Rear Drive Kit
ProStripe
Model No. 134-6408
Loose Parts
Use the chart below to verify that all parts have been shipped.
Description
No parts required
Bearing support plate
Bolt (M6 x 16)
Rear roller bushing
Thrust washer (36 mm)
Drive cam
Drive key
Roller bushing
Flat washer
Spacer
Shaft
Sprocket (22T)
Washer (M6 x 18)
Bolt (M6 x 20)
Tensioner template
Tensioner pulley
Cap head bolt (M6 x 35)
Nut
Back plate
Chain
Sprocket (10T)
Thrust washer (20 mm)
Circlip
Preparing the Machine
WARNING
Tipping the machine may cause the fuel to
leak. Fuel is flammable and explosive, and
can cause personal injury.
Run the engine dry or remove the fuel with a
hand pump; never siphon the fuel.
1.
Run the engine dry or remove the fuel with a
hand pump.
2.
Move the machine to a level surface, shut off
the engine, wait for all moving parts to stop, and
allow the engine to cool.
© 2021—The Toro® Company
8111 Lyndale Avenue South
Bloomington, MN 55420
®
560 Mower
Qty.
2
3
2
2
4
4
2
6
1
1
1
1
1
1
1
1
1
1
1
1
1
1
Register at www.Toro.com.
Prepare the machine.
Remove the roller.
Finish the installation.
3.
Disconnect the spark-plug wire from the spark
plug; refer to the Operator's Manual for your
machine.
Original Instructions (EN)
Printed in the UK
All Rights Reserved
Form No. 3447-369 Rev B
Installation Instructions
Use
*3447-369*

Advertisement

loading
Need help?

Need help?

Do you have a question about the ProStripe 134-6408 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Toro ProStripe 134-6408

  • Page 1 Move the machine to a level surface, shut off the engine, wait for all moving parts to stop, and allow the engine to cool. *3447-369* © 2021—The Toro® Company Original Instructions (EN) Register at www.Toro.com. 8111 Lyndale Avenue South Printed in the UK...
  • Page 2: Removing The Roller

    Removing the Roller If the grass bag is on the machine, remove the grass bag. Remove the chain cover from the machine by removing the 2 chain-cover bolts (Figure Note: Retain the chain cover and 2 chain-cover bolts for later installation. Remove and discard the existing circlip, thrust washer, sprocket, and chain from the gearbox post (Figure g349697...
  • Page 3 g357358 Figure 2 1. Bolt (M6 x 16) (3) 8. Flat washer (6) 2. Bearing support plate ( 2) 9. Spacer (1) 3. Rear roller bushing (2) 10. Shaft (1) 4. Thrust washer (36 mm) (2) 11. Sprocket (1) 5. Drive cam (4) 12.
  • Page 4: Finishing The Installation

    Finishing the Installation Line up the tensioner template on the rear axle support and temporarily fix the template in place using a chain cover bolt in the corresponding hole. Drill 4 pilot holes [3 mm (1/8 inch)] in the rear axle support in the locations marked.
  • Page 5 g357359 Parts Ref. Part Number Qty. Description Ref. Part Number Qty. Description 111-8216 Washer-thrust 134-6282 Tensioner template 111-8602 Washer-thrust 09438 134-0254 Circlip 09545 Bolt (M6 x 16) 134-1734 Bearing support plate 340129 Roller bushing 134-2034 Key drive 480097 Flat washer 134-2635 Rear roller bushing ZBHIF025U...
