- Page 1 Instructions for use. rifton tricycle. The adaptive Rifton tricycle.
- Page 2 Instructions for use may deviate from your prod- uct due to differing equipment. We reserve the right to make technical modifications. Important information! Ensure that these Instructions for use remain with the product. Your schuchmann Team...
-
Page 3: Table Of Contents
Contents. 1. Preparation................... 05 1.1 Delivery ..........................05 1.2 Safety measures prior to use ................05 1.3 Safe disposal .......................05 1.3.1 Packaging ......................05 1.3.2 Product ........................05 1.4 Where to store the Instructions for use ............06 2. Product description............... 06 2.1 Material information ....................06 2.2 Handling / transport ....................06 2.3 Application areas, use according to the intended purpose .....06 2.3.1 Indications ...................... - Page 4 Contents. 3.15 Mounting bar ......................22 3.16 Front basket ......................22 3.17 Abduction block ...................... 23 3.18 Abduction block with straps ................23 3.19 Groin harness ......................24 3.20 Tricycle stand ......................25 4. Cleaning and maintaining............. 26 4.1 Cleaning and disinfecting ..................26 4.1.1 Cleaning ......................
-
Page 5: Preparation
1. Preparation. 1.1 Delivery On receiving the product, please check it for completeness, lack of faults and any transport damage. Inspect the goods in the presence of your forwarder. Should transport damage have occurred, please arrange for an inventory (determination of the faults) to be made in the presence of the forwarder. -
Page 6: Where To Store The Instructions For Use
2.3 Application areas, use according to the intended purpose The rifton tricycle. is a medical product of risk class 1 and was designed for children, youths and adults for use on private, even surfaces both outdoors and indoors. -
Page 7: Indications
2. Product description. 2.3.1 Indications The rifton tricycle. is suited for users with neuromuscular disorders (e.g. cerebral palsy, muscular dystrophy), who cannot use standard bicycles or vehicles, not even with commercial support wheels, due to their disabilities. To ensure mobility in indoor areas and outdoor areas on... -
Page 8: Equipment For Basic Model
2. Product description. longer. Therefore, always ensure that your speed remains such that you can stop at any time. • The tricycles are not suitable for carrying a second person. The con- sequences arising from such use, which is not in accordance with the intended purpose, shall not fall within the scope of responsibility of the manufacturer. -
Page 9: List Of Accessories
2. Product description. 2.6 List of accessories • Guidance for accompanying • Headrest (shell shape) height- escort incl. push bar adjustable • Guidance for accompanying • Headrest (shell shape) height and escort with hand brake for rear depth-adjustable wheels incl. push bar •... -
Page 10: Settings
All settings can be made using the tool supplied (see below) or without tools. The rifton tricycle is supplied with an assembly kit* to start using the tricycle. The assembly kit* includes: • Two quick-release bolts (not included in the rifton tricycle. -
Page 11: Attachment Of Rear Wheels (Only For Medium & Large Sizes)
3. Settings. 3.1.1 Attachment of rear wheels (only for medium & large sizes) Before attaching or removing the rear wheels, make sure that the parking brake is fully released (variable resistance set to zero). Slide both rear wheels onto the axle. Push both wheels inwards to ensure that the axles reach the outside of the wheel hubs before attaching the quick-release pins. -
Page 12: Attachment Of Front Section (Only For Medium & Large Sizes)
3. Settings. 3.1.2 Attachment of front section (only for medium & large sizes) Set the handlebars to the maximum setting and set the brake to PARK (see point 3.6) before attaching the front section. Align the recess in the front wheel assembly with the recesses in the head tube. -
Page 13: Rear End Cap
3. Settings. 3.2 Rear end cap The end cap is used if a push bar is not in use. Slide the push bar (A) into the tube. Insert the screw through the hole (B), insert the nut into the opposite hole and tighten the nut using the hexagon spanners supplied (see point 3, assembly kit). -
Page 14: Push Bar For Accompanying Escort With Hand Brake For Rear Wheels
3. Settings. 3.4 Push bar for accompanying escort with hand brake for rear wheels Slide the push bar (A) into the tube (B) as shown. Insert the screw (C) through the hole, insert the nut (D) into the opposite hole and tighten the nut (D) using the hexagon spanners supplied (see point 3). -
Page 15: Brake For Accompanying Escorts
3. Settings. 3.5 Brake for accompanying escorts Put the parking brake into the PARK position (see point 3.6). Hook the ball end of the brake cable into the metal bracket (A) in the parking brake housing and lift the cable guide up into the pocket in the brake housing (B) as shown. -
Page 16: Parking Brake
3. Settings. 3.6 Parking brake The parking brake blocks the rear wheels to keep the tricycle in position. It may only be used on flat surfaces. To activate the brake, pull the brake lever (A) all the way up so that the display (B) is aligned with the PARK position. -
Page 17: Pedals / Sandals
3. Settings. 3.7 Pedals / sandals The sandals and the lifting cable (A) can be completely removed so that conven- tional bicycle pedals remain underneath. Loosen the loops of the lifting cable (A) on the backs of both pedals, pull them through the holes in the sandals and release the quick-release pulley from the metal loop at the base of the seat rail. -
Page 18: Seat Height And Depth
3. Settings. 3.8 Seat height and depth To adjust the seat height, place your foot on the grey bar (A) between the rear wheels of the tricycle. Press the release button (B) with both hands on the handle and move the handle up or down to adjust the seat height. -
Page 19: Backrest
3. Settings. 3.10 Backrest The backrest allows you to sit upright and provides attachment points for the positioning vest, positioning strap and headrest. Release the knob (A) to attach the backrest. Turn the clamp (B) so that it fits exactly between the tubes (C). Turn the clamp (B) again to align the brackets with the tubes, set the desired height and tighten the knob (A). -
Page 20: Thorax Pelotte Pads
3. Settings. 3.11 Thorax pelotte pads The thorax pelotte pads can be adjusted in height, angle and width and can also be folded away. Release the knob (A) and bring the thorax pelotte pads on the metal rail (B) into the desired position. To fold away the thorax pelotte pads, press button (C) and push the thorax pelotte pads away. -
Page 21: Handlebars
3. Settings. 21 21 3.13 Handlebars A standard handlebar and a round handlebar are available for the rifton tricycle. The handlebars can be adjusted in height and angle. Release the button (A) and bring the handlebars back into desired position. Release the button (B) to adjust... -
Page 22: Guidance/Pull Bar
3. Settings. 3.14 Guidance/pull bar The guidance/pull bar makes it possible to guide and move the tricycle from the front. Remove the guide/pull bar from the tricycle when it is not in use. Attachment: Raise the handlebars out of the lowest position. -
Page 23: Abduction Block
3. Settings. 3.17 Abduction block The abduction block is suitable for all those who require separation of the knees or abduction. Slide the support tube (A) into the holder underneath the saddle and then tighten the knob (B). The support tube (A) is provided with markings. -
Page 24: Groin Harness
3. Settings. 3.19 Groin harness The lap belt positions the user's pelvis firmly by securing the hips and thighs without exerting pressure on the stom- ach. The small seat only has one slot and one ring per side. If both the positioning strap and the groin harness are used, the slot and the ring of both harnesses should be used. -
Page 25: Tricycle Stand
3. Settings. 3.20 Tricycle stand The tricycle stand transforms your tricycle into a stationary trainer for learning the basic movements of pedaling. Place stand required place ground. Lift the rear end of the tricycle and place the grey projections (B) in the correct recess on the stands. -
Page 26: Cleaning And Maintaining
Velcro séparément dans un hygiene advice. This can be found at sac de lavage www.schuchmann.de/mediathek. 4.1.2 Disinfection Various products can be used for surface disinfection of metal and plastic parts. Liquid disinfectants are available as ready-to-use solutions that are sprayed on and evenly applied with a soft cloth. -
Page 27: Maintenance Specifications
4. Cleaning and maintaining. 4.3.1 Maintenance specifications • Basic cleaning according to manufacturer instructions (see Point 4.1.1) • If necessary, disinfection according to manufacturer instructions (see Point 4.1.2) • Damages to the frame, mounting parts and accessories (cracks, breaks, corrosion, bent or missing parts) •... -
Page 28: Spare Parts
4. Cleaning and maintaining. 4.4 Spare parts Use only original accessories and original spare parts from Schuchmann, as otherwise the safety of the user is endangered and the warranty expires. Should you wish to order spare parts, please contact the specialist dealer who supplied you with the product, stating the serial number of the therapy chair (see Point 7.6). -
Page 29: Technical Data
5. Technical data. 5.1 Dimensions Dimensions - basic model rifton tricycle. rifton tricycle. rifton tricycle. small medium large Total height 54 cm 54 cm 76 cm 112 cm 135 cm 165 cm Total length 67 cm 70 cm 80 cm... -
Page 30: Guarantee
6. Guarantee. The two-year statutory guarantee period shall apply for all products. This begins with the delivery or handover of the goods. Should a verifiable material or manufacturing fault occur within this time period, we shall, after carriage paid return to us, view the indicated damage and, if applicable, either repair or deliver a new product at our discretion. -
Page 31: Identification
• info@schuchmann.de • Fon +49 (0) 5402 / 40 71 00 Product labelling in accordance with MDR 7.2 Product version The rifton tricycle. is available in three sizes and can be supplemented through a diverse range of accessories (see Point 2.6). 7.3 Issue of the document Instructions for use rifton tricycle. - Page 32 schuchmann.de...
