momo therapy bicycle.
Instructions for use.
momo therapy bicycle. The bicycle for more balance.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Momo and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Schuchmann Momo

Summary of Contents for Schuchmann Momo

  • Page 1 Instructions for use. momo therapy bicycle. The bicycle for more balance.
  • Page 2 Instructions for use may deviate from your product due to differing equipment. We reserve the right to make technical modifications. Important information! Ensure that these Instructions for use remain with the product. Your schuchmann Team...

  • Page 3: Table Of Contents

    2. Product description. Contents. 1. Preparation................... 05 1.1 Delivery ..........................05 1.2 Safety measures prior to use ................05 1.3 Safe disposal .......................05 1.3.1 Packaging ......................05 1.3.2 Product ........................05 1.4 Where to store the Instructions for use ............05 2. Product description............... 06 2.1 General information ....................06 2.2 Handling and transport ..................06 2.3 Application areas, use according to the intended purpose .....06...
  • Page 4 Contents. 4.10 Crank shortener ...................... 26 4.11 Special crank for knee contracture..............27 5. Foot positioner................28 5.1 Exercise bike pedals ....................28 5.2 Foot positioning pedals ..................28 5.3 Foot pans ........................28 5.4 Foot pans with leg guidance................29 5.5 Foot pans with dynamic leg guidance ............

  • Page 5: Preparation

    1. Preparation. 1.1 Delivery On receiving the product, please check it for completeness, lack of faults and any transport damage. Inspect the goods in the presence of your forwarder. Should transport damage have occurred, please arrange for an inventory (determination of the faults) to be made in the presence of the forwarder.

  • Page 6: Product Description

    2.2 Handling and transport The momo therapy bicycle. is not intended for carrying since it is equipped with tyres. Should you have to carry the equipment due to obstacles, ensure that all moving parts are tightened. Subsequently, stand in twos on either side of the therapy bicycle, hold the frame from the left and right and carry it to the desired location.

  • Page 7: Contraindications

    2. Product description. dination within the scope of physiotherapy treatment (regular physical therapy measures) 2.3.2 Contraindications In general, the indication should be accompanied by a doctor/orthopae- dist. It should therefore be clarified prior to procurement whether contrain- dications exist for the patient. Any danger to the user or others through the use of a bicycle with support wheels should be excluded.

  • Page 8: Use Not In Accordance With The Intended Purpose / Warning Gui

    2. Product description. 2.4 Use not in accordance with the intended purpose / warning guidelines • Replace bent handlebars and handlebar stems immediately! Breakage may occur in the event of continued use or repairs. • Correct usage of the product requires precise and careful training of the accompanying person.

  • Page 9: Equipment For Basic Model

    2. Product description. 2. Product description. 2.5 Equipment for basic model • Aluminium frame with extra-low access point • Rim brake with separate parking brake • Angle adjustable handlebar stem • Handlebar damper for stabilisation when moving straight on • Drum brake in front wheel •...

  • Page 10: Overview Of Equipment / Accessories

    2. Product description. 2.7 Overview of equipment / accessories Saddle Art. No. Saddle Width Length 37 01 001 Standard saddle Size 1 15 cm 21 cm 37 02 001 Standard saddle Size 2 15 cm 24 cm 37 03 001 Standard saddle Size 3 18 cm 26 cm...
  • Page 11 2. Product description. 2. Product description. Headrest Art. No. Headrest Width Height 37 01 029 Headrest Size 1 20 cm 15 cm 37 02 029 Headrest Size 2 23 cm 18 cm Handlebars Art. No. Classic handlebars – black Width 37 01 011 Classic handlebars for 12"...
  • Page 12 2. Product description. Foot pans Foot pans Min. Max. Min. Max. Min. Max. with dy- height height Art. No. width at width at width at width at Length namic leg of leg Leg gui- front front rear rear guidance guidance dance 37 01 035 Size 1...
  • Page 13 2. Product description. 2. Product description. Positioning Art. No. Hand positioning aid - for all handlebars Front width 37 00 054 Hand positioning aid size 0 8.5 cm 37 01 054 Hand positioning aid size 1 10 cm 37 02 054 Hand positioning aid size 2 12 cm 37 03 054...
  • Page 14 38 01 101 For 12" 38 02 101 For 16" Stabiliser frame with dynamically-working stabilisers and 38 03 101 For 20" adjustable spring strength 38 04 101 For 24" 38 05 101 For 26" 38 00 025 Assembly at Schuchmann...
  • Page 15 You have selected one of the following e-drive configurations (with or without start-up assistance) for the momo therapy bicycle. . Here you have chosen a beginner version or an advanced version. The difference here is the start-up and the top speed of the various modes Eco, Standard and Power, which can be selected via the display.

  • Page 16: Drive Possibilities

    2. Product description. 2.8 Drive possibilities The momo therapy bicycle. can be equipped with the following drives: Rigid sprocket During active pedaling, the rigid sprocket supports the user in overcoming the "dead"/ apex point of the crank. A passive user is assisted in pedaling constantly;...

  • Page 17: Adjusting The Stabilisers

    2. Product description. 2. Product description. 2.9 Adjusting the stabilisers The stabilisers are equipped with spring elements that can be adjusted from soft to hard. To do this, loosen the screw (A) and move the spring element in the slot. Moving towards the stabiliser increases the spring hard- ness.

  • Page 18: Settings

    3.1 Presettings The momo therapy bicycle. is delivered com- pletely assembled. Prior to initial use, howe- ver, the following pre-settings must be made. 3.1.1 Handlebar adjustment You can find our scope of delivery for hand- lebars on page 7 of these Instructions for use.

  • Page 19: Saddle Adjustment

    3. Settings. 3.1.2 Saddle adjustment You can find our selection of saddle forms on page 9 of these Instructions for use. Saddle height The height of the saddle can be adjusted on the frame saddle tube (A) by pulling the saddle post in or out.

  • Page 20: Brakes

    3. Settings. 3.2 Brakes For the momo therapy bicycle. there are different brakes available, depending on the individual requirements of the user. 3.2.1 Parking brake The parking brake supports the user when getting on and off and also secures the therapy bicycle against unintentional rolling away.

  • Page 21: Round Handlebars With Brake Lever Ring

    3. Settings. 3.2.2 Round handlebars with brake lever ring Braking with round handlebars with brake lever ring is done by gently pushing down the ring (A) and is therefore suitable for users with limited strength in arms and hands who re- quire the round handlebars as support point at the same time.

  • Page 22: Tyres And Hoses

    3. Settings. 3.3 Tyres and hoses The tyres of the therapy bicycle must always have enough air pressure, as otherwise the tyres could puncture and the rims get da- maged or the driving behaviour is negatively affected. The optimal tyre pressure is marked on the tyre casing (A).

  • Page 23: Accessories

    4. Accessories. 4.1 Dynamic back and pelvic guide pelotte pads All back and pelvic guide pelotte pads can only be used in connection with a holding bracket (see Point 4.7). For depth adjustment of the pelotte pad holding bracket, please loosen the screws (A) on the right and left- hand sides of the support under the saddle, and bring the holding bracket into the requi-...

  • Page 24: Push Bar

    4. Accessories. 4.3 Push bar The push bar is height adjustable and equip- ped with an integrated antirotation lock. In addition, it can be dismantled. In order to adjust the height, please loosen the clamp (A) and bring the push handle to the required height.

  • Page 25: Handlebar Lock Limiter

    4. Accessories. 4.6 Handlebar lock limiter The handlebar lock limiter can be adjusted to determine the direction of travel. In order to adjust the handlebar lock limiter, please loosen all grub screws (A) and bring the limiter (B) into the required position. You can determine the direction by moving both limiters (B) towards the handlebar stop (C) and tightening them.

  • Page 26: Universal Adapter

    4. Accessories. 4.8 Universal adapter The universal adapter is mounted to the holding bracket and is used to mount the belt sets available for the therapy bicycle. The universal adapter is adjustable in height. To do this, simply loosen the screw (A) at the rear on the adapter and bring the universal adapter into the required position.

  • Page 27: Special Crank For Knee Contracture

    4. Accessories. 4.11 Special crank for knee contracture The special crank for knee contractures is suitable for 20" - 26" tricycles, and can either be mounted on the left or right-hand side.

  • Page 28: Foot Positioner

    5. Foot positioner. 5.1 Exercise bike pedals The exercise bike pedals are characterised by their integrated balancing weight, whereby the tread surface automatically balances its- elf horizontally. This permits the rider to climb on independently. The strap (A) is adjustable in length, and at the same time provides easy side guidance.

  • Page 29: Foot Pans With Leg Guidance

    5. Foot positioner. 5.4 Foot pans with leg guidance See Point 5.3 for the function and set- tings of foot pans. The leg guidance also stabilises the foot joint and re- duces internal rotation of the leg. The adjustment of the leg guidance is to be undertaken through loosening of the screws (A) and moving them in the slotted hole.

  • Page 30: Strap Systems

    6. Strap systems. 6.1 Chest strap The chest strap is attached to the width adjustable back pelotte pad, and, required, ensures secure positioning of the user. The strap is mounted with the aid of the plug lock to the back pelotte pad and threaded through the strap guidance on the click buckle.

  • Page 31: Groin Harness, T-Shaped

    6. Strap systems. 6.3 Groin harness, T-shaped The T-shaped groin harness is moun- ted onto the width adjustable pelvic pelotte pad. The strap is mounted onto the pelvic pelotte pad with the aid of the plug lock and threaded th- rough the strap guidance on the click buckle.

  • Page 32: Electric Drives

    7. Electric drives. 7.1 E-drive The momo therapy bicycle. can optional- ly be equipped with an E-drive (Heinz- mann Direct Power motor (36V, 250W, impulse torque 60Nm). Switching the E-drive on and off To switch the e-drive on and off, press and hold the "MODE"...

  • Page 33: Light System

    (see HEINZMANN user manual) increases its service life. Range The mileage of the momo therapy bicycle. with E-drive depends on different factors: track layout (gradients), load/rider weight, selected assistance le- vel, riding style. HEINZMANN achieves a range of 40 to 80 km per battery charge.

  • Page 34: Cleaning And Servicing

    Danger due to rotating parts The motor can set itself in motion unexpectedly, if the drive system remains switched on when carrying out cleaning work on the momo therapy bicycle. with E-drive. • Remove the E-drive battery before cleaning.

  • Page 35: Chain Maintenance

    8. Cleaning and servicing. 8.1.3 Chain maintenance Drive chains must be regularly cared for. This is in particular the case after riding in rain. The chain must be lubricated with a commercially available chain oil. Due to the expansion of the chain which is a natural result of use, regular inspection of the chain tension is required (see Point 3.4).

  • Page 36: Maintenance Plan

    8. Cleaning and servicing. Danger of malfunction in case of incorrect maintenance Improper maintenance of the electric drive can cause damage to essen- tial components. This might cause a fall. • Maintenance work may only be performed by your specialist dealer (see Point 11.5).

  • Page 37: Repairs

    8. Cleaning and servicing. 8.4 Repairs Bicycle repairs that are not performed by your specialist dealer are at the user’s own risk and discretion. Caution When reinstalling the drive, e.g. after a tyre change on the front wheel, the wheel nuts must be tightened again with a tightening torque of 45 Nm ±...

  • Page 38: Spare Parts

    8. Cleaning and servicing. 8.7 Spare parts Only use accessories and spare parts made by Schuchmann, otherwise you will endanger the user and the warranty becomes void. Please contact the supplying specialist dealer to order spare parts stating the serial number of the bicycle (see Point 11.5). Necessary spare parts and accessories must only be installed by trained personnel.

  • Page 39: Error Messages And Troubleshooting

    8. Cleaning and servicing. 8.9 Error messages and troubleshooting If errors occur during operation of the drive system, “Error” is indicated on the display. At the same time, instead of the current display of the speed, an error number appears. The following table provides information about the possible error sources associated with these numbers and how the malfunction can be elimina- ted.
  • Page 40 8. Cleaning and servicing. ERROR_FAST_OVER_VOLTAGE Brief overvoltage in the intermediate circuit, possibly due to excessive Error wheel speed or damaged contacts on the battery. Remove the battery and check the contacts. If the contacts are OK, reinsert the battery and restart the system. Please contact your specialist Measure dealer (see Point 11.5) if the contacts on the battery pack are visibly damaged or the error continues to occur.
  • Page 41 8. Cleaning and servicing. ERROR_UNDER_TEMP_MOTOR Error Lower limit temperature for motor operation reached Store the system at room temperature (approx. 20°C). Please contact your Measure specialist dealer (see Point 11.5) if the error continues to occur after approx. 1 hour. ERROR_EEPROM Error Error in the system accumulator...
  • Page 42 8. Cleaning and servicing. ERROR_BMS_VERSION Error Loose contact or other defect on the torque sensor Restart the system. Please contact your specialist dealer (see Point 11.5) if Measure the error continues to occur. 22-30 ERROR_BMS_FAULTY_xxx Error Rechargeable battery error Measure Please contact your specialist dealer (see Point 11.5).

  • Page 43: Technical Data

    9. Technical data. 9.1 Dimensions 12“ 16“ 20“ 24“ 26“ 30 - 38 42 - 57.5 50 - 64.5 59 - 76.5 71.5 - 87.5 Pedal to top edge of saddle 33 - 41 45 - 60 52 - 68 61 - 84 73 - 95 Pedal to top edge of saddle...

  • Page 44: E-Drive

    9. Technical data. 9.4 E-drive system Protection class Control Operating voltage 36 V Max. current depending on design & operation: 10 - 33 A Motor Type PRA 180-25 Motor nominal voltage 22.8 VAC Output 250 W Pedelec (DIN EN 60034-1) depending on design &...

  • Page 45: Lighting System

    9. Technical data. 9.5 Lighting system Front lighting Type AXA Pico 30-E 6V-42V Luminous intensity 30 lx 50 m Be seen 3000 m Lateral visibility Including reflector On/off switch Automatic light/dark sensor Parking light Daytime running light Suitable for E-bike Yes, 6-42 V Primary colour black...

  • Page 46: Identification

    EU Konformitätserklärung EU Declaration of Conformity Firma / Company Schuchmann GmbH & Co. KG Rudolf-Runge-Str. 3 · 49143 Bissendorf · Deutschland / Germany Tel. +49 (0) 5402 / 40 71 00 · Fax +49 (0) 5402 / 40 71 109 erklärt in alleiniger Verantwortung, dass das nachfolgend genannte Produkt der Risikoklasse 1...

  • Page 47: Serial Number / Date Of Manufacture

    • info@schuchmann.de • Fon +49 (0) 5402 / 40 71 00 Product labelling in accordance with MDR 11.3 Product version The momo therapy bicycle. is available in five sizes (12“ - 26“) and can be supplemented through a diverse range of accessories (see Point 4). 11.4 Issue of the document Instructions for use momo therapy bicycle.
  • Page 48 schuchmann.de...
