- Page 1 Z-WAVE.ME WALL-MOUNTED MULTISENSOR USER MANUAL ZME_WB-MSW WB-MSW-ZWAVE...
- Page 2 The multisensor case is made of plastic and is not waterproof, designed for use in homes and offices. For wall mounting. Supports operation via the Z-Wave™ radio protocol or via the two-wire RS-485 bus with Modbus RTU commands. Wall-mounted Multisensor Manual full manual...
-
Page 3: Wall Mounting
CONNECTION WALL MOUNTING The terminal block “V+ GND A B” with a 3.5 mm pitch For mounting with the possibility of easy removal use is used to connect power and the RS-485 bus. screws with a head diameter of about 7 mm, for permanent fixation use 9-10 mm. - Page 4 Z-WAVE ADD / REMOVE PROCESS Remove the top cover Locate the latch tab on the underside Press the latch until the ends with Lift the top cover of the case a screwdriver perpendicular to the side of the case...
-
Page 5: Technical Specifications
TECHNICAL SPECIFICATIONS Z-Wave include button is located on the board. Switch the controller to the “Inclusion” or “Add” mode and press the button 3 times. To exclude multisensor, switch the Z-Wave controller to the Voltage 9 V – 28 V DC “Exclusion”... - Page 6 Ready to work Measured value Range Error rate after power on 400 – 5000 ppm 100 ppm + 5% 3 min, Concentration CO (parts per million) from the measured value auto-calibration every 7 days ±0.3 °С (in range 0 – 70 °C) 1 sec Temperature -40 °С...
- Page 7 You can contact us using the form on the website https://help.z-wave.me or by writing to us directly by e-mail: info@z-wave.me support@z-wave.me FULL MANUAL https://z-wave.me/manual/msw/...
