- Page 1 DMC-42x0 Installation Manual - UL DMC-42x0 Installation Manual Manual Rev. 1.0a By Galil Motion Control, Inc. Galil Motion Control, Inc. 270 Technology Way Rocklin, California 95765 Phone: (916) 626-0101 Fax: (916) 626-0102 E-mail Address: support@galil.com URL: www.galil.com Rev 05/2023...
-
Page 2: Using This Manual
Using This Manual This user manual provides information for proper operation and installation of the DMC-42x0 controller. A separate supplemental manual, the Command Reference, contains a description of the commands available for use with this controller. Your DMC-42x0 motion controller has been designed to work with both servo and stepper type motors. -
Page 3: Chapter 1 Overview
Chapter 1 Overview Introduction The DMC-42x0 Series are Galil’s highest performance stand-alone controller. The controller series offers many enhanced features including high speed communications, non-volatile program memory, faster encoder speeds, and improved cabling for EMI reduction. Each DMC-42x0 provides two communication channels: high speed RS-232 (2 channels up to 115K Baud) and 100BaseT Ethernet. -
Page 4: Chapter 2 Installation
Chapter 2 Installation Pre-Installation Operating Environment The location for the use of the DMC-42x0 must meet the following requirements. Description Units Specification Operating Temperature 0 to +70 Humidity 20-95% (non-condensing) Operating Altitude Feet 10000 Mounting Location The DMC-4280 can be mounted in one of two ways, according to figure 2a and 2b in the Mounting the Controllers section. -
Page 5: Unpacking The Controller
1. Check that no visible damage has occurred to the controller, or internal amplifiers. If any damage has occurred to the controller, or the components shipped with the controller, contact Galil Motion Control immediately. Contact information can be found in the beginning of this manual. -
Page 6: Communication Connections
Installation Mounting the Controllers The DMC-42x0 motion controller must be mounted to a flat surface with the configuration in either figure 2a or 1 . If you are using the configuration in figure 2a: Use #10 pan head screws to connect each of the 4 holes shown below. -
Page 7: Additional Wiring
Additional Wiring Additional wiring to the Analog and Digital I/O, encoders, limit switches and other connections found on the ICM-2900 connected to the DMC-42x0 motion controller can be used to complete your applications. For detailed information regarding these connections, see the DMC-42x0 User Manual. Powering the controller Once the connections have been made from the AC power to the DMC-42x0 motion controller, the controller may be powered-up. -
Page 8: Appendix: Specifications
Appendix - Specifications A1 - Electrical Specifications Servo Control MCMD Motor Command: +/-10 volt analog signal. Resolution 16-bit DAC or 0.0003 volts. 3 mA maximum Amplifier Enable TTL (0-5V), 20mA sink/source Input / Output Opto-isolated Inputs: DI[16:1]*, 2.2 kΩ in series with opto-isolator Limit Active high or low requires at least 1mA to activate. -
Page 9: 5, ±12V Power Output Specifications
+5, ±12V Power Output Specifications Output Voltage Tolerance Max Current Output ±5% 1.1A +12V ±10% 40mA -12V ±10% 40mA A2 – Environmental Specifications Description Units Specification Storage Temperature -25 to +70 Operating Temperature 0 to +70 Operating Altitude feet 10,000 Humidity 20-95% A3 –...
