Small Spit Roaster
Get tender, juicy results with a Charmate Spit
Roaster and Charcoal BBQ
240V AC ~ 50Hz rotisserie motor rated to 10kgs
Durable high temperature powder coated solid
steel firebox
Two chrome plated prongs to secure meat
Adjustable rod height lets you control your
cook time
BBQ hot & fast with the two chrome plated heavy
duty grills
Cooking surface (mm): 600 x 320
Overall dimensions (mm): 950 W x 360 D x 620 H
Approved to Australian Standards
FOR OUTDOOR USE ONLY
DO NOT OPERATE THIS APPLIANCE BEFORE READING THE INSTRUCTION BOOKLET
DO NOT PLACE ARTICLES ON OR AGAINST THIS APPLIANCE
DO NOT STORE CHEMICALS OR FLAMMABLE MATERIALS OR SPRAY AEROSOLS NEAR THIS APPLIANCE
DO NOT OPERATE THE APPLIANCE INDOORS
DO NOT OPERATE IN AN ENCLOSED AREA. ACCESSIBLE PARTS MAY BE VERY HOT. KEEP YOUNG
CHILDREN AWAY.
MINIMUM CLEARANCES FROM COMBUSTIBLE MATERIALS: 3 METRES
Charmate® is a registered trademark of: Sitro Group Australia Pty Ltd - www.gasmate.com.au & Aber Living, N.Z. - www.charmate.co.nz
& Charcoal BBQ
Model No. CSB001
Important: Retain these instructions for future use.
03913 04/19

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the CSB001 and is the answer not in the manual?

Questions and answers

Related Manuals for Charmate CSB001

Summary of Contents for Charmate CSB001

  • Page 1 DO NOT OPERATE IN AN ENCLOSED AREA. ACCESSIBLE PARTS MAY BE VERY HOT. KEEP YOUNG CHILDREN AWAY. MINIMUM CLEARANCES FROM COMBUSTIBLE MATERIALS: 3 METRES Important: Retain these instructions for future use. Charmate® is a registered trademark of: Sitro Group Australia Pty Ltd - www.gasmate.com.au & Aber Living, N.Z. - www.charmate.co.nz 03913 04/19...

  • Page 2: Important Safety Warnings

    IMPORTANT SAFETY WARNINGS • Proper clearance of 3m between the barbecue and READ ALL SAFETY WARNINGS AND INSTRUCTIONS combustible material (bushes, trees, wooden decks, CAREFULLY BEFORE ASSEMBLING AND OPERATING fences, buildings, etc.) or construction should be YOUR BARBECUE. maintained at all times when barbecue is in use. Do not place barbecue under a roof over hang or other enclosed area.
  • Page 3 IMPORTANT SAFEGUARDS TO AVOID BURNS ROTISSERIE MOTOR • DO NOT attempt to move the barbecue. When using electrical appliances, basic safety precautions • Always wear protective gloves or oven mitts. should always be followed, including the following: • DO NOT touch any hot barbecue surfaces. •...

  • Page 4: Exploded Diagram

    EXPLODED DIAGRAM PARTS LIST PART NO. DESCRIPTION PART NO. DESCRIPTION Motor Hexagon Screw Prong Split Pin Skewer Fixing Pin Handle Support Assembly A Sleeve Support Post Cooking Grate Hexagon Screw Support Assembly B Charcoal Grate...
  • Page 5 ASSEMBLY INSTRUCTIONS Tools Needed 2 Adjustable spanners. Step 1 Attach the four legs using eight M8x16mm bolts and nuts. Step 2 Attach the two support posts using four M8x35mm bolts and nuts.
  • Page 6 Step 3 Slide the support assemblies onto the posts and secure with the fixing pin and split pin. Step 4 Place the charcoal grate into the bottom of the body. The cooking grates fit into the top of the body if required.
  • Page 7 Step 5 Slide the motor onto the support assembly, then position the prongs sleeve and handle onto the rotisserie shaft as required. Completed Assembly...

  • Page 8: After Use Safety

    OPERATING INSTRUCTIONS AFTER USE SAFETY WARNING WARNING Place the barbecue outdoors on a hard, level and • Always allow barbecue and all components to cool non-combustible surface away from roof overhangs completely before handling. or any combustible material. Never use on wooden •...

  • Page 9: Cleaning And Care

    CLEANING & CARE COOKING CAUTION: All cleaning and maintenance should be done when Cooking directly over hot coals, ideal for searing in juices barbecue is cool and with the fuel supply removed. and grilling food requiring less than 25 minutes of grilling time, such as steaks,ham burgers, hotdogs, chicken parts, Note: Abrasive cleaners will damage this product.

  • Page 10: Rotisserie Cooking

    ROTISSERIE COOKING Rotisserie cooking produces foods that are moist, flavourful Rolled Meat and attractive, as the turning food self bastes. Although the A rolled piece of meat only requires the rotisserie skewer to rotisserie is best for larger pieces of meat or poultry, nearly be inserted through the centre of the length of meat then anything can be used if prepared properly.

  • Page 11: Warranty Statement

    WARRANTY STATEMENT Warranty repairs are free of charge, provided the product is CHARMATE BARBECUES & ACCESSORIES delivered to our Service Department at 33- 35 Lionel Road, Mt PRODUCT RANGE Waverley, Victoria, 3149 or to one of our Authorised Service SITRO GROUP AUSTRALIA (S.G.A.) warrants the purchaser of Agents.
