LINCOLN ELECTRIC EUROPE
Service Notice N° : ESN0071 Rev. 0
Date:
R-5141-002-2R TRIGGER CABLE REPLACEMENT
Invertec 170TX 230V CE
Invertec 170TPX 230V CE
Invertec 170TPX 230V AUS
Invertec 220TPX 115-230V CE
Invertec 220TPX 115-230V AUS
This service note is always applicable to all equipment listed with
serial number
Be sure that only qualified individuals perform all installation, operation,
maintenance and repair procedures.
damages caused by improper installation, improper care or abnormal operation.
Before opening or disassembling any parts of the product, the power must be
turned OFF and the product must be disconnected from the input power source.
Only Lincoln trained service technicians are authorized to perform these
modifications.
17 September 2018
Product
Before P1180704983
WARNING
K Number
K12054-1
K12055-1
K12055-2
K12057-1
K12057-2
Lincoln Electric is not responsible for
1
Code Number
52111
52112
52122
52104
52121
Advertisement
Related Manuals for Lincoln Electric Invertec 170TX 230V CE
Summary of Contents for Lincoln Electric Invertec 170TX 230V CE
- Page 1 Be sure that only qualified individuals perform all installation, operation, maintenance and repair procedures. Lincoln Electric is not responsible for damages caused by improper installation, improper care or abnormal operation. Before opening or disassembling any parts of the product, the power must be turned OFF and the product must be disconnected from the input power source.
- Page 2 Explanation of the Problem The 5 pin metallic trigger connector assembled on cable R-5141-002-2 doesn’t guarantee a good insulation between the ground connected case and the torch cables during high voltage start ignition. This cause the equipment restart during the start of welding or in the worst case the failure of the input board.
- Page 3 Figure 2: Inside picture of the equipment 3. Un-wrap the cable around the toroid. This toroid will be assembled again on the new cable. 4. Un-screw the fixing screws of the connector on the front panel and remove the cable. 5.
- Page 4 Figure 3: Trigger cable 5 turns around the toroid 7. Link the toroid with a tie to the remote cable. 8. Verify that all the earth/ground connections are correctly fixed 9. Close the equipment...
