Slide Compound Miter Saw
INSTRUCTION MANUAL
2
EN
51
HE
LS1110F

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the LS1110F and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Makita LS1110F

Summary of Contents for Makita LS1110F

  • Page 1 Slide Compound Miter Saw INSTRUCTION MANUAL LS1110F...

  • Page 2: Specifications

    SPECIFICATIONS Model: LS1110F Blade diameter European countries 260 mm Countries other than Europe 255 mm - 260 mm Hole diameter European countries 30 mm Countries other than Europe 25.4 mm Max. kerf thickness of the saw blade 3.2 mm Max. miter angle Left 47°, Right 47°...

  • Page 3: General Power Tool Safety Warnings

    10. If the cord is damaged, have it replaced by the SAFETY WARNINGS manufacturer or his agent in order to avoid a safety hazard. Personal safety General power tool safety warnings Stay alert, watch what you are doing and use common sense when operating a power tool.

  • Page 4: Safety Instructions For Mitre Saws

    It is an employer's responsibility to enforce Safety instructions for mitre saws the use of appropriate safety protective equip- ments by the tool operators and by other per- Mitre saws are intended to cut wood or wood- sons in the immediate working area. like products, they cannot be used with abra- Power tool use and care such as bars, rods, studs, etc.
  • Page 5 Inspect your workpiece before cutting. If the workpiece is bowed or warped, clamp it with hold the saw head down and wait for the blade the outside bowed face toward the fence. Always make certain that there is no gap Reaching with your hand near the coasting blade between the workpiece, fence and table along is dangerous.
  • Page 6 10. While making a slide cut, KICKBACK can occur. KICKBACK occurs when the saw blade binds in the workpiece during a cutting operation and the saw blade is driven rapidly towards the operator. Loss of control and serious personal injury can result. If saw blade begins to bind during a cutting operation, do not continue to cut and release switch immediately.

  • Page 7: Parts Description

    PARTS DESCRIPTION Fig.2 Stopper arm Dust bag lower limit position) riage sliding) Pointer (for bevel angle) Bevel angle scale Slide pole Vertical vise Sliding fence Guide fence Sub base bevel angle) Miter angle scale Pointer (for miter angle) Kerf board Lock lever (for turn base) Grip (for turn base) Dust collecting guard...
  • Page 8 Fig.3 Lamp switch Shaft lock Stopper pin (for carriage mum cutting capacity) elevation) Set plate Hex wrench Lever (for bevel angle) bevel angle) Releasing button (for bevel angle) 8 ENGLISH...

  • Page 9: Installation

    INSTALLATION FUNCTIONAL DESCRIPTION Bench mounting WARNING: Always be sure that the tool is WARNING: Ensure that the tool does not move on the supporting surface. Movement of the checking function on the tool. miter saw on the supporting surface while cutting may and unplug the tool may result in serious personal Fix the base to a level and stable surface, screw- Handle lock...

  • Page 10: Slide Lock

    4. Blade guard WARNING: Do not remove spring holding blade guard. If guard becomes damaged in course of time or UV light exposure, contact a Makita ser- vice center for replacement. DO NOT DEFEAT OR REMOVE GUARD. Fig.8 1. Blade guard...
  • Page 11 Positioning kerf boards sides of the saw blade teeth. blade does not contact the kerf boards. Before use, all the screws (three each on left and right) securing the kerf boards. Fig.12 Fig.10 1. Kerf board 2. Screw Re-tighten them only to the extent that the kerf boards can still be easily moved by hand.
  • Page 12 Rotate the circular saw blade by hand while Maintaining maximum cutting holding the handle all the way down to be sure that capacity the circular saw blade does not contact any part of the necessary. cutting capacity for a 260 mm circular saw blade. WARNING: After installing a new circular saw When installing a new circular saw blade, always check...

  • Page 13: Adjusting The Miter Angle

    Tilting the circular saw blade to the Adjusting the miter angle left 0° - 45° CAUTION: After changing the miter angle, Rotate the lever counterclockwise. always secure the turn base by tightening the grip Hold the handle and tilt the carriage to the left. NOTICE: bevel angle scale.

  • Page 14: Switch Action

    When tilting the carriage to the right 2° Switch action WARNING: Before plugging in the tool, always check to see that the switch trigger actu- ates properly and returns to the “OFF” position when released. Do not pull the switch trigger hard cause switch breakage.

  • Page 15: Electronic Function

    WARNING: Use only the Makita wrench pro- Hold the handle and lower the circular saw blade vided to remove and install the circular saw blade. so a dense shadow of the saw blade is thrown against a Failure to use the wrench may result in overtightening workpiece.
  • Page 16 Common preparations for installing Installing the circular saw blade or removing the circular saw blade CAUTION: Make sure to install the circular Unlock the carriage by pulling the stopper pin, saw blade so that the direction of the arrow on then move the carriage to the raised position.
  • Page 17 Removing the circular saw blade wise securely using the hex wrench while pressing the shaft lock. Press the shaft lock to lock the spindle. Loosen the hex socket bolt clockwise using the hex wrench. circular saw blade. Fig.28 1. Hex socket bolt (left-handed) 2. 3.

  • Page 18: Securing Workpiece

    When you wish to perform clean cutting operation, remove particles adhering to the insides which might connect a Makita vacuum cleaner. hamper further collection. NOTICE: Depending on the type of vacuum cleaner...
  • Page 19 Guide fences left side of the base, right side of the base, or left side of the sub base. WARNING: Before operating the tool, make turn base. Position the workpiece at the desired cutting sure that the sliding fence is secured with the Make sure that no part of the tool contacts the vertical WARNING: Before bevel-cutting, make sure...

  • Page 20: Operation

    Gently lower the handle to the fully lowered posi- tion to cut the workpiece. Refer to our website or contact your local Makita dealer wait until the circular saw blade has come to a com- for the correct circular saw blades to be used for the plete stop before returning the circular saw blade to its material to be cut.

  • Page 21: Miter Cutting

    Slide (push) cutting (cutting wide Miter cutting workpieces) Bevel cut WARNING: Whenever performing a slide cut, the handle all the way down, then push the car- WARNING: After setting the saw blade for a riage toward the guide fence. Never start the cut bevel cut, ensure that the carriage and saw blade with the carriage not pulled fully toward you.

  • Page 22: Compound Cutting

    Cutting crown and cove moldings wait until the circular saw blade has come to a com- plete stop before returning the saw blade to its fully Crown and cove moldings can be cut on a compound elevated position. one type of cove moldings; 52/38° wall angle crown molding, 45°...
  • Page 23 Measuring Table (B) – Molding Molding edge Finished position in against guide piece fence of the workpiece's wall contact edge is the same as wall length. For inside Ceiling contact Finished piece corner edge should will be on the be against Left side of the guide fence.

  • Page 24: Carrying Tool

    Remove the workpiece material between the Cutting repetitive lengths grooves with a chisel. When cutting several pieces of stock to the same Carrying tool length, ranging from 225 mm to 350 mm, pull up the set Before carrying the tool, be sure to unplug the tool and Secure the workpiece in the position for cutting.

  • Page 25: Adjusting The Cutting Angle

    Fig.51 1. Stopper pin 2. 3. Hex socket bolts Centers, always using Makita replacement parts. Square the side of the saw blade with the face of the guide fence using a triangular rule or try-square. fence in order from the right side.
  • Page 26 If the pointer does not point to 0°, loosen the Carefully square the side of the saw blade with the top surface of the turn base using the triangular so that it points 0°. angle you have set. Fig.55 2. Saw blade 3. turn base If the pointer does not point 0°, loosen the screw 0°.

  • Page 27: After Use

    Both carbon brushes should be replaced at the same time. Use only identical carbon brushes. If you need any assistance for more details regard- ing these accessories, ask your local Makita Service Center. NOTE: Some items in the list may be included in the Fig.59...
  • Page 28 LS1110F- EN, HE 20230808...
