- Page 1 PEX 8608 Quick Start Hardware Design Guide Version 1.2 December 2009 Website: www.plxtech.com Technical Support: www.plxtech.com/support Copyright © 2009 by PLX Technology, Inc. All Rights Reserved – Version 1.2 December 18, 2009...
- Page 2 © 2009 PLX Technology, Inc. All Rights Reserved. PLX Technology, Inc. retains the right to make changes to this product at any time, without notice. Products may have minor variations to this publication, known as errata. PLX assumes no liability whatsoever, including infringement of any patent or copyright, for sale and use of PLX products.
-
Page 3: Table Of Contents
Channel ............................7 PCB Layout and Stackup Considerations ....................8 PEX 8608 BGA Routing Escape and De-Coupling Capacitor Placement........8 Add-in Board Routing ........................9 System Board Routing ........................9 ... - Page 4 Figure 10. Enable NT Function with NT Strapping Balls ..................11 Figure 11. Disable NT Function ..........................11 Figure 12. SHPC Interface to PEX 8608 Block Diagram ..................12 Figure 13. JTAG Interface Block Diagram ....................... 13 ...
-
Page 5: Preface
PEX 8608, or for any damage or loss caused by deletion of data as a result of malfunction or repair. -
Page 6: Introduction
PLX’s PEX 8608 is an 8-Lane, 8-Port PCI Express 2.0 (Gen 2) compliant switch. PCI Express 2.0 supports transfer rates of 2.5 GT/s and 5.0 GT/s per Lane. The PEX 8608 supports the required 2.5 GT/s as well as the optional 5.0 GT/s on its physical interface. -
Page 7: Transmitter
Longer Links should use 6.0 dB, whereas shorter Links can use the 3.5 dB level. The standard de-emphasis level is selectable by way of the PEX 8608 Link Control 2 register Selectable De- Emphasis bit (Configuration register, offset 98h[bit 6]). - Page 8 In addition to supporting the standard de-emphasis levels, the PEX 8608 has a number of programmable registers to control the Transmitter’s characteristics, such as drive level and de-emphasis. Registers at offsets B98h and BA0h are the SerDes Drive Level registers. Registers at offsets BA8h and BB0h are the Post-Cursor Emphasis Level registers.
-
Page 9: Receiver
The PEX 8608 provides a programmable receive equalization function. Each port has a set of Receiver Equalizer registers, located at offsets BB8h and BBCh, to control a group of 8 SerDes. Each individual SerDes has a 4-bit control word. -
Page 10: Figure 3. Transport Delay Delta
Reference Clock transport delay delta. The PEX 8608 PEX_REFCLKn/p signal is the Reference Clock Input buffer. It has an internal DC-biasing circuit, and hence, should be AC-coupled from the RefClk source driver. Use 0.01 to 0.1 µF capacitors (0603 or 0402-... -
Page 11: Spread Spectrum Clocking (Ssc)
(CFC), the downstream interface will not link-up. To solve this problem, a system designer using the PEX 8608 can either use the SSC isolation feature (explained in section 1.4.1) or provide a means to pass the SSC clock to the downstream component. -
Page 12: Channel
Figure 6 demonstrates a mixed SSC and CFC system that might exist when utilizing PEX 8608’s SSC isolation feature. NOTE: When SSC isolation is used, the SSC clock must be connected to PEX_REFCLKp/n. Downstream Downstream REFCLKp /n Device Device REFCLKp /n . -
Page 13: Pcb Layout And Stackup Considerations
“dog-bone” nets from the pad to a via which will connect it with an internal power or ground plane. The PEX 8608 places all Transmitter and Receiver differential pairs on the outer two rows of balls. -
Page 14: Add-In Board Routing
Add-in Board Routing The PEX 8608 Transmitter pairs escape on the top layer, but at some point must route to the bottom layer, to connect to the gold fingers. If a logic analyzer midbus footprint is placed in the routing path, the layer transition can occur at that point. -
Page 15: Midbus Routing
PCBs with six or more layers. Microstrip and stripline traces each have their own properties, which must be weighed when determining which type of trace to use. 8608 Quick Start Hardware Design Guide – Version 1.2 Copyright © 2009 by PLX Technology, Inc. All rights reserved. -
Page 16: Non-Transparent Port Function
STRAP_NT_UPSTREAM_PORTSEL[3:0] to select the NT Port. Make sure the NT port selected is NOT the same as the upstream port. Method 2. Enable the NT function and configure the NT Port through the serial EEPROM, when the PEX 8608 switch is powering up. -
Page 17: Hot-Plug Circuitry
C Bus. To use 40-I/O expander(s), a register bit within the PEX 8608 must be Set, and boot with serial EEPROM is essential. After the PEX 8608 is powered up, the state machine inside the PEX 8608 scans the number of I/O expander ICs connecting to the I C Bus, starting from Address 000h, in ascending order. -
Page 18: Jtag Interface
At the board level, pull JTAG_TDI, JTAG_TMS, and JTAG_TCK up to 2.5V with 1-kohm to 5-kohm resistors. Pull JTAG_TRST# down to VSS with a 1-kohm to 5-kohm resistor. Because the PEX 8608 JTAG clock frequency can be as high as 25 MHz, a 15-ohm series terminator can be added to TCK, TDI, and TDO, to improve signal quality. -
Page 19: C Interface
The PEX 8608 provides 8 Active-Low “Lane Good” Output balls for each PCI Express Lane on the device. These Output balls can be used to indicate the status of each PEX 8608 Lane. If a given Lane Good indicator is continually asserted, that lane is up and operating at 5 Gbps. -
Page 20: Debug Functions
The SDM function is for viewing the 20-bit Receive Bus (elastic buffer exit) and 20-bit Transmit Bus of each Lane of the SerDes, in the PEX 8608. Two Strapping balls are used to enable either Debug mode function. Pulling down the STRAP_PROBE_MODE# ball enables the EPM function. Pulling down the STRAP_SERDES_MODE_EN# ball enables the SDM function. - Page 21 PEX_LANE_GOOD3# prb_outB3 xmit_dat3 PEX_LANE_GOOD2# prb_outB2 xmit_dat2 PEX_LANE_GOOD1# prb_outB1 xmit_dat01 PEX_LANE_GOOD0# prb_outB0 xmit_dat0 N/C on ball N1 sclk/2 rclk/2 STRAP_NT_P2P_EN# trig_out trig_out 8608 Quick Start Hardware Design Guide – Version 1.2 Copyright © 2009 by PLX Technology, Inc. All rights reserved.
-
Page 22: Pex 8608 Strapping Balls
PEX 8608 Strapping Balls The PEX 8608 has a total of 22 Strapping balls. Eleven of them service different configuration functions. For the PEX 8608, none of the Strapping balls, including the Strapping balls for configuration, have internal pull-up or pull- down resistors. -
Page 23: Power Supplies, Sequencing, And De-Coupling
Power Supplies, Sequencing, and De-Coupling The switch’s maximum power consumption is approximately 3.4W. Special cooling requirements may exist, depending upon the system environment. (Refer to the PEX 8608 Data Book for details). 10.1 Power Supplies The PEX 8608 has the following Power ball groups: VDD10 –... -
Page 24: Figure 15. Power Plane Impedance Versus Frequency
( such as 10 to 22 µF) can be used for bulk de-coupling of lower-frequency components. The proximity of these capacitors is not critical; therefore, they can be placed well outside the BGA matrix if necessary. 8608 Quick Start Hardware Design Guide – Version 1.2 Copyright © 2009 by PLX Technology, Inc. All rights reserved. -
Page 25: Figure 16. Capacitor Footprint Effects On Series Inductance
If holes do exist, capacitor values of some of the capacitors can be adjusted to fill them. 8608 Quick Start Hardware Design Guide – Version 1.2 Copyright © 2009 by PLX Technology, Inc. All rights reserved. -
Page 26: References
PCI Express Card Electromechanical (CEM) Specification, Revisions 1.0a and 1.1 Right the First Time: A Practical Handbook on High Speed PCB and System Design , by Lee Ritchie 8608 Quick Start Hardware Design Guide – Version 1.2 Copyright © 2009 by PLX Technology, Inc. All rights reserved.
