Sennheiser MKE PLATINUM Product Sheet

MKE
Microphones |

General Description

The MKE is a high-quality, sweat-resistant, sub-miniature clip-
on microphone designed for all areas of live work. It features excellent
sound quality and rugged design. The frequency response curve has
been optimised for live stage work, with more headroom in the treble for
higher levels and improved feedback rejection. The MKE
with a very thin (only 1 mm) yet rugged cable, making this microphone
an ideal partner for all live sound applications.

Features

Umbrella Diaphragm™ protects the mic against sweat
Versatile attachment due to an extensive range of accessories
High maximum sound pressure level
Treble response adapted to the requirements of live stage work
Thin (only 1 mm), flexible and rugged cable, low in handling noise
Delivery includes: 1 MKE
1 MZC 2-1 cap (short), 1 MZC 2-2 cap (long)
(for altering the frequency response curve)

Recommended Accessories

MZ 2-1 Gold accessory set
consisting of: 2 MZW 2 (black and beige)
2 MZQ 02 (black and beige)
2 ZH 102 (anthracite and beige)
1 MZW 02
1 carrying case
MZ 2-3 Gold accessory set
consisting of 10 make-up protection caps
MZM 2/MZM 10 magnetic mount set

Product Variants

MKE platinum-4-3-C: as MKE
MKE platinum-5-C: with open-ended cable,
cable length 4 m, 5 mV/Pa ± 2.5 dB, black
MKE platinum-5-3-C: as MKE
-4-C
Back-Electret Condenser Microphone
-4-C clip-on microphone,
Cat. No. 004741
Cat. No. 004743
Cat. No. 001866
-4-C, but beige Cat. No. 005277
Cat. No. 005303
-5-C, but beige Cat. No. 005304
is fitted

Technical Data

Pick-up pattern ....................................................... omni-directional
Frequency response .................................... 20 – 20,000 Hz ± 3 dB
Sensitivity
(free field, no load) (1 kHz) ........................... 6.3 mV/Pa ± 2.5 dB
Nominal impedance .................................................................... 1 kΩ
Min. terminating impedance ..................................................4.7 kΩ
Equivalent noise level
A-weighted (DIN IEC 651)........................................................ 26 dB
CCIR-weighted (CCIR 468-3).................................................... 39 dB
Max. SPL (1 kHz)...............................................140 dB (THD = 1 %)
Power supply .................................................................. 18 kΩ/7.5 V
Supply current...........................................................approx. 250 µA
Connector .................................................3-pin audio connector for
Cable length.................................................................................1.6 m
Dimensions .......................................................................... Ø 4.8 mm
Weight .............................................................................................. 1 g
0°
Cat. No. 005276
SK 50/SK 250/SK 5012
90°
