Sennheiser MKE platinum-C Instructions For Use Manual
Sennheiser MKE platinum-C Instructions For Use Manual

Sennheiser MKE platinum-C Instructions For Use Manual

Clip-on condenser microphone
Hide thumbs Also See for MKE platinum-C:

Advertisement

MKE
platinum-C
Bedienungsanleitung
Instructions for use
Notice d'emploi
Istruzioni per l'uso
Instrucciones para el uso
Gebruiksaanwijzing

Advertisement

loading
Need help?

Need help?

Do you have a question about the MKE platinum-C and is the answer not in the manual?

Questions and answers

Summary of Contents for Sennheiser MKE platinum-C

  • Page 1 platinum-C Bedienungsanleitung Instructions for use Notice d‘emploi Istruzioni per l‘uso Instrucciones para el uso Gebruiksaanwijzing...
  • Page 2 It features excellent sound quality and rugged design. The MKE platinum-C is fitted with a very thin (only 1 mm) yet rugged cable, making this microphone an ideal partner for all live sound applications.
  • Page 3 MZC platinum-2 Please protect your MKE platinum-C by means of the makeup protection, if you attach your MKE platinum-C to your body and want to put on makeup. The makeup protection is easy to install: just slip it on the microphone (with or without slip-on cap).
  • Page 4 Attachment of the microphone Depending on the field of application, you may attach the MKE platinum-C in different ways to either articles of clothing or your body. Attachment to articles of clothing You may use the MZQ 02 clip to attach the microphone to your lapel, tie, collar, a button hole, etc.
  • Page 5 You may also use the ZH 102 pin to attach the microphone to articles of clothing made of fabric that will not be damaged by the pin. mechanical loads and is also a very convenient solution, if the articles of clothing do not have collars or edges to which the MZQ 02 clip can be attached.
  • Page 6 Wind-shields Wind noise impairs the quality of outdoor recording and close-up miking. The MZW 2 and MZW 02 wind-shields considerably reduce the wind noise. Freefield frequency-response free Please install the MZW 2 wind-shield, first. This wind-shield reduces the wind noise by a maximum of 20 dB. You may further reduce the wind noise by 10 dB by means of the additional MZW 02 foam-net wind-shield.
  • Page 7 Microfone placed in the middle of the forehead capsule only with MZW2 Microfone placed on the chest, distance to the mouth 25 cm capsule only with MZW2 with MZC2-1 with MZC2-2 with MZC2 and MZW02 with MZC2-1 with MZC2-2 with MZW2 and MZW02...
  • Page 8 MKE platinum-C - Technical data MKE platinum Directional- characteristic Transmission range Freefield- open-Circuit sensitiv (1kHz) Ratedimpedance Min. terminating- impedance Equivalent noise level A-weighted (DIN IEC 651) CCIR-weighted (CCIR 468-1) Sound pressure level limit Feed via SK 50, SK 5012 transmitter...
  • Page 9: Manufacturer Declarations

    Manufacturer declarations Warranty 2 years Approval Sennheiser electronic GmbH & Co. KG declare that this device is in compliance with the applicable CE standards and regulations. WEEE Declaration Please dispose of this product at the end of its operational lifeti- me by bringing it to your local collection point or recycling centre for such equipment.
  • Page 10 Sennheiser electronic GmbH & Co. KG 30900 Wedemark, Germany Phone +49 (5130) 600 0 Fax +49 (5130) 600 300 www.sennheiser.com Printed in Germany Publ. 03/07 086046 / A03...

This manual is also suitable for:

Mke platinum-c - 03-07Mke platinum-c - annexe 38
