- Page 1 Instructions for use. follow-me momo. The cleaver parent-child tandem coupling for Schuchmann tricycles.
- Page 2 Instructions for use may deviate from your product due to differing equipment. We reserve the right to make technical modifications. Important information! Ensure that these Instructions for use remain with the product. Your schuchmann Team...
-
Page 3: Table Of Contents
7. Coupling and decoupling on the go..........18 8. Suspension bracket for luggage carrier with "Top Light" (optional). . 19 9. Notes on use of the follow-me momo. in size 3....... 20 9.1 Setting up to follow-me momo. in size 3 ............21 follow-me momo. -
Page 4: Preparation
1.4 Where to store the Instructions for use Please store these Instructions for use carefully and ensure that these Instructions for use remain with the product in case of re-use. Should you lose the instructions, you can always download an updated version at www.schuchmann.de . -
Page 5: Product Description
The follow-me momo. in size 1 couples Schuchmann tricycles to 12“. Size 2 is suited for tricycles in 16“ and 20“. follow-me momo. in size 3 pulls tricycles in sizes 24“ and 26“. - Page 6 • We therefore expressly recommend that you only ride your bicycle using the appropriate bicycle helmet acc. DIN EN 1078. • In order to use your follow-me momo. in public road traffic, the lead cycle and the tricycle must be equipped accordingly in line with the provisions.
-
Page 7: Riding Response
2. Product description. 2.4 Riding response If follow-me momo. is used to couple a momo tricycle. to the lead bicycle, the riding response changes. We therefore recommend to practice hand- ling the follow-me momo. at first away from public road traffic and at first without user on the momo tricycle.. -
Page 8: Equipment For Basic Model
2. Product description 2.5 Equipment for basic model • adapter for leading bicycle rear wheel • Incl. special axle nuts • Suspension straps 2.6 Product overview The Fig. below is intended to show you the designation of the most important components as well as the terms which you will find in these Instructions for use. -
Page 9: Requirements For The Lead Bicycle
3. Requirements for the lead bicycle. Both bicycles without suspension and full-suspension bicycles with rear swing arm are suitable for use with the follow me momo.. Prerequisite: The rear construction and the rear wheel rim must be strong enough to safely adsorb the typical side forces, as also generated with one-wheel trailers and bicycle trailers. -
Page 10: Replacing The Quick-Release Clamp On The Lead Bicycle
4. Mounting the parent-child tandem coupling. 4.1.1 Replacing the quick-release clamp on the lead bicycle First, open the quick-release lever (A) and remove it completely. Then screw in the special quick-release clamp (B) and clamp it tight. Please ensure correct assembly: after tightening, the lever must run parallel to the frame strut (C) and allow itself to be folded tightly. -
Page 11: Mount Full Axle Adapter
4. Mounting the parent-child tandem coupling. 4.2 Mount full axle adapter (for bicycles with wheel nuts) First of all, you must unscrew and re- move the wheel nuts (A). Leave the washer on the axle and screw on the full axle adapter (B), tightening the construction well (to the torque stated by the bicycle manufacturer). -
Page 12: Mounting The Hub Shift Adapter
4. Mounting the parent-child tandem coupling. 4.3.1 Mounting the hub shift adapter First, please dismantle the click box (A) or corresponding shift cable from the axle and loosen the wheel nut (B). Then hold the U-tube bracket (C) between the wheel and the luggage carrier. -
Page 13: Mounting Thru Axle Adapter
4. Mounting the parent-child tandem coupling. 4.4 Mounting thru axle adapter First loosen the existing quick-release axle (A) and pull it out. Now please take the thru axle adapter (B), loosen the screw (C) and push the thru axle adapter (B) into the opening on the frame. Now screw on the thru axle adapter (B), e.g. -
Page 14: Mounting The Follow-Me Momo
(G) on the saddle or the luggage carrier (H). Alternatively, an optional suspension bracket (I) can be used (see Point 8). This is fastened onto the luggage carrier. In this way, the follow-me momo. can be hooked safely onto the adult`s bicycle if it is not being used. -
Page 15: Preparation Of The Momo Tricycle
5. Preparation of the momo tricycle. 5.1 Mounting the axle extension Unscrew and remove the wheel nuts (A), leaving the washer on the axle, and screw on the axle extensions (B). Ensure that the failure protection is engaged in the appropriate aperture, and is then firmly tightened (to the torque stated by the bicycle manu- facturer). -
Page 16: Adjust Follow-Me Momo. (To Wheel Diameter Of The Tricycle)
6. Adjust follow-me momo. (to wheel 16 16 diameter of the tricycle) Prior to use, the follow-me momo. must be adjusted to ensure safe utilisation. During the course of this, please ob- serve the following guidelines. 6.1 Adjust clamping plate to tricycle... -
Page 17: Adjusting The Position Of The Adapter Clamp
6. Adjust follow-me momo. (to wheel diameter of the tricycle) Unscrew the two hexagon screws (A) on the clamping plate. Push the clam- ping plate (B) up to the marking (C) you made earlier. The hole centre in the clamping plate (B) must be posi- tioned to the height of the marking. -
Page 18: Coupling And Decoupling On The Go
(D) downwards and unscrew the two handle nuts (E). Now insert the tricycle, whilst lifting the follow-me momo. with one hand – the tricycle should always remain on the ground. Once the axle extensions (F) have been inserted into the clamping... -
Page 19: Suspension Bracket For Luggage Carrier With "Top Light" (Optional)
Turn the ends of the suspension bracket around the edge of the luggage carrier (C) and insert the ends at the top (D). In addition, you can secure the adapter bar with a cable tie (E). Now you can suspend the follow-me momo. from the suspension bracket using a snap hook (F). -
Page 20: Notes On Use Of The Follow-Me Momo. In Size 3
9. Notes on use of the follow-me momo. in size 3. Scope of delivery The following additional parts are included with the follow-me momo. size 3: 1x suspension bracket "Top-Light“ incl. snap hook 2x retaining ropes with ring and eyelet (A) -
Page 21: Setting Up To Follow-Me Momo. In Size 3
9. Notes on using the follow-me momo. in size 3. 9.1 Setting up to follow-me momo. in size 3 After you have adjusted the follow-me momo. to the wheel diameter of the tricycle, you still have to secure the two... -
Page 22: Riding Without Tricycle With The Follow-Me Momo. In Size 3
9. Notes one using the follow-me momo. in size 3. 9.2 Riding without tricycle with the follow-me momo. in size 3 The suspension bracket with snap hook must already be mounted for carrying out the next steps (see Point 8). -
Page 23: Cleaning And Servicing
• Do not use aggressive cleaning agents. Use a mild soapy solution to clean. • Store the bicycle with the follow-me momo., in particular in winter, in a dry room with constant temperatures. 10.2 Servicing Please carry out a daily visual inspection and regularly check the parent-child tandem coupling for cracks, fractures, missing parts and malfunctions. -
Page 24: Guarantee
13. Identification. 13.1 Product version The follow-me momo. tandem coupling is available in three sizes and can be supplemented through accessories (see Point 8). 13.2 Issue of the document Instructions for use follow-me momo. - Change status G; issue 07.2021 13.3 Name and address of the manufacturer, specialist dealer supplying...
