  • Page 1 UPER ® UPER TORAGE YSTEM 2027R-E1CR24N USER’S MANUAL 1.0a...
  • Page 2 This manual is written for professional system integrators and PC technicians. It mentation, is the property of Supermicro and/or its licensors, and is supplied only under a license. Any use or reproduction of this product is not allowed, except as expressly permitted by the terms provides information for the installation and use of the 2027R-E1CR24N.
  • Page 3 Preface UPER TORAGE YSTEM 2027R-E1CR24N User's Manual Notes Chapter 5: Advanced Serverboard Setup Chapter 5 provides detailed information on the X9DRi-LN4F+ serverboard, includ- ing the locations and functions of connections, headers and jumpers. Refer to this chapter when adding or removing processors or main memory and when reconfig- uring the serverboard.

  • Page 4: Table Of Contents

    Table of Contents UPER TORAGE YSTEM 2027R-E1CR24N User's Manual Table of Contents Control Panel LEDs ..................3-1 Power Fail ....................... 3-2 Overheat/Fan Fail ................... 3-2 Chapter 1 Introduction NIC1 ........................ 3-2 Overview ......................1-1 NIC2 ........................ 3-2 Serverboard Features ..................1-2 HDD .........................
  • Page 5 UPER TORAGE YSTEM 2027R-E1CR24N User's Manual DIMM Installation .................... 5-9 Adding PCI Add-On Cards ................5-14 Serverboard Details ..................5-15 X9DRi-LN4F+ Quick Reference ..............5-16 Connector Definitions ................... 5-18 Jumper Settings .................... 5-25 5-10 Onboard Indicators ..................5-29 5-11 SATA Ports ....................5-30 5-12 Installing Software ..................

  • Page 6: Chapter 1 Introduction

    Chapter 1 Introduction Overview The 2027R-E1CR24N is a high-end storage system comprised of two main subsys- tems: the SC216BTS-R920LPBP 2U/rack mount chassis and the X9DRi-LN4F+ dual processor serverboard. Please refer to our web site for information on operating systems that have been certified for use with the system (www.supermicro.com).

  • Page 7: Serverboard Features

    UDIMM (Unbuffered DIMMs) ECC/Non-ECC DDR3-1866/1600/1333/1066/800 SDRAM. See Chapter 5 for details. Front Control Panel The control panel on the SuperServer 2027R-E1CR24N provides you with system Serial ATA monitoring and control. LEDs indicate system power, HDD activity, network activ- A SATA controller is also integrated into the chipset to provide two SATA 3 (6/Gbps) ity, system overheat/fan fail and power supply failure.
  • Page 8 VGA CONN RTL8211 W83527 Note: The SSG-2027R-E1CR24N comes pre-installed with a Hardware RAID controller installed in PCI-E slot 1 and a JBOD expansion port installed in PCI-E slot 2. Serverboard SAS components shown in the figure above are not included...

  • Page 9: Contacting Supermicro

    UPER TORAGE YSTEM 2027R-E1CR24N User's Manual Contacting Supermicro Headquarters Address: Super Micro Computer, Inc. 980 Rock Ave. San Jose, CA 95131 U.S.A. Tel: +1 (408) 503-8000 Fax: +1 (408) 503-8008 Email: marketing@supermicro.com (General Information) support@supermicro.com (Technical Support) Website: www.supermicro.com Europe Address: Super Micro Computer B.V.

  • Page 10: Chapter 2 Server Installation

    Unpacking the System You should inspect the box the SuperServer 2027R-E1CR24N was shipped in and note if it was damaged in any way. If the server itself shows damage you should file a damage claim with the carrier who delivered it.

  • Page 11: Warnings And Precautions

    Chapter 2: Server Installation UPER TORAGE YSTEM 2027R-E1CR24N User's Manual • Rack Mounting Considerations This product is for installation only in a Restricted Access Location (dedicated equipment rooms, service closets and the like). Ambient Operating Temperature • This product is not suitable for use with visual display work place devices If installed in a closed or multi-unit rack assembly, the ambient operating tempera- acccording to §2 of the the German Ordinance for Work with Visual Display Units.

  • Page 12: Rack Mounting Instructions

    Chapter 2: Server Installation UPER TORAGE YSTEM 2027R-E1CR24N User's Manual Rack Mounting Instructions Locking Tabs Each inner rail has a locking tab. This tab locks the chassis into place when installed This section provides information on installing the chassis into a rack unit with the and pushed fully into the rack.

  • Page 13: Installing The Inner Rails On The Chassis

    Chapter 2: Server Installation UPER TORAGE YSTEM 2027R-E1CR24N User's Manual Inner Rails L-min=676.00(26.61")(outer rail) 21D01 Figure 2-3. Installing the Inner Rails Figure 2-5. Extending and Releasing the Outer Rails Installing the Outer Rails on the Rack Installing the Outer Rails 1.

  • Page 14: Standard Chassis Installation

    Chapter 2: Server Installation UPER TORAGE YSTEM 2027R-E1CR24N User's Manual Optional Quick Installation Method Ball-Bearing Shuttle The following quick installation method may be used to install the chassis onto a rack. Installing the Chassis into a Rack 1. Install the whole rail assembly onto the rack as described on page 6-7.
  • Page 15 UPER TORAGE YSTEM 2027R-E1CR24N User's Manual Notes 2-10...

  • Page 16: Chapter 3 System Interface

    Chapter 3: System Interface Chapter 3 System Interface Overview There are several LEDs on the control panel as well as others on the hard drive carriers to keep you constantly informed of the overall status of the system as well as the activity and health of specific components.

  • Page 17: Power Fail

    TORAGE YSTEM 2027R-E1CR24N User's Manual Power Fail Indicates IDE channel activity. On the SuperServer 2027R-E1CR24N, this LED Indicates a power supply module has failed. The second power supply module will indicates hard and/or DVD-ROM drive activity when flashing. take the load and keep the system running but the failed module will need to be replaced.
  • Page 18 UPER TORAGE YSTEM 2027R-E1CR24N User's Manual Notes...

  • Page 19: Chapter 4 Standardized Warning Statements For Ac Systems

    Only certified technicians should attempt to install or configure components. Read this appendix in its entirety before installing or configuring components in the Supermicro chassis. These warnings may also be found on our web site at http://www.supermicro.com/ about/policies/safety_information.cfm. Warning Definition Warning! This warning symbol means danger.
  • Page 20 Warning Statements for AC Systems UPER TORAGE YSTEM 2027R-E1CR24N User's Manual Warnung ‫جسذٌة‬ ‫اصابة‬ ً‫تتسبب ف‬ ‫حالة ٌوكي أى‬ ً‫اًك ف‬ ‫خطز‬ ًٌ‫ٌع‬ ‫هذا الزهز‬ !‫تحذٌز‬ WICHTIGE SICHERHEITSHINWEISE ‫الذوائز‬ ‫بالوخاطز الٌاجوة عي‬ ‫ي على علن‬ ، ‫ك‬ ‫هعذات‬ ‫تعول على أي‬...

  • Page 21: Installation Instructions

    Chapter 4: Warning Statements for AC Systems UPER TORAGE YSTEM 2027R-E1CR24N User's Manual Installation Instructions Circuit Breaker Warning! Warning! This product relies on the building's installation for short-circuit (overcurrent) Read the installation instructions before connecting the system to the power source.

  • Page 22: Power Disconnection Warning

    Chapter 4: Warning Statements for AC Systems UPER TORAGE YSTEM 2027R-E1CR24N User's Manual ¡Advertencia! 경고! El sistema debe ser disconnected de todas las fuentes de energía y del cable 이 제품은 전원의 단락(과전류)방지에 대해서 전적으로 건물의 관련 설비에 eléctrico quitado de los módulos de fuente de alimentación antes de tener acceso 의존합니다.

  • Page 23: Equipment Installation

    Chapter 4: Warning Statements for AC Systems UPER TORAGE YSTEM 2027R-E1CR24N User's Manual Equipment Installation Waarschuwing Deze apparatuur mag alleen worden geïnstalleerd, vervangen of hersteld door Warning! geschoold en gekwalificeerd personeel. Only trained and qualified personnel should be allowed to install, replace, or service Restricted Area this equipment.

  • Page 24: Battery Handling

    Chapter 4: Warning Statements for AC Systems UPER TORAGE YSTEM 2027R-E1CR24N User's Manual Warnung ‫אזור עם גישה מוגבלת‬ Bei Einsetzen einer falschen Batterie besteht Explosionsgefahr. Ersetzen Sie die Batterie nur durch den gleichen oder vom Hersteller empfohlenen Batterietyp. !‫אזהרה‬ Entsorgen Sie die benutzten Batterien nach den Anweisungen des Herstellers.

  • Page 25: Redundant Power Supplies

    Chapter 4: Warning Statements for AC Systems UPER TORAGE YSTEM 2027R-E1CR24N User's Manual Redundant Power Supplies ‫امداد الطاقة‬ ‫بوحدات‬ ‫عدة اتصاالت‬ ‫جهاز‬ ‫ال‬ ‫يكون لهذا‬ ‫قد‬ ‫الكهرباء‬ ‫عن‬ ‫وحدة‬ ‫ال‬ ‫لعسل‬ ‫كافة االتصاالت‬ ‫يجب إزالة‬ 경고! Warning! This unit might have more than one power supply connection. All connections must 이...

  • Page 26: Comply With Local And National Electrical Codes

    Chapter 4: Warning Statements for AC Systems UPER TORAGE YSTEM 2027R-E1CR24N User's Manual Attention ‫מתח בפנל האחורי‬ L'équipement doit être installé conformément aux normes électriques nationales et locales. !‫הרה‬ ‫אז‬ ‫קיימת סכנת מתח בפנל האחורי בזמן תפעול המערכת. יש להיזהר במהלך‬...

  • Page 27: Hot Swap Fan Warning

    Chapter 4: Warning Statements for AC Systems UPER TORAGE YSTEM 2027R-E1CR24N User's Manual ¡Advertencia! 警告 當您從機架移除風扇裝置，風扇可能仍在轉動。小心不要將手指、螺絲起子和其他 Al deshacerse por completo de este producto debe seguir todas las leyes y 物品太靠近風扇。 reglamentos nacionales. Warnung Attention Die Lüfter drehen sich u. U. noch, wenn die Lüfterbaugruppe aus dem Chassis La mise au rebut ou le recyclage de ce produit sont généralement soumis à...

  • Page 28: Power Cable And Ac Adapter

    UL ou CSA câbles certifiés qui ont UL ou CSA indiqué sur le code power cables and AC adaptors. Using any other cables and adaptors could cause pour tous les autres appareils électriques que les produits désignés par Supermicro a malfunction or a fire. Electrical Appliance and Material Safety Law prohibits the seulement.
  • Page 29 UPER TORAGE YSTEM 2027R-E1CR24N User's Manual Notes 4-20...

  • Page 30: Chapter 5 Advanced Serverboard Setup

    Chapter 5: Advanced Serverboard Setup Chapter 5 Advanced Serverboard Setup This chapter covers the steps required to install the X9DRi-LN4F+ serverboard into the chassis, connect the data and power cables and install add-on cards. All serverboard jumpers and connections are also described. A layout and quick refer- ence chart are included in this chapter for your reference.

  • Page 31: Unpacking

    UPER TORAGE YSTEM 2027R-E1CR24N User's Manual Chapter 5: Advanced Serverboard Setup Unpacking Figure 5-1. Control Panel Header Pins The serverboard is shipped in antistatic packaging to avoid electrical static dis- charge. When unpacking the board, make sure the person handling it is static Ground protected.

  • Page 32: Installing The Processor And Heatsink

    (Do not drop the CPU • on the socket. Do not move the Refer to the Supermicro web site for updates on CPU support. CPU horizontally or vertically and do not rub the CPU against any Installing an LGA2011 Processor pins of the socket, which may damage the CPU or the socket.)

  • Page 33: Installing A Passive Cpu Heatsink

    UPER TORAGE YSTEM 2027R-E1CR24N User's Manual Chapter 5: Advanced Serverboard Setup Installing a Passive CPU Heatsink Warning: You can only install the CPU to the socket in one direction. Make sure that the CPU is properly inserted into the socket before closing the load plate. If it doesn't 1.

  • Page 34: Removing The Heatsink

    UPER TORAGE YSTEM 2027R-E1CR24N User's Manual Chapter 5: Advanced Serverboard Setup Removing the Heatsink Installing Memory Warning: We do not recommend that the CPU or the heatsink be removed. However, if you do need to uninstall the heatsink, please follow the instructions below to uninstall Caution: Exercise extreme care when installing or removing DIMM modules to prevent the heatsink to prevent damage done to the CPU or the CPU socket.
  • Page 35 CPU1/CPU Note: For detailed information on memory support and updates, please refer to the SMC Recommended 13 DIMMs~24 P1-DIMMA1/P1-DIMMB1, P2-DIMME1/P2-DIMMF1, P1-DIMMC1/P1-DIMMD1, P2-DIMMG1/ Memory List posted on our website at http://www.supermicro.com/support/resources/mem.cfm. DIMMs P2-DIMMH1, P1-DIMMA2/P1-DIMMB2, P2-DIMME2/P2-DIMMF2, P1-DIMMC2/P1-DIMMD2, P2-DIMMG2/P2-DIMMH2, P1-DIMMA3/P1-DIMMB3, P2-DIMME3/ Populating RDIMM (ECC) Memory Modules...
  • Page 36 Capacity Channel (DPC) Note: For detailed information on memory support and updates, please refer to the SMC Recommended DIMM Per DIMM Memory List posted on our website at http://www.supermicro.com/support/resources/mem.cfm. 2 Slots Per Channel 3 Slots Per Channel & Data (See the Note...

  • Page 37: Adding Pci Add-On Cards

    YSTEM 2027R-E1CR24N User's Manual Chapter 5: Advanced Serverboard Setup Adding PCI Add-On Cards Serverboard Details The 2027R-E1CR24N can accommodate up to four PCI add-on cards. Figure 5-6. X9DRi-LN4F+ Layout Installing an Add-on Card FAN5 1. Begin by removing the shield for the PCI slot you wish to populate.

  • Page 38: X9Dri-Ln4F+ Quick Reference

    UPER TORAGE YSTEM 2027R-E1CR24N User's Manual Chapter 5: Advanced Serverboard Setup X9DRi-LN4F+ Quick Reference (IPMI) LAN IPMI_Dedicated LAN Onboard Buzzer (Internal Speaker) Jumper Description Default Setting USB 0/1 Back Panel USB 0/1 JBT1 Clear CMOS See Section 5-9 USB 2/3...

  • Page 39: Connector Definitions

    UPER TORAGE YSTEM 2027R-E1CR24N User's Manual Chapter 5: Advanced Serverboard Setup Connector Definitions Power Fail LED ATX Power 24-pin Connector Pin Definitions PWR Fail LED The Power Fail LED connection is Pin Definitions (JF1) Pin# Definition Pin # Definition located on pins 5 and 6 of JF1. Re- Power Connectors +3.3V...
  • Page 40 UPER TORAGE YSTEM 2027R-E1CR24N User's Manual Chapter 5: Advanced Serverboard Setup Power On LED Chassis Intrusion Power LED Chassis Intrusion Pin Definitions (JF1) Pin Definitions The Power On LED connector is lo- The Chassis Intrusion header is des- Pin# Definition...
  • Page 41 UPER TORAGE YSTEM 2027R-E1CR24N User's Manual Chapter 5: Advanced Serverboard Setup IPMB IPMB Header Serial Port Pin Definitions Serial Ports Pin Definitions (COM1/COM2) A System Management Bus header Pin# Definition Pin # Definition Pin # Definition Two serial ports are included on the for IPMI 2.0 is located at IPMB.

  • Page 42: Jumper Settings

    Note: UID can also be triggered via IPMI. For more information on IPMI, please refer to the IPMI User's Guide posted on our Website @http://www.supermicro.com. CMOS Clear JBT1 is used to clear CMOS (which will also clear any passwords). Instead of pins,...
  • Page 43 UPER TORAGE YSTEM 2027R-E1CR24N User's Manual Chapter 5: Advanced Serverboard Setup GLAN Enable/Disable GLAN Enable Manufacturer's Mode Jumper Settings JPL1 enables or disables the GLAN Jumper Setting Definition ports on the serverboard. See the Jumper JPME2 allows the user to...

  • Page 44: 5-10 Onboard Indicators

    X8DT3/i-F/-LN4F UPER TORAGE YSTEM 2027R-E1CR24N User's Manual Chapter 5: Advanced Serverboard Setup X8DT3-LN4/LN4F 5-10 Onboard Indicators Watch Dog Enable/Disable Jumper JWD controls the Watch LAN LEDs Dog function. Watch Dog is a sys- The Ethernet ports (located beside the tem monitor that can reboot the JLAN1/2 LED VGA port) have two LEDs.

  • Page 45: 5-11 Sata Ports

    YSTEM 2027R-E1CR24N User's Manual Chapter 5: Advanced Serverboard Setup 5-11 SATA Ports 5-12 Installing Software The Supermicro FTP site contains drivers and utilities for your system at ftp://ftp. supermicro.com. Some of these must be installed, such as the chipset driver. Serial ATA Ports...

  • Page 46: Superdoctor Iii

    UPER TORAGE YSTEM 2027R-E1CR24N User's Manual Chapter 5: Advanced Serverboard Setup SuperDoctor III The SuperDoctor ® III program is a Web base management tool that supports remote management capability. It includes Remote and Local Management tools. The local management is called SD III Client. The SuperDoctor III program included on the CD-ROM that came with your serverboard allows you to monitor the environment and operations of your system.

  • Page 47: 5-13 Onboard Battery

    UPER TORAGE YSTEM 2027R-E1CR24N User's Manual 5-13 Onboard Battery Please handle used batteries carefully. Do not damage the battery in any way; a damaged battery may release hazardous materials into the environment. Do not discard a used battery in the garbage or a public landfill. Please comply with the regulations set up by your local hazardous waste management agency to dispose of your used battery properly.

  • Page 48: Chapter 6 Advanced Chassis Setup

    Chapter 6: Advanced Chassis Setup Chapter 6 Advanced Chassis Setup This chapter covers the steps required to install components and perform main- tenance on the SC216BTS-R920LPBP chassis. For component installation, follow the steps in the order given to eliminate the most common problems encountered. If some steps are unnecessary, skip ahead to the step that follows.

  • Page 49: Control Panel

    Chapter 6: Advanced Chassis Setup UPER TORAGE YSTEM 2027R-E1CR24N User's Manual Removing the Chassis Cover Figure 6-1. Front and Rear Chassis Views Control Panel Hard Drives (24) Power Supplies (2) 5 Low-profile PCI Slots Remove this screw (if necessary) I/O Ports (see Figure 5-2)

  • Page 50: System Cooling

    Chapter 6: Advanced Chassis Setup UPER TORAGE YSTEM 2027R-E1CR24N User's Manual System Cooling Figure 6-3. Replacing System Cooling Fans System Fans Three 8-cm hot-swap chassis fans provide the cooling for the SuperServer 2027R- E1CR24N. It is very important that the chassis top cover is properly installed in order for the cooling air to circulate properly through the chassis and cool the components.

  • Page 51: Drive Bay Installation/Removal

    SATA drives. Proceed to the next step for instructions. 2. Slide the additional air shroud into the chassis before installing the main air Note: You must use 2.5" drives in the SuperServer 2027R-E1CR24N. shroud. The cjhassis supports 24 hot-swappable hard drives. Only enterprise level SATA 3.
  • Page 52 Figure 6-7. Proper Installation of the Carrier into Hard Drive Bay Warning! Enterprise level hard disk drives are recommended for use in Supermicro chassis and servers. For information on recommended HDDs, visit the Supermicro Web site at http://www.supermicro.com/products/nfo/files/storage/SAS-1-CompList-110909.

  • Page 53: Power Supply

    Changing the Power Supply 1. Determine which power supply needs to be replaced and unplug the power The 2027R-E1CR24N chassis has two redundant, hot-plug 920 Watt power sup- cord to that module. plies. The power modules are hot-swappable, enabling them to be changed without powering down the system.

  • Page 54: Attaching A Jbod Expansion Chassis

    YSTEM 2027R-E1CR24N User's Manual Attaching a JBOD Expansion Chassis The SSG-2027R-E1CR24N features a single JBOD expansion port. The JBOD at- tachment will vary depending on the specific JBOD chassis that is being connected. Please follow the instructions provided with the JBOD.

  • Page 55: Chapter 7 Bios

    The configuration data that determines the system parameters may be changed by entering the AMI BIOS Setup utility. This Setup utility can be accessed by pressing <F2> at the appropriate time during system boot. Note: For AMI UEFI BIOS Recovery, please refer to the UEFI BIOS Recovery User Guide posted @http://www.supermicro.com/support/manuals/.

  • Page 56: Main Setup

    Chapter 7: BIOS UPER TORAGE YSTEM 2027R-E1CR24N User's Manual Starting the Setup Utility Supermicro X9DR6-LN4+ Normally, the only visible Power-On Self-Test (POST) routine is the memory test. SMC Version As the memory is being tested, press the <F2> key to enter the main menu of This item displays the SMC version of the BIOS ROM used in this system.
  • Page 57 Chapter 7: BIOS UPER TORAGE YSTEM 2027R-E1CR24N User's Manual AddOn ROM Display Mode CPU Configuration Use this item to set the display mode for the Option ROM. Select Keep Current to This submenu displays the information of the CPU as detected by the BIOS. It also use the current AddOn ROM Display setting.
  • Page 58 Chapter 7: BIOS UPER TORAGE YSTEM 2027R-E1CR24N User's Manual Clock Spread Spectrum based on the specifications of the application running in the system at the time. The options are Disabled and Enabled. Select Enable to enable Clock Spectrum support, which will allow the BIOS to moni- tor and attempt to reduce the level of Electromagnetic Interference caused by the Intel®...
  • Page 59 Chapter 7: BIOS UPER TORAGE YSTEM 2027R-E1CR24N User's Manual Chipset Configuration CPU C3 Report Select Enabled to allow the BIOS to report the CPU C3 State (ACPI C2) to the operating system. During the CPU C3 State, the CPU clock generator is turned North Bridge Configuration...
  • Page 60 Chapter 7: BIOS UPER TORAGE YSTEM 2027R-E1CR24N User's Manual Port 1B Link Speed Up Tx Preset Select GEN1 to enable PCI-Exp Generation 1 support for Port 1B. Select GEN2 This feature allows the user to select the preset setting for a upstream component to enable PCI-Exp Generation 2 support for Port 1B.
  • Page 61 Chapter 7: BIOS UPER TORAGE YSTEM 2027R-E1CR24N User's Manual Isoc Memory Mode Select Enabled to enable Ischronous support to meet QoS (Quality of Service) When Independent is selected, all DIMMs are available to the operating system. requirements. This feature is especially important for virtualization technology.
  • Page 62 Chapter 7: BIOS UPER TORAGE YSTEM 2027R-E1CR24N User's Manual DRAM RAPL Legacy USB Support (Available when USB Functions is not Disabled) This item allows the user to select the average power limit setting when a DRAM Select Enabled to support legacy USB devices. Select Auto to disable legacy sup- module is in operation.
  • Page 63 Chapter 7: BIOS UPER TORAGE YSTEM 2027R-E1CR24N User's Manual Aggressive Link Power Management Thermal Configuration Select Enabled to enable Aggressive Link Power Management support Thermal Management for Cougar Point B0 stepping and beyond. The options are Enabled and Select Enabled to initialize the PCH Thermal subsystem device located at D31:F6.
  • Page 64 Chapter 7: BIOS UPER TORAGE YSTEM 2027R-E1CR24N User's Manual PERR# Generation Option ROM is Enabled, and the default settings for LAN2 Option ROM~LAN4 Option ROM are Disabled. Select Enabled to allow a PCI device to generate a PERR number for a PCI Bus Signal Error Event.
  • Page 65 Chapter 7: BIOS UPER TORAGE YSTEM 2027R-E1CR24N User's Manual VT-UTF8 Combo Key Support Console Redirection Settings Select Enabled to enable VT-UTF8 Combination Key support for ANSI/VT100 This feature allows the user to specify how the host computer will exchange terminals. The options are Enabled and Disabled.

  • Page 66: Event Logs

    Chapter 7: BIOS UPER TORAGE YSTEM 2027R-E1CR24N User's Manual TPM State TPM Support: Trusted Platform support Select Enabled to enable TPM security settings to improve data integrity and TPM State: Trusted Platform state network security. The options are Disabled and Enabled.
  • Page 67 Chapter 7: BIOS UPER TORAGE YSTEM 2027R-E1CR24N User's Manual Change SMBIOS Event Log Settings METW (Multiple Event Count Time Window)  This item allows the user to decide how long (in minutes) should the multiple event This feature allows the user to configure SMBIOS Event settings.

  • Page 68: Ipmi

    Chapter 7: BIOS UPER TORAGE YSTEM 2027R-E1CR24N User's Manual IPMI When SEL is Full This feature allows the user to decide what the BIOS should do when the system Use this feature to configure Intelligent Platform Management Interface (IPMI) event log is full. Select Erase Immediately to erase all events in the log when the settings.

  • Page 69: Boot

    Chapter 7: BIOS UPER TORAGE YSTEM 2027R-E1CR24N User's Manual Boot Security This submenu allows the user to configure the following boot settings for the This menu allows the user to configure the following security settings for the system. system. Administrator Password...

  • Page 70: Save & Exit

    Chapter 7: BIOS UPER TORAGE YSTEM 2027R-E1CR24N User's Manual Save & Exit Discard Changes Select this feature and press <Enter> to discard all the changes and return to the This submenu allows the user to configure the Save and Exit settings for the BIOS setup.
  • Page 71 UPER TORAGE YSTEM 2027R-E1CR24N User's Manual Notes 7-32...

  • Page 72: Appendix A Bios Error Beep Codes

    Appendix A: BIOS Error Beep Codes Appendix A BIOS Error Beep Codes During the POST (Power-On Self-Test) routines, which are performed at each system boot, errors may occur. Non-fatal errors are those which, in most cases, allow the system to continue to boot.
  • Page 73 UPER TORAGE YSTEM 2027R-E1CR24N User's Manual Notes...

  • Page 74: Appendix B System Specifications

    Appendix B: System Specifications Appendix B System Specifications Processors Single or dual Intel® Xeon E5-2600 Series processors Note: Please refer to our web site for a complete listing of supported processors. Chipset Intel C600 chipset BIOS 32 Mb AMI® SPI Flash ROM Memory Capacity Twenty-four DIMM sockets supporting up to 1.5 TB of LRDIMM (Load Reduced DIMM), 768 GB of RDIMM (Registered DIMMs) or 128 GB of UDIMM...
  • Page 75 Appendix B: System Specifications UPER TORAGE YSTEM 2027R-E1CR24N User's Manual Notes Weight Gross: 61 lbs. (27.7 kg.) System Cooling Three 8-cm system fans Two 8-cm exhaust fans One air shroud System Input Requirements AC Input Voltage: 100 - 240V AC auto-range...
  • Page 76 YSTEM 2027R-E1CR24N User's Manual (continued from front) The products sold by Supermicro are not intended for and will not be used in life support systems, medical equipment, nuclear facilities or systems, aircraft, aircraft devices, aircraft/emergency com- munication devices or other critical systems whose failure to perform be reasonably expected to result in significant injury or loss of life or catastrophic property damage.
