Makita LS1110F Instruction Manual
Slide compound miter saw
Hide thumbs
Also See for LS1110F:
- Instruction manual (161 pages) ,
- Instruction manual (128 pages) ,
- Instruction manual (29 pages)
Subscribe to Our Youtube Channel
Related Manuals for Makita LS1110F
Summary of Contents for Makita LS1110F
- Page 1 Slide Compound Miter Saw INSTRUCTION MANUAL מסור גרונג עם פנדל חוברת הוראות LS1110F...
-
Page 2: Specifications
SPECIFICATIONS Model: LS1110F Blade diameter European countries 260 mm Countries other than Europe 255 mm - 260 mm Hole diameter European countries 30 mm Countries other than Europe 25.4 mm Max. kerf thickness of the saw blade 3.2 mm Max. miter angle Left 47°, Right 47°... -
Page 3: General Power Tool Safety Warnings
10. If the cord is damaged, have it replaced by the SAFETY WARNINGS manufacturer or his agent in order to avoid a safety hazard. Personal safety General power tool safety warnings Stay alert, watch what you are doing and use common sense when operating a power tool. -
Page 4: Safety Instructions For Mitre Saws
It is an employer's responsibility to enforce Safety instructions for mitre saws the use of appropriate safety protective equip- ments by the tool operators and by other per- Mitre saws are intended to cut wood or wood- sons in the immediate working area. like products, they cannot be used with abra- sive cut-off wheels for cutting ferrous material Power tool use and care... - Page 5 18. After finishing the cut, release the switch, Inspect your workpiece before cutting. If the workpiece is bowed or warped, clamp it with hold the saw head down and wait for the blade to stop before removing the cut-off piece. the outside bowed face toward the fence.
- Page 6 10. While making a slide cut, KICKBACK can occur. KICKBACK occurs when the saw blade binds in the workpiece during a cutting operation and the saw blade is driven rapidly towards the operator. Loss of control and serious personal injury can result. If saw blade begins to bind during a cutting operation, do not continue to cut and release switch immediately.
-
Page 7: Parts Description
PARTS DESCRIPTION Fig.2 Adjusting screw (for Thumb screw (for car- Stopper arm Dust bag lower limit position) riage sliding) Pointer (for bevel angle) Bevel angle scale Slide pole Vertical vise 0° adjusting bolt (for Sliding fence Guide fence Sub base bevel angle) Turn base Miter angle scale Pointer (for miter angle) Kerf board Adjusting bolt (for turn Lock lever (for turn base) - Page 8 Fig.3 Adjusting bolt (for maxi- Lamp switch Shaft lock Stopper pin (for carriage mum cutting capacity) elevation) 45° adjusting bolt (for Set plate Hex wrench Lever (for bevel angle) bevel angle) Releasing button (for bevel angle) 8 ENGLISH...
-
Page 9: Installation
INSTALLATION FUNCTIONAL DESCRIPTION Bench mounting WARNING: Always be sure that the tool is WARNING: Ensure that the tool does not switched off and unplugged before adjusting or move on the supporting surface. Movement of the checking function on the tool. Failure to switch off miter saw on the supporting surface while cutting may and unplug the tool may result in serious personal result in loss of control and serious personal injury. -
Page 10: Slide Lock
4. Blade guard WARNING: Do not remove spring holding blade guard. If guard becomes damaged in course of time or UV light exposure, contact a Makita ser- vice center for replacement. DO NOT DEFEAT OR REMOVE GUARD. Fig.8 ► 1 . Blade guard... - Page 11 Adjust the kerf boards so that they are close to the Positioning kerf boards sides of the saw blade teeth. This tool is provided with the kerf boards in the turn base to minimize tearing on the exit side of a cut. The kerf boards are factory adjusted so that the circular saw blade does not contact the kerf boards. Before use, adjust the kerf boards as follows: Make sure that the tool is unplugged. Then, loosen all the screws (three each on left and right) securing the kerf boards. Fig.12 Fig.10 ► 1 . Kerf board 2. Screw Re-tighten them only to the extent that the kerf boards can still be easily moved by hand.
- Page 12 Rotate the circular saw blade by hand while Maintaining maximum cutting holding the handle all the way down to be sure that capacity the circular saw blade does not contact any part of the lower base. Re-adjust the maximum cutting capacity, if This tool is factory adjusted to provide the maximum necessary. cutting capacity for a 260 mm circular saw blade. WARNING: After installing a new circular saw When installing a new circular saw blade, always check...
-
Page 13: Adjusting The Miter Angle
Tilting the circular saw blade to the Adjusting the miter angle left 0° - 45° CAUTION: After changing the miter angle, Rotate the lever counterclockwise. always secure the turn base by tightening the grip Hold the handle and tilt the carriage to the left. firmly. -
Page 14: Switch Action
NEVER use the tool if it runs when you simply pull the switch trigger without press- ing the lock-off button. A switch in need of repair may result in unintentional operation and serious personal injury. Return tool to a Makita service center for proper repairs BEFORE further usage. Fig.20 To prevent the switch trigger from being accidentally ► 1 . Lever 2. Handle 3. Releasing button pulled, a lock-off button is provided. To start the tool,... - Page 15 The indicator helps cut through an existing cut-off line penciled on a workpiece. WARNING: Use only the Makita wrench pro- Hold the handle and lower the circular saw blade vided to remove and install the circular saw blade. so a dense shadow of the saw blade is thrown against a...
- Page 16 Common preparations for installing Installing the circular saw blade or removing the circular saw blade CAUTION: Make sure to install the circular Unlock the carriage by pulling the stopper pin, saw blade so that the direction of the arrow on then move the carriage to the raised position.
- Page 17 Install the outer flange and hex socket bolt. Removing the circular saw blade Tighten the hex socket bolt (left-handed) counterclock- Complete the steps in the “Common preparations wise securely using the hex wrench while pressing the for installing or removing the circular saw blade”. shaft lock. Press the shaft lock to lock the spindle. Loosen the hex socket bolt clockwise using the hex wrench. Then remove the hex socket bolt, outer flange and circular saw blade. Fig.28 ► 1 .
-
Page 18: Securing Workpiece
When you wish to perform clean cutting operation, remove particles adhering to the insides which might connect a Makita vacuum cleaner. hamper further collection. NOTICE: Depending on the type of vacuum cleaner... - Page 19 The vertical vise can be installed into the holes on the Guide fences left side of the base, right side of the base, or left side of the sub base. Press the workpiece flat against the guide fence and the WARNING: Before operating the tool, make turn base. Position the workpiece at the desired cutting sure that the sliding fence is secured with the position and secure it firmly by tightening the vise knob.
-
Page 20: Operation
— Aluminum products When the cut is completed, switch off the tool and Refer to our website or contact your local Makita dealer wait until the circular saw blade has come to a com- for the correct circular saw blades to be used for the plete stop before returning the circular saw blade to its material to be cut. -
Page 21: Miter Cutting
Slide (push) cutting (cutting wide Miter cutting workpieces) Refer to the section for adjusting the miter angle. Bevel cut WARNING: Whenever performing a slide cut, first pull the carriage full towards you and press the handle all the way down, then push the car- WARNING: After setting the saw blade for a riage toward the guide fence. -
Page 22: Compound Cutting
When the cut is completed, switch off the tool and Cutting crown and cove moldings wait until the circular saw blade has come to a com- plete stop before returning the saw blade to its fully Crown and cove moldings can be cut on a compound elevated position. miter saw with the moldings laid flat on the turn base. There are two common types of crown moldings and one type of cove moldings;... - Page 23 Table (B) Measuring Measure the wall width, and adjust the width of the – Molding Molding edge Finished workpiece according to it. Always make sure that width position in against guide piece the figure fence of the workpiece's wall contact edge is the same as wall length. For inside Ceiling contact Finished piece corner edge should will be on the be against Left side of the guide fence.
-
Page 24: Carrying Tool
Remove the workpiece material between the Cutting repetitive lengths grooves with a chisel. When cutting several pieces of stock to the same Carrying tool length, ranging from 225 mm to 350 mm, pull up the set plate as shown in the figure. Before carrying the tool, be sure to unplug the tool and Secure the workpiece in the position for cutting. -
Page 25: Maintenance
Fig.51 repairs, any other maintenance or adjustment should ► 1 . Stopper pin 2. Thumb screw 3. Hex socket bolts be performed by Makita Authorized or Factory Service Centers, always using Makita replacement parts. Square the side of the saw blade with the face of the guide fence using a triangular rule or try-square. Then securely tighten the hex socket bolts on the guide fence in order from the right side. -
Page 26: Bevel Angle
If the pointer does not point to 0°, loosen the Carefully square the side of the saw blade with screw which secures the pointer and adjust the pointer the top surface of the turn base using the triangular rule, try-square, etc. by turning the 0° adjusting bolt so that it points 0°. clockwise. Then tighten the lever firmly to secure the 0° angle you have set. Fig.55 ► 1 . Triangular rule 2. -
Page 27: After Use
Both carbon brushes should be replaced at the personal injury. same time. Use only identical carbon brushes. If you need any assistance for more details regard- ing these accessories, ask your local Makita Service Center. • Steel & Carbide-tipped saw blade •...
