Summary of Contents for Stoltzen APOLLO SA-6100E
- Page 1 4K60 4:4:4 over 1G HDMI over IP Encoder & Decoder w/ KVM...
-
Page 2: Important Safety Information
SA-6100E & SA-6100D USER MANUAL... -
Page 3: Important Safety Information
Protect the power cord from being walked on or pinched particularly at plugs, convenience receptacles, and the point where they exit from the product. Only use attachments/accessories specified by Stoltzen to avoid fire, shock, or other hazards. 10. To reduce the risk of electric shock and/or damage to this product, never handle or touch this unit or power cord if your hands are wet or damp. -
Page 4: Table Of Contents
Table of Contents Important Safety Information ................3 Overview ....................7 Features....................7 Package Contents ..................8 Encoder ..................... 8 Decoder ..................... 9 Specifications ....................10 Encoder ....................10 Decoder ....................12 Panel Description ................... 14 Encoder ....................14 Decoder ....................16 Bracket Installation .................. -
Page 5: Package Contents
Configuring before HDR10/Dolby Vision Signal Input ........23 Firmware Upgrade ..................23 Important Safety Information ................1 Overview ....................3 Features....................3 Package Contents ..................4 Encoder ..................... 4 Decoder ..................... 5 Specifications ....................6 Encoder ....................6 Decoder ....................8 Panel Description ................... -
Page 6: Decoder
Firmware Upgrade ..................22 Important Safety Information ................1 Overview ....................3 Features....................3 Package Contents ..................4 Encoder ..................... 4 Decoder ..................... 5 Specifications ....................6 Encoder ....................6 Decoder ....................8 Panel Description ................... 10 Encoder ....................10 Decoder .................... -
Page 7: Overview
Introduction Overview SA-6100E encoders and SA-6100D decoders provide the flexible, powerful, and scalable solution at resolutions up to 3840 x 2160@60Hz 4:4:4. They allow 4K UHD media to be switched and distributed over standard gigabit Ethernet networks, providing complete end-to-end streaming systems. -
Page 8: Package Contents
HDCP 2.2/2.3 compliant. Flexible routing policies, allowing audio, video, USB, IR and RS232 signals to be routed separately or as a whole throughout the matrix system. Allows AV, USB, IR, RS232 and power signals to be delivered up to 328ft/100m over a single Cat 5e cable or above. -
Page 9: Decoder
Decoder 1 x SA-6100D Unit 1 x DC 12V Power Adapter with EU Pins 1 x 3.5mm 3-Pin Phoenix Male Connector 1 x IR Emitter (1.2m) 1 x Broadband IR Receiver (1m, 30 kHz ~ 50 kHz) ... -
Page 10: Specifications
Specifications Encoder Video Input Video Port 1 x female HDMI type A (19 pins) Input Video Type HDMI 2.0, HDCP 2.2/2.3 3840 x 2160p@24Hz 4:4:4, 3840 x 2160p@30Hz 4:4:4, 3840 x 2160p@50Hz 4:4:4, 3840 x 2160p@60Hz 4:4:4, 640 x 480p@60Hz, 720 x 480p@60Hz 1280 x 720p@60Hz, 1920 x 1080i@60Hz, 1920 x 1080p@60Hz, 720 x 576p@50Hz 1280 x 720p@50Hz, 1920 x 1080i@50Hz... -
Page 11: Panel Description
Audio Input Audio Port 1 x HDMI; 1 x 3.5 mm stereo jack HDMI: Fully supports audio formats in HDMI 2.0 specification, including PCM 2.0/5.1/7.1, Dolby Input Audio Signal TrueHD, Dolby Atmos, DTS-HD Master Audio and DTS:X; Audio In: analog Output Audio Port 1 x 3.5 mm stereo jack;... -
Page 12: Decoder
Decoder Video Input Video Port 1 x female RJ-45, 1 x Optical Input Video Type IP Stream 3840 x 2160p@24Hz 4:4:4, 3840 x 2160p@30Hz 4:4:4, 3840 x 2160p@50Hz 4:4:4, 3840 x 2160p@60Hz 4:4:4, 640 x 480p@60Hz, 720 x 480p@60Hz 1280 x 720p@60Hz, 1920 x 1080i@60Hz, 1920 x 1080p@60Hz, 720 x 576p@50Hz 1280 x 720p@50Hz, 1920 x 1080i@50Hz 1920 x 1080p@50Hz, 1920 x 1080p@24Hz... - Page 13 Audio TrueHD, Dolby Atmos, DTS-HD Master Audio and DTS:X; Audio Out: Analog Control Windows Apollo Configurator, Apollo Visual Composer Control Method Touch, IP controller SA-C General Operating Temperature/ +32°F ~ +113°F (0°C ~ +45°C) Humidity 10% ~ 90%, non-condensing Storage Temperature/ -4°F ~ +158°F (-20°C ~ +70°C) Humidity...
-
Page 14: Panel Description
Panel Description Encoder Front Panel Name Description The device is powered on. POWER Blinking The device is booting. The device is powered off. The device is connected to an active video Solid On source. The device is not connected to an active STATUS Blinking video source. -
Page 15: Typical Applications
Name Description Note: When the settings are restored, your custom data is lost. Therefore, exercise caution when using the RESET button. Connect either the LAN (POE) port or Optical port LAN (POE) to a gigabit Ethernet switch for IP stream output and device control (the device can be powered by a PoE-enabled switch through LAN (POE) port). -
Page 16: Decoder
Decoder Front Panel Name Description The device is powered on. Blinking The device is booting. POWER The device is powered off. Solid The device is connected to an encoder and the video is displayed. The device is not connected to an encoder STATUS Blinking or the connected encoder has no active... -
Page 17: Bracket Installation
Rear Panel Name Description Connect this port to the 12 V 2 A power adapter. When the device is powered on, use a pointed stylus to hold down the RESET button for five or more seconds, and then release it, it will reboot and restore RESET to its factory defaults. - Page 18 Note: Before installation, ensure all devices are disconnected from the power source. Steps to install the device on a suitable location: Attach the mounting brackets to the panels of both sides using the screws (two on each side) provided in the package. Install the brackets onto the position as desired using the screws (not included).
-
Page 19: Typical Applications
Typical Applications Scenario 1 Ethernet Switch Amplifier Apple TV Encoder HDMI IN AUDIO OUT Decoder 3 x 3 Video Wall HDMI Set-top Box Encoder HDMI IN Serial Decoder HDMI 4K Media Player HDMI IN Encoder 4 x 5 Video Wall Decoder HDMI Workstation/PC... -
Page 20: Scenario 2
Scenario 2 Ethernet Switch Apple TV Remote Encoder Encoder HDMI IN 7.1 Surround Sound System Display Set-top Box Encoder Encoder Decoder HDMI IN HDMI OUT HDMI OUT 4K Media Player Encoder Encoder HDMI IN Display Remote Workstation/PC Decoder Encoder Encoder HDMI IN USB(PC) HDMI OUT... -
Page 21: Hardware Installation
Hardware Installation Lapto p Display (Keyboard and Mouse) Remote Amplifier Display Amplifier (PC) RS232 Dev ice USB Host RS232 RS232 IP Controller IP Stream Control Desktop iPad with VisualM IP Stream Control Ethernet Switch Wireles s Route r Control Lapto p Display (Keyboard and Mouse) Remote... -
Page 22: Operating The Devices
Operating the Devices Introduction to Different Operation Tools The SA-6100E encoders and SA-6100D decoders allow you to use Apollo Configurator, Apollo Visual Composer Touch and IP controller SA-C to manage and control them. This section briefly introduces how to route the video from source to the display using these tools. By default, audio, video together with IR, and USB signals are routed as a whole. -
Page 23: Performing Fast Switching
Performing Fast Switching The fast video switching function is that when a source change is implemented the switch occurs very quickly and appears seamless to the human eye with the latency of one second only. However, users shall meet several requirements prior to realize fast switching, otherwise video switching may take longer (approx. - Page 24 The following table lists different cases in which whether black screen encounters or not. Force Force Pass Timing (†) Change Case Force Timing Pass through Force (†)(#) Timing (w initial through (Strict HDCP (†)(#) Configuration pixel & Force Mode) format) HDCP ●...
-
Page 25: Configuring Mouse Roaming
Configuring Mouse Roaming SA-6100E encoders and SA-6100D decoders support Mouse Roaming. With configuration on Apollo Configurator, you can move the mouse to the edge of the screen to control different computers in a system. They support one set of mouse and keyboard to control up to 16 host computers. - Page 26 4. Create a layout for the video wall. Click VW in the RX list > Create Layout/Scene in the working area > specify a name for this layout and choose Mouse Roaming > OK. 5. Configure RX and TX for the created layout. Drag RXs from the RX list and TXs from Other Devices area to display tiles in the working area.
- Page 27 on the RX and choose Delete Master (or Delete Slave). 7. Reboot the RX for the Mouse Roaming configuration to take effect. Select Batch Commands > Others > select RX device > Reboot > Apply. Please wait for a few seconds for the RX device to reboot. Now you can use the Master Roaming mouse to control both computers.
-
Page 28: Configuring Before Hdr10/Dolby Vision Signal Input
Configuring before HDR10/Dolby Vision Signal Input SA-6100E and SA-6100D support HDR10 and Dolby Vision only if the device’s HDMI Timing Hybrid is set to “Pass-through” mode (default setting). Before you input HDR10/Dolby Vision video, ensure the source and all displays support HDR10/Dolby Vision, and follow the steps below to configure the decoder(s) through Apollo Configurator: 1. - Page 29 Tel: +47 22 90 37 00 | http://www.stoltzen.eu Sales: sales@stoltzen.eu | Technical: support@stoltzen.eu Address: Dronning Mauds Gate 15, 0250 OSLO, Norway...
