8 0 P a 3 7 5 3 6 0 P a...
  • Page 23 Table 6.1: ESP settings through DIP switch SW2 Capacity ESP1 ESP2 ESP3 ESP4 7.1-16.0kW 100Pa 50Pa 170Pa 200Pa 20.0-28.0kW 170Pa 100Pa 200Pa 250Pa 40-56kW 300Pa 100Pa 200Pa 400Pa Table 6.2: ESP settings through the new wired controller Capacity 7.1-16.0kW 30Pa 50Pa 60Pa 70Pa...

  • Page 24: Capacity Tables

    7 Capacity Tables 7.1 Cooling Capacity Table Table 7.1: High Static Pressure Duct cooling capacity Indoor air temperature (°C WB/DB) Outdoor air Capacity 14/20 16/23 18/26 19/27 20/28 22/30 24/32 temperature (kW) (°C DB) 10.0 12.0 14.0 16.0 18.0 20.0 21.0 23.0 25.0...
  • Page 25 Table 7.1: High Static Pressure Duct cooling capacity (continued) Indoor air temperature (°C WB/DB) Outdoor air Capacity 14/20 16/23 18/26 19/27 20/28 22/30 24/32 temperature (kW) (°C DB) 10.0 10.7 11.7 12.0 10.7 11.5 14.0 10.7 11.4 16.0 10.7 11.3 18.0 10.7 11.0...
  • Page 26 Table 7.1: High Static Pressure Duct cooling capacity (continued) Indoor air temperature (°C WB/DB) Outdoor air Capacity 14/20 16/23 18/26 19/27 20/28 22/30 24/32 temperature (kW) (°C DB) 10.0 11.3 13.2 10.4 14.0 10.6 14.8 10.6 16.7 11.0 18.2 11.0 12.0 11.3 13.2...
  • Page 27 Table 7.1: High Static Pressure Duct cooling capacity (continued) Indoor air temperature (°C WB/DB) Outdoor air Capacity 14/20 16/23 18/26 19/27 20/28 22/30 24/32 temperature (kW) (°C DB) 10.0 13.8 12.1 16.2 13.3 18.8 14.8 20.0 15.1 21.2 15.1 23.8 15.7 26.0 15.7...
  • Page 28 Table 7.1: High Static Pressure Duct cooling capacity (continued) Indoor air temperature (°C WB/DB) Outdoor air Capacity 14/20 16/23 18/26 19/27 20/28 22/30 24/32 temperature (kW) (°C DB) 10.0 19.3 16.9 22.7 18.6 26.3 20.8 28.0 21.2 29.7 21.2 33.3 22.0 36.4 22.0...
  • Page 29 Table 7.1: High Static Pressure Duct cooling capacity (continued) Indoor air temperature (°C WB/DB) Outdoor air Capacity 14/20 16/23 18/26 19/27 20/28 22/30 24/32 temperature (kW) (°C DB) 10.0 31.1 27.2 36.5 29.9 42.3 33.3 45.0 34.0 47.7 34.0 53.6 35.3 58.5 35.4...
  • Page 30 7.2 Heating Capacity Table Table 7.2: High Static Pressure Duct heating capacity Indoor air temperature (°C DB) Outdoor air Capacity temperature (°C) (kW) -19.8 4.48 4.48 4.48 4.48 4.48 4.48 -18.8 4.80 4.80 4.80 4.80 4.80 4.80 -16.7 5.04 5.04 5.04 5.04 5.04...
  • Page 31 Table 7.2: High Static Pressure Duct heating capacity (continued) Indoor air temperature (°C DB) Outdoor air Capacity temperature (°C) (kW) -19.8 5.60 5.60 5.60 5.60 5.60 5.60 -18.8 6.00 6.00 6.00 6.00 6.00 6.00 -16.7 6.30 6.30 6.30 6.30 6.30 6.30 -14.7 6.50...
  • Page 32 Table 7.2: High Static Pressure Duct heating capacity (continued) Indoor air temperature (°C DB) Outdoor air Capacity temperature (°C) (kW) -19.8 8.96 8.96 8.96 8.96 8.96 8.96 -18.8 9.60 9.60 9.60 9.60 9.60 9.60 -16.7 10.08 10.08 10.08 10.08 10.08 10.08 -14.7 10.40...
  • Page 33 Table 7.2: High Static Pressure Duct heating capacity (continued) Indoor air temperature (°C DB) Outdoor air Capacity temperature (°C) (kW) -19.8 12.60 12.60 12.60 12.60 12.60 12.60 -18.8 13.50 13.50 13.50 13.50 13.50 13.50 -16.7 14.18 14.18 14.18 14.18 14.18 14.18 -14.7 14.63...
  • Page 34 Table 7.2: High Static Pressure Duct heating capacity (continued) Indoor air temperature (°C DB) Outdoor air Capacity temperature (°C) (kW) -19.8 17.64 17.64 17.64 17.64 17.64 17.64 -18.8 18.90 18.90 18.90 18.90 18.90 18.90 -16.7 19.85 19.85 19.85 19.85 19.85 19.85 -14.7 20.48...
  • Page 35 Table 7.2: High Static Pressure Duct heating capacity (continued) Indoor air temperature (°C DB) Outdoor air Capacity temperature (°C) (kW) -19.8 28.00 28.00 28.00 28.00 28.00 28.00 -18.8 30.00 30.00 30.00 30.00 30.00 30.00 -16.7 31.50 31.50 31.50 31.50 31.50 31.50 -14.7 32.50...

  • Page 36: Electrical Characteristics

    8 Electrical Characteristics Table 8.1: High Static Pressure Duct electrical characteristics Power supply Indoor fan motors Model name Rated motor Volts Min. volts Max. volts output (kW) SDV5-71DHA 220-240 0.15 SDV5-80DHA 220-240 0.15 SDV5-90DHA 220-240 0.18 SDV5-112DHA 220-240 0.31 SDV5-140DHA 220-240 0.34 SDV5-160DHA...

  • Page 37: Table Of Contents

    9 Sound Levels 9.1 Overall Figure 9.1: High Static Pressure Duct sound pressure level Table 9.1: High Static Pressure Duct sound pressure levels measurement Sound pressure levels dB(A) Model name SDV5-71DHA SDV5-80DHA SDV5-90DHA SDV5-112DHA SDV5-140DHA SDV5-160DHA SDV5-200DHA SDV5-250DHA SDV5-280DHA SDV5-400DHA SDV5-450DHA SDV5-560DHA Notes:...
  • Page 38 Figure 9.4: SDV5-112DHA octave band levels Figure 9.5: SDV5-140DHA octave band levels NC65 NC65 NC60 NC60 NC55 NC55 NC50 NC50 NC45 NC45 NC40 NC40 NC35 NC35 NC30 NC30 NC25 NC25 NC20 NC20 NC15 NC15 125 250 500 1000 2000 4000 8000 500 1000 2000 4000 8000 Octave band center frequency (Hz) Octave band center frequency (Hz)
  • Page 39 HIGH STATIC PRESSURE DUCT UNITS SDV5-71-280DHA C O M M E R C I A L A I R C O N D I T I O N E R S S D V 5...

  • Page 40: Sdv5-71Dha

    SDV5-71DHA...
  • Page 41 Description Part Code Note Qty Price Code MODEL: SDV5-71DHA HIGH STATIC PRESSURE DUCT UNIT E-Part box cover 12226000000009 E-part box assembly 17226000002934 Reactor 17400306000070 Indoor unit main control board 17126000003647 17400401001516 Wire joint Wire joint 17400401000156 Pipe temperature sensor 11201007000025 Pipe temperature sensor assemblies 11201007000030 Evaporator ass'y...

  • Page 42: Sdv5-80Dha

    SDV5-80DHA...
  • Page 43 Description Part Code Note Qty Price Code MODEL: SDV5-80DHA HIGH STATIC PRESSURE DUCT UNIT E-Part box cover 12226000000009 E-part box assembly 17226000002934 Reactor 17400306000070 Indoor unit main control board 17126000003647 17400401001516 Wire joint Wire joint 17400401000156 Pipe temperature sensor 11201007000025 Pipe temperature sensor assemblies 11201007000030 Evaporator ass'y...

  • Page 44: Sdv5-90Dha

    SDV5-90DHA...
  • Page 45 Description Part Code Note Qty Price Code MODEL: SDV5-90DHA HIGH STATIC PRESSURE DUCT UNIT E-Part box cover 12226000000009 E-part box assembly 17226000002774 Indoor unit main control board 17126000003317 Reactance 17400306000163 17127000006656 Radiator Components 2.3.1 rectifier bridge 11201418000014 2.3.2 Module board assembly 17127000006679 Wire joint 17400401001516...

  • Page 46: Sdv5-112Dha

    SDV5-112DHA...
  • Page 47 Description Part Code Note Qty Price Code MODEL: SDV5-112DHA HIGH STATIC PRESSURE DUCT UNIT E-Part box cover 12226000000009 E-part box assembly 17226000002774 Indoor unit main control board 17126000003317 Reactance 17400306000163 17127000006656 Radiator Components 2.3.1 rectifier bridge 11201418000014 2.3.2 Module board assembly 17127000006679 Wire joint 17400401001516...

  • Page 48: Sdv5-140Dha

    SDV5-140DHA...
  • Page 49 Description Part Code Note Qty Price Code MODEL: SDV5-140DHA HIGH STATIC PRESSURE DUCT UNIT E-Part box cover 12226000000009 E-part box assembly 17226000002659 Reactance 17400306000163 Radiator Components 17127000006656 2.2.1 17127000006679 Module board assembly 2.2.2 Radiator 11203803002876 2.2.3 rectifier bridge 11201418000014 Indoor unit main control board 17126000003317 Wire joint 17400401001516...

  • Page 50: Sdv5-160Dha

    SDV5-160DHA...
  • Page 51 Description Part Code Note Qty Price Code MODEL: SDV5-160DHA HIGH STATIC PRESSURE DUCT UNIT E-Part box cover 12226000000009 E-part box assembly 17226000002659 Reactance 17400306000163 Reactance 17400306000163 17127000006656 Radiator Components Radiator Components 17127000006656 2.2.1 Module board assembly 17127000006679 2.2.1 Module board assembly 17127000006679 2.2.2 Radiator...

  • Page 52: Sdv5-200Dha

    SDV5-200DHA...
  • Page 53 Description Part Code Note Qty Price Code MODEL: SDV5-200DHA HIGH STATIC PRESSURE DUCT UNIT Electric control box cover assembly 12223000010829 E-part box assembly 17226000002663 Indoor unit main control board 17126000003320 Radiator assembly 17127000006663 2.2.1 11201418000014 rectifier bridge 2.2.2 Module board assembly 17127000006676 Reactance 17400306000785...

  • Page 54: Sdv5-250Dha

    SDV5-250DHA...
  • Page 55 Description Part Code Note Qty Price Code MODEL: SDV5-250DHA HIGH STATIC PRESSURE DUCT UNIT Electric control box cover assembly 12223000010829 E-part box assembly 17226000002663 Indoor unit main control board 17126000003320 Radiator assembly 17127000006663 2.2.1 11201418000014 rectifier bridge 2.2.2 Module board assembly 17127000006676 Reactance 17400306000785...

  • Page 56: Sdv5-280Dha

    SDV5-280DHA...
  • Page 57 Description Part Code Note Qty Price Code MODEL: SDV5-280DHA HIGH STATIC PRESSURE DUCT UNIT Electric control box cover assembly 12223000010829 E-part box assembly 17226000002663 Indoor unit main control board 17126000003320 Radiator assembly 17127000006663 2.2.1 11201418000014 rectifier bridge 2.2.2 Module board assembly 17127000006676 Reactance 17400306000785...

  • Page 58: Technical Support

    SINCLAIR CORPORATION Ltd. 1-4 Argyll St. London W1F 7LD Great Britain www.sinclair-world.com This product was manufactured in China (Made in China). REPRESENTATIVE SINCLAIR Global Group s.r.o. Purkynova 45 612 00 Brno Czech Republic TECHNICAL SUPPORT SINCLAIR Global Group s.r.o. Purkynova 45...
