iTOOLco Cannon 1K User Manual

Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
USER'S GUIDE
1325 Carden Farm Drive | Clinton, TN 37716 | 865-670-3713 | www.iTOOLco.com

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Cannon 1K and is the answer not in the manual?

Questions and answers

Related Manuals for iTOOLco Cannon 1K

Summary of Contents for iTOOLco Cannon 1K

  • Page 1 USER’S GUIDE 1325 Carden Farm Drive | Clinton, TN 37716 | 865-670-3713 | www.iTOOLco.com...
  • Page 2 Page 2...

  • Page 3: Table Of Contents

    BEFORE OPERATION OF THIS TOOL, READ & UNDERSTAND ALL OF THE INSTRUCTIONS & SAFETY INFORMATION IN THIS MANUAL. CONTENTS Safety First...............4 Important Safety Information..........5 Parts Breakdown...............8 Mounting the Puller on a Drill..........13 Using the Capstan Cleet............14 Using the Articulating Wedge Arm........14 Understanding the Capstan End Plate.........15 Using the Slotted Roller Arm Attachment......15 Using the End Screw Attachment........17...

  • Page 4: Safety First

    SAFETY FIRST Safety is essential in the use and maintenance of this tool. This instruction manual & any markings on the tool provide information for avoiding hazards and unsafe practices related to the use of this tool. Observe all of the safety information provided. SAFETY ALERT SYMBOLS This symbol is used to call your attention to hazards ord unsafe practices that could result in injusry or property damage.

  • Page 5: Important Safety Information

    IMPORTANT SAFETY INFORMATION WARNING Read and understand all instructions and safety information in this manual before operating or servicing this tool. Also read the instruction manual supploed with your drill. FAILURE TO OBSERVE THESE WARNINGS CAN RESULT IN SEVERE INJURY OR DEATH. WARNING - PERSONAL SAFETY HAZARDS Only qualified persons should use this equipment.
  • Page 6 IMPORTANT SAFETY INFORMATION WARNING ENTAGLEMENT HAZARD Do not operate this tool while wearing loose fitting clothing. Put up long hair and keep it away from the unit. Keep hands away from moving objects or anything that can pinch or crush a hand or body part. FAILURE TO OBSERVE THESE WARNINGS CAN RESULT IN SEVERE INJURY OR DEATH.
  • Page 7 DO NOT ALTER CABLE PULLING EQUIPMENT OR ANY EQUIPMENT BOUGHT FROM iTOOLco. Doing so will VOID YOUR WARRANTY. Guards, testing, and safety features are provided for your protection.

  • Page 8: Parts Breakdown

    PARTS BREAKDOWN Page 8...
  • Page 9 PARTS BREAKDOWN Page 9...
  • Page 10 PARTS BREAKDOWN Page 10...
  • Page 11 PARTS BREAKDOWN Page 11...
  • Page 12 PARTS BREAKDOWN Page 12...

  • Page 13: Mounting The Puller On A Drill

    Mounting The Puller on a Drill. The C1K is designed to fit on most manufacturers’ 18v or 20v cordless drills. it is recommended to use brush-less drills for the best pulling results. We do not recommend using the C1K with a 120v electrical drill, these drills can damage your unit.

  • Page 14: Using The Capstan Cleet

    Using the Capstan Cleat You can tie off your rope or string to the capstan using the cleat built into the side of the capstan. Once you have reached the end of the pull, simply remove the rope from the cleat, remove the end plate & slide the rope off. FIG.

  • Page 15: Understanding The Capstan End Plate

    Understanding the Capstan End Plate The Capstan End Plate is designed to allow greater spooling capacity. To remove the plate, loosen the two thumb screws and slide the plate down the channel. Then slide the plate over the thumbscrews to remove it. Use reverse order to install. Fig 1.
  • Page 16 Using the Slotted Roller Arm Attachment (Cont.) When pulling directly on a conduit, align the roller arm wheel center to the edge of the conduit that is going to be used for pulling. Fig 2. Once the alignment is complete, let the slotted arm rest on the lip of the electrical panel with slight downward pressure.

  • Page 17: Using The End Screw Attachment

    Using the Slotted Roller Arm Attachment with the End Screw. When installing wire in an underground conduit or any electrical conduit stub up, install the End Screw on the Slotted Roller Arm. Place End Screw adapter inside the conduit, then tighten down the set screw on the lip of the conduit.

  • Page 18: General Usage Instructions

    General Usage Instructions. WARNING: Never use the puller in situations where live electrical circuits are in use. Always use the proper hand protection (gloves) and eye protection (goggles) when working with tools like the C1K. For wire pulls in electrical junction boxes, gutters, switchgear, or sub panels when using rope, we recommend that you use the Pivot Arm.

This manual is also suitable for:

C1k
