PEX 8618
Quick Start Hardware Design Guide
Website:
Technical Support:
Copyright © 2009 by PLX Technology, Inc. All Rights Reserved – Version 1.2
December 18, 2009
Version 1.2
December 2009
www.plxtech.com
www.plxtech.com/support

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the PEX 8618 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for PLX Technology PEX 8618

Summary of Contents for PLX Technology PEX 8618

  • Page 1 PEX 8618 Quick Start Hardware Design Guide Version 1.2 December 2009 Website: www.plxtech.com Technical Support: www.plxtech.com/support Copyright © 2009 by PLX Technology, Inc. All Rights Reserved – Version 1.2 December 18, 2009...
  • Page 2 © 2009 PLX Technology, Inc. All Rights Reserved. PLX Technology, Inc. retains the right to make changes to this product at any time, without notice. Products may have minor variations to this publication, known as errata. PLX assumes no liability whatsoever, including infringement of any patent or copyright, for sale and use of PLX products.

  • Page 3: Table Of Contents

      Channel ............................7     PCB Layout and Stackup Considerations ....................8     PEX 8618 BGA Routing Escape and De-Coupling Capacitor Placement........8     Add-in Board Routing ........................9     System Board Routing ........................9  ...
  • Page 4 Figure 10. Enable NT Function with NT Strapping Balls ................. 11  Figure 11. Disable NT Function ......................11  Figure 12. SHPC Interface to PEX 8618 Block Diagram ................ 12  Figure 13. JTAG Interface Block Diagram ....................13  C Interface Block Diagram ....................14 ...

  • Page 5: Notice

    PEX 8618, or for any damage or loss caused by deletion of data as a result of malfunction or repair.

  • Page 6: Pci Express Link Interface

    PLX’s PEX 8618 is a 16-Lane, 16-Port PCI Express 2.0 (Gen 2) compliant switch. PCI Express 2.0 supports transfer rates of 2.5 GT/s and 5.0 GT/s per Lane. The PEX 8618 supports the required 2.5 GT/s as well as the optional 5.0 GT/s on its physical interface.

  • Page 7: Transmitter

    Longer Links should use 6.0 dB, whereas shorter Links can use the 3.5 dB level. The standard de-emphasis level is selectable by way of the PEX 8618 Link Control 2 register Selectable De- Emphasis bit (Configuration register, offset 98h[bit 6]).
  • Page 8 Systems with short Links and/or power-sensitive applications ( such as mobile platforms) can optionally decide to use low-swing output drive levels (400 mV ). In the PEX 8618, this can be accomplished by setting the SerDes Drive Level register for a specific Lane to 01000b (400 mV ), and the Post-Cursor Emphasis Level register to 00000b (no de-emphasis).

  • Page 9: Receiver

    The PEX 8618 provides a programmable receive equalization function. Each port has a set of Receiver Equalizer registers, located at offsets BB8h and BBCh, to control a group of 16 SerDes. Each individual SerDes has a 4-bit control word.

  • Page 10: Figure 3. Transport Delay Delta

    Reference Clock transport delay delta. The PEX 8618 PEX_REFCLKn/p signal is the Reference Clock Input buffer. It has an internal DC-biasing circuit, and hence, should be AC-coupled from the RefClk source driver. Use 0.01 to 0.1 µF capacitors (0603 or 0402-...

  • Page 11: Spread Spectrum Clocking (Ssc)

    (CFC), the downstream interface will not link-up. To solve this problem, a system designer using the PEX 8618 can either use the SSC isolation feature (explained in section 1.4.1) or provide a means to pass the SSC clock to the downstream component.

  • Page 12: Channel

    Figure 6 demonstrates a mixed SSC and CFC system that might exist when utilizing PEX 8618’s SSC isolation feature. NOTE: When SSC isolation is used, the SSC clock must be connected to PEX_REFCLKp/n. Downstream Downstream REFCLKp /n Device Device REFCLKp /n .

  • Page 13: Pcb Layout And Stackup Considerations

    “dog-bone” nets from the pad to a via which will connect it with an internal power or ground plane. The PEX 8618 places all Transmitter differential pairs on the outer two rows of balls and Receiver differential pairs on rows three and four.

  • Page 14: Add-In Board Routing

    Add-in Board Routing The PEX 8618 Transmitter pairs escape on the top layer, but at some point must route to the bottom layer, to connect to the gold fingers. If a logic analyzer midbus footprint is placed in the routing path, the layer transition can occur at that point.

  • Page 15: Midbus Routing

    PCBs with six or more layers. Microstrip and stripline traces each have their own properties, which must be weighed when determining which type of trace to use. PEX 8618 Quick Start Hardware Design Guide – Version 1.2 Copyright © 2009 by PLX Technology, Inc. All rights reserved.

  • Page 16: Non-Transparent Port Function

    STRAP_NT_UPSTREAM_PORTSEL[3:0] to select the NT Port. Make sure the NT port selected is NOT the same as the upstream port. Method 2. Enable the NT function and configure the NT Port through the serial EEPROM, when the PEX 8618 switch is powering up.

  • Page 17: Hot-Plug Circuitry

    C Bus. To use 40-I/O expander(s), a register bit within the PEX 8618 must be Set, and boot with serial EEPROM is essential. After the PEX 8618 is powered up, the state machine inside the PEX 8618 scans the number of I/O expander ICs connecting to the I C Bus, starting from Address 000h, in ascending order.

  • Page 18: Jtag Interface

    At the board level, pull JTAG_TDI, JTAG_TMS, and JTAG_TCK up to 2.5V with 1-kohm to 5-kohm resistors. Pull JTAG_TRST# down to VSS with a 1-kohm to 5-kohm resistor. Because the PEX 8618 JTAG clock frequency can be as high as 25 MHz, a 15-ohm series terminator can be added to TCK, TDI, and TDO, to improve signal quality.

  • Page 19: C Interface

    The PEX 8618 provides 16 Active-Low “Lane Good” Output balls for each PCI Express Lane on the device. These Output balls can be used to indicate the status of each PEX 8618 Lane. If a given Lane Good indicator is continually asserted, that lane is up and operating at 5 GT/s.

  • Page 20: Table 2. Cross-Reference Of Ball Names And Related Debug Signal Names

    GPIO18 prb_outB10 xmit_dat10 GPIO17 prb_outB9 xmit_dat9 GPIO16 prb_outB8 xmit_dat8 PEX_LANE_GOOD11# prb_outB7 xmit_dat7 PEX_LANE_GOOD10# prb_outB6 xmit_dat6 PEX_LANE_GOOD9# prb_outB5 xmit_dat5 PEX 8618 Quick Start Hardware Design Guide – Version 1.2 Copyright © 2009 by PLX Technology, Inc. All rights reserved.
  • Page 21 PEX_LANE_GOOD0# prb_outB0 xmit_dat0 N/C at ball T6 sclk/2 rclk/2 STRAP_NT_P2P_EN# trig_out trig_out STRAP_SPARE5# rcvr_dat19 GPIO27 xmit_dat19 GPIO26 xmit_dat18 PEX 8618 Quick Start Hardware Design Guide – Version 1.2 Copyright © 2009 by PLX Technology, Inc. All rights reserved.

  • Page 22: Pex 8618 Strapping Balls

    9 PEX 8618 Strapping Balls The PEX 8618 has a total of 30 Strapping balls. Sixteen of them service different configuration functions. For the PEX 8618, none of the Strapping balls, including the Strapping balls for configuration, have internal pull-up or pull- down resistors.

  • Page 23: Power Supplies, Sequencing, And De-Coupling

    Power Supplies, Sequencing, and De-Coupling The switch’s maximum power consumption is approximately 4.5W. Special cooling requirements may exist, depending upon the system environment. (Refer to the PEX 8618 Data Book for details). 10.1 Power Supplies The PEX 8618 has the following Power ball groups: VDD10 –...

  • Page 24: Board-Level De-Coupling

    A power and ground plane separation of 0.254 mm (0.010 in.) results in approximately 100 pF/in , while a separation of 0.102 mm (0.004 in.) provides approximately 200 pF/in PEX 8618 Quick Start Hardware Design Guide – Version 1.2 Copyright © 2009 by PLX Technology, Inc. All rights reserved.

  • Page 25: Figure 16. Capacitor Footprint Effects On Series Inductance

    If holes do exist, capacitor values of some of the capacitors can be adjusted to fill them. PEX 8618 Quick Start Hardware Design Guide – Version 1.2 Copyright © 2009 by PLX Technology, Inc. All rights reserved.

  • Page 26: References

    PCI Express Card Electromechanical (CEM) Specification, Revisions 1.0a and 1.1 Right the First Time: A Practical Handbook on High Speed PCB and System Design , by Lee Ritchie PEX 8618 Quick Start Hardware Design Guide – Version 1.2 Copyright © 2009 by PLX Technology, Inc. All rights reserved.
